- Page 1 On April 1 , 2010, NEC Electronics Corporation merged with Renesas Technology Corporation, and Renesas Electronics Corporation took over all the business of both companies. Therefore, although the old company name remains in this document, it is a valid Renesas Electronics document. We appreciate your understanding.
- Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific”...
- Page 3 H8/36049 Group FP-80A User System Interface Cable User’s Manual Renesas Microcomputer Development Environment System HS36049ECH61H Rev.3.00 2005.10...
- Page 5 (iii) prevention against any malfunction or mishap. 1. These materials are intended as a reference to assist our customers in the selection of the Renesas Technology Corp. product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corp.
-
Page 7: Important Information
Renesas sales company. Such use includes, but is not limited to, use in life support systems. Buyers of this emulator product must notify the relevant Renesas sales offices before planning to use the product in such applications. -
Page 8: Limited Warranty
Renesas, upon inspection, shall determine to be defective in material and/or workmanship. The foregoing shall constitute the sole remedy for any breach of Renesas’ warranty. See the Renesas warranty booklet for details on the warranty period. This warranty extends only to you, the original Purchaser. - Page 9 The Warranty is Void in the Following Cases: Renesas shall have no liability or legal responsibility for any problems caused by misuse, abuse, misapplication, neglect, improper handling, installation, repair or modifications of the emulator product without Renesas’ prior written consent or any problems caused by the user system.
-
Page 10: Read First
• READ this user's manual before using this emulator product. • KEEP the user's manual handy for future reference. Do not attempt to use the emulator product until you fully understand its mechanism. DEFINITION OF SIGNAL WORDS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. - Page 11 Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1. Do not repair or remodel the emulator product by yourself for electric shock prevention and quality assurance.
- Page 12 Warnings on Emulator Usage Be sure to read and understand the warnings below before using this emulator. Note that these are the main warnings, not the complete list. Always switch OFF the host computer and user system before connecting or disconnecting any CABLES or PARTS. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY.
- Page 13 Preface Thank you for purchasing this user system interface cable (HS36049ECH61H) for the Renesas’ original microcomputer H8/36049 group. The HS36049ECH61H is a user system interface cable that connects an H8/36049 group E6000 emulator (HS3664EPI61H or HS3664EPI62H; hereinafter referred to as the emulator) to the IC socket for an FP-80A package for the H8/36049 group MCU on the user system and to the H8/36049 group expansion I/O board (HS36024EIO61H).
-
Page 14: Table Of Contents
Section 1 Configuration...1 Section 2 Connection Procedures ...3 Connecting User System Interface Cable to Emulator Station (without Channel 3 of Serial Communication Interface for H8/36049 Group) ... 3 Connecting User System Interface Cable to Expansion I/O Board (with Channel 3 of Serial Communication Interface for H8/36049 Group) ... 5 Connecting User System Interface Cable to User System ... -
Page 15: Section 1 Configuration
Section 1 Configuration Use an IC149-080-017-B5 socket (manufactured by YAMAICHI ELECTRONICS Co., Ltd.) for the FP-80A package IC socket on the user system. Figure 1 shows the configuration of the HS36049ECH61H user system interface cable for the FP-80A package. To emulator station or expansion I/O board Screws (M2 x 8 mm) with flat washers... - Page 16 Table 1 lists the HS36049ECH61H components. Please make sure you have all of these components when unpacking. Table 1 HS36049ECH61H Components No. Component Cable body Cable head IC socket Socket cover Screws (M2 x 12 mm) Screws (M2 x 8 mm) CTS screws (M3 x 6 mm) Documentation Quantity...
-
Page 17: Section 2 Connection Procedures
Section 2 Connection Procedures Connecting User System Interface Cable to Emulator Station (without Channel 3 of Serial Communication Interface for H8/36049 Group) Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. - Page 18 Emulator station Cable body connector CTS screws (M3 x 6 mm) User system interface cable Figure 2 Connecting User System Interface Cable to Emulator Station...
-
Page 19: Connecting User System Interface Cable To Expansion I/O Board (With Channel 3 Of Serial Communication Interface For H8/36049 Group)
Connecting User System Interface Cable to Expansion I/O Board (with Channel 3 of Serial Communication Interface for H8/36049 Group) Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part. Before connecting, make sure that pin 1 on both sides are correctly aligned. - Page 20 Expansion I/O board Cable body connector CTS screws (M3 x 6 mm) User system interface cable Figure 3 Connecting User System Interface Cable to Expansion I/O Board...
-
Page 21: Connecting User System Interface Cable To User System
Connecting User System Interface Cable to User System Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part. Before connecting, make sure that pin 1 on both sides are correctly aligned. -
Page 22: Inserting Cable Head
2.3.3 Inserting Cable Head Check the location of pin 1 before inserting. Align pin 1 on the IC socket for an FP-80A package on the user system with pin 1 on the user system interface cable head, and insert the user system interface cable head into the IC socket on the user system, as shown in figure 4. - Page 23 Fasten the user system interface cable head to the IC socket for an FP-80A package on the user system with the four screws (M2 be tightened a little at a time, alternating between screws on opposing corners. Take special care, such as manually securing the IC socket soldered area, to prevent the soldered IC socket from being damaged by overtightening the screws or twisting the components.
-
Page 24: Fastening Cable Body
2.3.5 Fastening Cable Body Connect the cable body to the cable head. Removing Cable body Push two remove jigs. Remove jig Cable head User system Figure 5 Fastening Cable Body... -
Page 25: Recommended Dimensions For User System Mount Pad
Recommended Dimensions for User System Mount Pad Figure 6 shows the recommended dimensions for the mount pad (footprint) for the user system with an IC socket for an FP-80A package (IC149-080-017-B5: manufactured by YAMAICHI ELECTRONICS Co., Ltd.). Note that the dimensions in figure 6 are somewhat different from those of the actual chip's mount pad. -
Page 26: Dimensions For User System Interface Cable Head
Dimensions for User System Interface Cable Head The dimensions for the user system interface cable head are shown in figure 7. 28.0 19.0 66.0 Unit: mm Tolerance: ±0.5 mm Figure 7 Dimensions for User System Interface Cable Head... -
Page 27: Resulting Dimensions After Connecting User System Interface Cable
Resulting Dimensions after Connecting User System Interface Cable The resulting dimensions, after connecting the user system interface cable head to the user system, are shown in figure 8. Cable head User system Figure 8 Resulting Dimensions after Connecting User System Interface Cable IC socket (IC149-080-017-B5 manufactured by... -
Page 28: Section 3 Installing The Mcu To The User System
Section 3 Installing the MCU to the User System 1. Check the location of pin 1 before inserting. 2. Use a Philips-type screwdriver whose head matches the screw head. 3. The tightening torque must be 0.0785 N•m or less. If the applied torque cannot be accurately measured, stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening. - Page 29 Screws (M2 x 8 mm) with flat washers User system Figure 9 Installing MCU to User System Socket cover Pin 1 IC socket (IC149-080-017-B5 manufactured by YAMAICHI ELECTRONICS Co., Ltd.)
-
Page 30: Section 4 Verifying Operation
Section 4 Verifying Operation 1. Turn on the emulator according to the procedures described in the H8/3664 E6000 Emulator User’s Manual (HS3664EPI61HE-U2 or HS3664EPI62HE-U2). 2. Verify the user system interface cable connections by accessing ports and checking the bus states of the pins. If an error is detected, recheck the soldered IC socket and the location of pin 3. - Page 31 Figure 10 shows the system clock oscillator on the user system interface cable and the subclock input specifications. Ω R1 1 M HCU04 To E6000 emulator HCU04 Ω R2 270 OSC1 OSC2 System clock oscillator Figure 10 System Clock Oscillator and Subclock Input Specifications Ω...
-
Page 32: Section 5 Notice
1. Make sure that pin 1 on the user system IC socket is correctly aligned with pin 1 on the cable head before inserting the cable head into the user system IC socket. 2. The dimensions of the recommended mount pad for the user system IC socket are different from those of the MCU. - Page 33 6. The P1 short connector is used for testing. Do not remove the inserted jumper pin. Figure 12 P1 Short Connector...
- Page 34 Publication Date: Rev.1.00, May 23, 2003 Rev.3.00, October 27, 2005 Published by: Sales Strategic Planning Div. Renesas Technology Corp. Edited by: Customer Support Department Global Strategic Communication Div. Renesas Solutions Corp. © 2005. Renesas Technology Corp., All rights reserved. Printed in Japan.
- Page 35 Nippon Bldg., 2-6-2, Ohte-machi, Chiyoda-ku, Tokyo 100-0004, Japan http://www.renesas.com RENESAS SALES OFFICES Refer to "http://www.renesas.com/en/network" for the latest and detailed information. Renesas Technology America, Inc. 450 Holger Way, San Jose, CA 95134-1368, U.S.A Tel: <1> (408) 382-7500, Fax: <1> (408) 382-7501...
- Page 36 H8/36049 Group FP-80A User System Interface Cable User’s Manual 1753, Shimonumabe, Nakahara-ku, Kawasaki-shi, Kanagawa 211-8668 Japan REJ10J1150-0300...
