- Page 1 ENGLISH INSTALLATION, OPERATION AND MAINTENANCE MANUAL Original Instructions RETAIN FOR FUTURE REFERENCE www.casals.com...
- Page 2 Dear customer, Thank you for purchasing a CASALS VENTILATION product made of high quality materials and advanced technologies. The quality level is under constant control, so that CASALS VENTILATION products are therefore synony- mous with Safety, Quality and Reliability. products are therefore synonymous with Safety, Quality and Reliability.
- Page 3 Reproduction, data storage and transmission, even partial, of this publication, in any form, without the prior written author- isation of Casals Ventilación Air Industrial S.L.U, is prohibited. Casals Ventilación Air Industrial S.L.U can be contacted for all inquiries regarding the use of its products.
-
Page 4: Table Of Contents
GENERAL INDEX 1. INTRODUCTION ..................................06 1.1 General information ............................06 1.2 Purpose and Content of the Instructions ......................06 1.3 Storage of instructions ............................ 06 1.4 Instructions update ............................06 1.5 How to use these instructions ........................06 1.6 Residual Risks ..............................07 1.7 General Safety Symbols ........................... - Page 5 14. RS485 SERIAL INTERFACE CARD............................36 15. CO PROBE ..................................36 16. ELECTRICAL CONNECTIONS .............................. 37 16.1 Electrical data ..............................38 16.2 Power supply connection ..........................38 16.3 Terminal Block Connections .......................... 39 16.4 Detail of electrical panel ..........................41 17.
-
Page 6: Introduction
1. INTRODUCTION Units must be installed and operated according to the instructions in this manual. Strict adherence to these simple instructions is a prerequisite to: • eliminate or reduce shutdown time due to unexpected failures; • improve the performance of components, resulting in energy savings; •... -
Page 7: Residual Risks
1.6 Residual Risks A residual risk is any hazard that cannot be fully reduced by design and protective techniques, or a potential hazard that is not obvious. ATTENTION This manual indicates any operation that may generate a hazardous situation as well as the precautionary measures to be observed in each case. - Page 8 Whilst the unit has been designed to minimize any risk posed to the safety of people who will interact with it. It has not been technically possible to eliminate completely the causes of risk. It is therefore necessary to refer to the require- ments and symbolism below.
-
Page 9: General Safety Symbols
1.7 General Safety Symbols Individual safety symbols in accordance with ISO 3864-2: PROHIBITION A black symbol inserted in a red circle with a red diagonal indicates an action that must not be performed. WARNING A black graphic symbol within a yellow triangle with black borders indicates a hazard. MANDATORY ACTION A white symbol inserted in a blue circle indicates an action that must be performed to avoid a hazard. -
Page 10: Safety Symbols
1.8 Safety Symbols GENERAL DANGER Strictly observe all indications placed beside the pictogram. Failure to observe the indications may lead to situations of risk with possible consequent damage to the health of the operator and the user in general. ELECTRICAL HAZARD Observe all signs placed next to the pictogram. -
Page 11: Limits Of Use And Prohibited Uses
A FAC-SIMILE of the nameplate is shown below with the relative caption of the data:: CAPTION: Unit model and size Manufactured by: CASALS VENTILACIÓN AIR Power supply characteristics INDUSTRIAL S.L.U Ctra. Camprodon, s/n 17860 Sant Joan de les Abadesses Nominal air flow (Girona) Spain - Tel. -
Page 12: Technical Characteristics
2. TECHNICAL CHARACTERISTICS 2.1 Introduction Any occupied room requires the correct supply of fresh air and, at the same time, the control of the internal thermo- hygrometric conditions, through the recovery of energy from the air extracted from the room, by means of static counter- flow heat recoveries, the level of well-being of the occupants is guaranteed, both in summer and winter. -
Page 13: Air Filters
2.4 Air filters ≥ 50% (F7) rigid bag filters in fresh air. Both types of filters are mounted on slides equipped with gaskets to ensure effec- tive sealing. Their position, upstream of the internal components, also guarantees their protection. 2.5 Fans The units are equipped with high efficiency plug-fan type fans with built-in brushless EC motor. -
Page 14: Version Control Evo Cav
3.3 Version CONTROL EVO CAV CONTROL EVO CAV: this control option is set to operate at constant air-flow, it is supplied complete with pressure transducer and air temperature sensors installed on the fresh air intake and room return air. The control system allows to select, in stepless mode, the supply and return fan speeds and automatically manages the heat recovery by-pass damper through the motorized On/Off control. -
Page 15: Main Components Of The Unit
5. MAIN COMPONENTS OF THE UNIT Return air filter Water heating/cooling coil Counterflow heat exchanger Backward blade fan, EC brushless motor with external rotor (supply side) Backward blade fan, EC brushless motor with external rotor (exhaust side) Electrical panel Air damper with actuator LCD remote display with segments (CONTROL BASIC version only) Electric defrost coil... -
Page 16: Available Accessories
6. AVAILABLE ACCESSORIES Return / Supply side ePM ≥ 50% (F7) air pre-filter Made of galvanized steel sheet frame and undulated filter media, 48mm thickness, in white synthetic material, contained by two welded galvanized nets. The filter media has a low pressure drop and it may be installed as pre-filter in combination with ≥... - Page 17 Antifreeze electric coil (external) The antifreeze system consists of an electric coil installed on the fresh air inlet. It is supplied in a dedicated section external to the base unit to be fixed using an installation kit supplied with it. Defrost system (internal) The automatic defrost system consists of a self-regulating electric coil in PWM mode of the input power, installed on the return air intake.
-
Page 18: Operating Mode
7. OPERATING MODE 7.1 Winter operating mode The return air from the room, with a higher thermal load than the fresh air, crosses the plate heat exchanger, where it gives up part of its thermal load and cools down before being exhausted. The fresh air, with a lower thermal load than the return one from the room, crosses the plate heat exchanger in the opposite direction and heats up before the introduction into... -
Page 19: Technical Data
8. TECHNICAL DATA MODEL Type of ventilation unit UVNR-B (Non Residential Ventilation Units - Bidirectional) Type of drive installed Analog signal on EC fan (0-10Vdc) Type of fans type/nr. EC / 2 EC / 2 EC / 2 EC / 4 EC / 2 Type of heat recovery system (HRS) type/nr. -
Page 20: Ventilation Curves
9. VENTILATION CURVES The graphs below indicate the operating limits of the EC fans installed on the units. Consider the static pressure shown as available for ductwork, having a unit equipped with ePM ≥50% (F7) on the supply side. The operating limits of the units may vary depending on the configuration and the components installed. For different unit configurations, please refer to the selection software or contact the company. - Page 21 1500 1900 2300 2700 3100 3500 3900 4300 4700 5100 5500 5900 6300 6700 Air flow [m³/h] 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000 Air flow [m³/h] 3000 4000 5000 6000 7000 8000 9000 10000 11000...
- Page 22 5000 6500 8000 9500 11000 12500 14000 15500 17000 18500 20000 Air flow [m³/h] 7000 9000 11000 13000 15000 17000 19000 21000 23000 25000 Air flow [m³/h] 9000 12000 15000 18000 21000 24000 27000 30000 33000 36000 Air flow [m³/h]...
-
Page 23: Operating Limits
10. OPERATING LIMITS SUMMER WINTER Only with defrost system External temperature [°C] External temperature [°C] All units can operate, within the given limits, with room relative humidity in the not exceeding 65%. It is mandatory to use the units within the operating limits shown in the diagrams above. The warranty will im- mediately expire if the unit is used in working conditions outside the above limits. -
Page 24: Sound Data
11. SOUND DATA The noise level of units is basically due to the fan rotation speed. Obviously, with the same air flow rate, the fan speed will be lower if the required static pressure is low, while it will be higher (and therefore noisier) if the required static pressure is higher. -
Page 25: Safety And Control Devices
12. SAFETY AND CONTROL DEVICES • Supply air temperature probe Passive sensor type NTC 10kΩ. Positioned on the supply air side, downstream of the heating/cooling units, it is used to monitor the temperature of the air supplied to the room. It is installed in combination with the temperature control accessories (water coils or post-heating electric resistance). -
Page 26: Installation
13. INSTALLATION General warnings and use of symbols Before carrying out any type of operation, each operator must be perfectly familiar with the operation of the machine and its controls and must have read and understood all the information contained in this manual. All operations performed on the machine must be carried out by qualified personnel in compliance with the national legislation in force in the country of destination. -
Page 27: Receipt And Inspection
13.1 Receipt and inspection When installing or working on the unit, it is necessary to scrupulously follow the instructions given in this manual, observe the indications on board the unit and in any case apply all necessary precautions. Failure to follow these instructions may result in dangerous situations. -
Page 28: Lifting And Handling
13.4 Lifting and handling Each unit section or single piece unit is provided with appropriate lifting points (lifting lugs or perimeter holes for lifting bars) clearly identified in the structural base. When unloading the unit, it is strongly recommended that sudden movements are avoided in order to protect the internal component of the unit. -
Page 29: Positioning
13.5 Positioning 13.5.1 Preliminary notice The unit must be placed in a special area that can be made inside a technical room or outside in a covered area or not, depen- ding on the structure on site. Prior to proceeding to unit installation it is recommended to check the following: •... - Page 30 • in case of overhead positioning, the individual support points must be realized in order to support the corresponding mass of the section in consideration of the unit’s height and in compliance with the safety limits for seismic risk. (Fig. F (concrete) Fig.
-
Page 31: Service Area Requirements
13.5.2 Service area requirements Area choosen for unit assembly must allow sufficient clearance space, around and on top of unit, for unit installation and further ordinary and extraordinary maintenance operations. Particularly important is the service area on the inspection and connection side, in order to allow panels to open completely and coils to slide out completely for extraordinary maintenance. - Page 32 EXTERNAL JUNCTIONS SCHEME INTERNAL JUNCTIONS SCHEME Install the unit to allow ordinary and extraordinary maintenance. The warranty does not cover costs related to platforms or handling equipment necessary for any intervention. Choose the installation site in accordance with EN 378-1 and 378-3.
-
Page 33: Hydronic Connections
13.7 Hydronic connections All connections should be made with the best available current workmanship practice according to the indicated dimensions of inlet and outlet diameters. Outlet connections should be complete with water traps and their height calculated on the basis of the maximum negative pressure existing at the drainage point. -
Page 34: Direct Expansion Coils
Coil performance is normally rated for counter-flow circuit arrangement, consequently coils are provided with water inlet at the bottom and downstream air flow, outlet at the top and upstream air flow. The stickers on the unit with the respective inlet and outlet symbols placed near the headers respect this rule. Furthermore, water circuit should be provided with: 1) water drain to be positioned at the unit lowest point (obligatory);... -
Page 35: Connecting The Unit To Air Ducts
13.10 Connecting the unit to air ducts FLEXIBLE JOINT DUCT Fixing of air ducts GENERAL RULES For a correct installation of the ductwork it is recommended to: • design the duct so that the air speed never exceeds 4-5 m/s, for the purpose of noise containment; •... -
Page 36: Rs485 Serial Interface Card
14. RS485 SERIAL INTERFACE CARD Serial line interface card to the supervision system (available only MODBUS-RS485). The installation of the card will allow the unit to be connected to a system with MODBUS-RS485 protocol. This system allows you to remotely monitor all the operating parameters of the unit and change their values. The serial inter- face card is installed and wired exclusively in the factory. -
Page 37: Electrical Connections
16. ELECTRICAL CONNECTIONS Preliminary safety information The electrical connection must be made according to the wiring diagram enclosed with the unit and in com- pliance with local and international regulations. Make sure the disconnector of the unit power supply line is upstream the unit. Ensure it is padlocked or that the appropriate warning is present indicating not to operate. -
Page 38: Electrical Data
16.1 Electrical data The following electrical data refer to the basic unit without accessories. In all other cases, refer to the electrical data in the wiring diagram attached to the unit. The supply voltage must not vary more than ± 10% of the nominal value and the unbalance between phases must be less than 1% according to EN 60204. -
Page 39: Terminal Block Connections
16.3 Terminal Block Connections Terminal numbers may change without notice. ALWAYS refer to the wiring diagram supplied with the unit. All the terminals shown in the following tables are in the terminal block inside the electrical cabinet, all the electrical connections mentioned below must be made in the field by the installer. - Page 40 REMOTE DISPLAY FOR CONTROL D2 - EPJ Graph (supplied with units in "CONTROL EVO COP" and "CONTROL EVO CAV" version only) 00 connect to terminal 3 of the display; 4.8 connect to terminal 4 of the display; 5.5 connect to terminal 2 of the display; 5.6 connect to terminal 1 of the display;...
-
Page 41: Detail Of Electrical Panel
16.4 Detail of electrical panel triac signal HEATERS' KIT MAIN BOX MAIN POWER SUPPLY sectioning LINE triad DOUBLE BOX WITH SINGLE DOOR INTERLOCKED BY MAINSWITCH HEATERS' KIT MAINSWITCH 17. STARTUP 17.1 Preliminary checks It is necessary to carry out preliminary checks on the electrical and hydraulic parts before starting the unit. Perform the commissioning operations in accordance with all the requirements of the previous paragraphs. -
Page 42: Description Of The Controller
17.2 Description of the controller 17.2.1 Function of keys and display icons (CONTROL BASIC) LCD REMOTE DISPLAY WITH SEGMENTS (CONTROL BASIC version only) Operating mode Current week DAY Bands SUMMER / WINTER indicator enabled Extract air Heat recovery temperature active icon Automatic mode Desired ventilation... -
Page 43: Function Of Keys And Display Icons (Control Evo Cop And Control Evo Cav)
17.2.2 Function of keys and display icons (CONTROL EVO COP and CONTROL EVO CAV) LCD REMOTE GRAPHIC DISPLAY (CONTROL EVO COP and CONTROL EVO CAV versions only) DATE and TIME Extract air indicator temperature ON / STAND-BY Operating mode SUMMER / WINTER Alarm Manual icon / Bands enabled... -
Page 44: Unit Use
18. UNIT USE 18.1 Turn the unit and setting parameters (CONTROL BASIC) LCD REMOTE DISPLAY WITH SEGMENTS (CONTROL BASIC version only) PRESS AND HOLD Once the unit is powered and the main switch is activated, To change the operation mode: the display turns on and shows the “OFF”... -
Page 45: Alarms Display And Reset
18.2 Alarms display and reset x 4 TIMES SET-POINT CONSTANT FLOW RATE (m /h / 10) SET-POINT CONSTANT PRESSURE (Pa) When there is an alarm which requires an immediate unit To change the parameter: STOP, the unit will turn off showing the OFF alarm screen. •... - Page 46 To reset an alarm, is enough to press the ”SET” key. If the alarm is correctly reset, ”NO ALARM” screen is dis- played. Once reset all the alarms, the blinking icon with the exclama- tion point disappears and ”NO ALARM” screen is displayed. To go back to the main screen press the ON / STAND-BY”...
-
Page 47: Turn On The Unit And Setting Parameters (Control Evo Cop And Control Evo Cav)
18.3 Turn the unit and setting parameters (CONTROL EVO COP and CONTROL EVO CAV) LCD REMOTE GRAPHIC DISPLAY (CONTROL EVO COP and CONTROL EVO CAV versions only) PRESS AND HOLD Once the unit is powered and the main switch is activated, To change the operation mode: the display turns on and shows the “Unit OFF BY KEYBOARD”... -
Page 48: Set "Real Time Clock" (Rtc)
18.4 Set "Real Time Clock" (RTC) PRESS x 2 TIMES AND HOLD SET-POINT CONSTANT FLOW RATE (m /h / 10) In the event of a prolonged power failure, it may be necessary SET-POINT CONSTANT PRESSURE (Pa) to reset the unit's RTC clock (”ALARM 29”). To change the parameter: From the main screen, through press and hold of the “OK”... -
Page 49: Alarms Display And Reset
18.5 Alarms display and reset When there is an alarm which requires an immediate unit If there are several active alarms, they can be displayed in STOP, the unit will turn off showing the ”Unit OFF BY ALARM” sequence by pressing the ”UP” or ”DOWN”keys. screen. -
Page 50: Diagnosis And Troubleshooting
19. DIAGNOSIS AND TROUBLESHOOTING 19.1 Troubleshooting All units are checked and tested at the factory before delivery, however, it is possible that some anomaly or failure may occur during operation. It is recommended to reset an identification alarm only after removing the cause that generated it; repeated resets may result in irreversible damage to the unit. -
Page 51: Dimensional Drawings
20. DIMENSIONAL DRAWINGS CONFIGURATION H1 Due to the large number of configurations available, only general dimensional drawings are shown, which are to be considered purely indicative and may change without notice. The specific drawing of the ordered unit is present in the documents supplied with the unit itself. GENERAL DIMENSIONAL DATA (50 mm profile Monoblock) MOD. -
Page 52: Unit Maintenance
21. UNIT MAINTENANCE 21.1 General warnings Maintenance allows you to: • Keep the unit efficient. • Prevent possible breakdowns. • Reduce the rate of deterioration of the unit. It is advisable to provide a unit booklet with the purpose of keeping track of the interventions carried out on the unit, facilitating the potential search for faults. -
Page 53: Dismantlement, Materials' Disposal And Recycling
22. DISMANTLEMENT, MATERIALS’ DISPOSAL AND RECYCLING 22.1 Unit disconnection Disconnection operations must be effected by a qualified technicist, who must follow the dispositions provided in this manual into the section “residual risks”. Before the disconnection of the unit the following materials (if any) must be recovered: •... -
Page 54: Raee Directive (Eu Only)
22.2 RAEE Directive (EU only) • The RAEE Directive requires that the disposal and recycling of electrical and electronic equipment must be managed through a specific collection, in appropriate centres, separate from mixed urban waste. • The user is obliged not to dispose of the equipment, at the end of its working life, as urban waste, but to comply with Directive 2012/19/EU at European level and with Legislative Decree 49/2014 at national level. - Page 55 NOTES...
- Page 56 The descriptions and illustrations in this catalogue are intended to be indicative and not binding. Without prejudice to the essential characteristics of the products described and illustrated here, CASALS reserves the right to make, at any time and without notice, changes to parts, aesthetic details or supply of accessories to its products that are deemed to be appropriate for improvement or for any construction or commercial requirement .
