  • Page 1 USER MANUAL AND INSTALLATION www.casals.com CV082021-1...
  • Page 2 INDEX DESCRIPTION p. 3 INSTALLATION p. 3 MAINTENANCE p. 3 EQUIPMENT WARRANTY p. 4 APPLICATION SETTINGS FOR THE UNIT p. 5 CONFIGURATIONS p. 6 CONDENSED BOARD p. 7 WIRING DIAGRAMS - FANS p. 7 ACCESSORIES - CUTTING SWITCH p. 8 ACCESSORIES - PRESSURE p.
  • Page 3: Installation

    DESCRIPTION ABRENSA EEC are heat recovery units that allow you to take advantage of the energy exchange between indoor and outdoor airflows. Its versatility of installation and the high number of possible configurations give this big equipment an adaptability to any type of building that can be installed on the outside as well as inside.
  • Page 4: Equipment Warranty

    If, during the warranty period, the product is experiencing problems resulting from manufacturing defects, Casals Ventilación or its Authori- zed Technical Services will, without any charge for repair at their premises or (at Casals Ventilación’s discretion) replace the product or place to the customer’s disposal the components to replace the defective ones in accordance with the following conditions.
  • Page 5: Troubleshooting

    Warranty exclusions • Natural wear parts. • Parts that are subject to deterioration or breakage, eg belts, filters, fuses, etc. • Malfunctions caused by misuse, abuse, neglect, negligence, lightning, flooding, humidity, falls, collisions, accidents and transportation. • Malfunctions caused by the use of the equipment for unintended purposes. •...
  • Page 6 Directives: Standard rules: • EN 60335-1: 2010 • Machinery Directive 2006/42 / CE • EN 60947-3: 2009 • EN 60947-5-1: 2004 + AC: 2005 + A1: 2009 • Low voltage directive 2014/35 / CE • EN 13857: 2008 • EN 12100-1: 2003 •...
  • Page 7 The P represents the maximum static pressure of the fan in mm c. to. The siphon must allow its cleaning for the purposes of regular maintenance. WIRING DIAGRAMS - FAN One of the vital components for the correct functioning of Casals Ventilación recovery units are the fans, so their correct connection must be guaranteed according to the following schemes.
  • Page 8 The installation of a cut-off switch is of major importance in order to safeguard those performing safety / maintenance interventions in ventilation equipment, and is obligatory to comply with the Machinery Directive 2006/42 / EC. Thus Casals Ventilación recovery units can be supplied with mounted cutting switches. The diagram below shows the connection diagram of the cut switch.
  • Page 9 ACCESSORIES - CONSTANT FLOW The constant flow attachment allows the flow to be maintained constant regardless of the variation of the system load loss. The flow con- trol is carried out using a relation between the occupied air flow rate and the pressure differential as indicated in the following image. A- Differential pressure sensor.
  • Page 10 The constant flow regulation is made in the flow controller, establishing a percentage value of the operating range selected in the differen- tial pressure sensor. For proper regulation you must follow the following steps: · Limit the operating range of the fan (JP1, SW2, R28, R29) ·...
  • Page 11 The regulation of the CO control is carried out in the CO controller, this being a percentage value of the reading range of the sensor in relation to the desired carbon dioxide concentration (ppm). For proper regulation you must follow the following steps: Limit the operating range of the fan (JP1, SW2, R28, R29) Regular SW1 (desired setpoint according to image).
  • Page 12: Important Considerations

    ACCESSORIES - DIRECT EXPANSION COIL Direct expansion coil modules can be used for heating or cooling. These coil use the flow rate of a refrigerant to transfer heat to the air. For proper operation and to avoid damaging the coil, the following warnings must be observed: •...
  • Page 13 ACCESSORIES - ELECTRICAL COIL - ABRENSA EEC 600 - 3kW - ABRENSA EEC 1300 - 6kW - ABRENSA EEC 900/2300 - 12kW - ABRENSA EEC 3000/3300 - 18kW PT: Thermal protection (Safety thermostat) CV082021-1...
  • Page 14 - ABRENSA EEC 4600 - 27kW - ABRENSA EEC 6700 - 36kW PT: Thermal protection (Safety thermostat) CV082021-1...
  • Page 15: Declaration Of Conformity

    DECLARATION OF CONFORMITY We hereby declare, under our only responsibility, that the CASALS brand products described in this manual comply with the directi- ves 2014/35/EU (Low Voltage),2006/42/EC (Machinery), 2014/30/EU (Electromagnetic compatibility), 2009/125/EC* (Ecodesign) and with all the standards mentioned in this instruction manual.
