- Page 1 Olivance PN-PN S- PN T PN X - PN XT PNEUMATIC RACKS USER MANUAL AND MAINTENANCE...
-
Page 2: Table Of Contents
OLIVANCE PN - PN S - PN T - PN X - PN XT index The manual in language is available at www.castellarisrl.com Use and maintenance manual: www.castellarisrl.com Manuale de uso y mantenimiento: www.castellarisrl.com USE AND MAINTENANCE MANUFACTURE: www.castellarisrl.com DESCRIPTION OF THE GENERAL CHARACTERISTICS OF MACHINERY 1.1. -
Page 3: Description Of The General Characteristics Of Machinery
This manual collects the necessary instructions for a correct and safe use of the pneumatic glazing "Olivance PN", "Olivance PN S" , "Olivance PN T" , " O l i v a n c e P N X " and " O l i v a n c e also N X T "... -
Page 4: Subjects To Whom The Manual Is Addressed
OLIVANCE PN - PN S - PN T - PN X - PN XT TELESCOPIC PNEUMATIC RODS APT 100 E APT 150 E APT 200 E FIXED PNEUMATIC RODS APF 100P APF 150 P APF 200 P APF 250 P... -
Page 5: Vibration Risk
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.6.2. Vibration risk The vibration level was measured by machine in motion, in accordance with UNI EN ISO 5349-1 2004 for the evaluation of vibrations transmitted to the MANO-BRACCIO system. The following value has been collected: Hand-arm vibration level: 17.3 m\s 2 considering the heaviest use of the machine. -
Page 6: Olivance Pn Components
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.7 Olivance PN Components • • Castellari S.r.l. road Lasie 16/E IMOLA (WILL) - Page 7 OLIVANCE PN - PN S - PN T - PN X - PN XT OLIVANCE PN POS. SET CODE SET DESCRIPTION PACK 100.OP01K CYLINDER BODY SET 100.OP47 GIGLER Ø2 100.OP40 THREADED SOAKING STOP OP14 POLYURETHANE WASHER OP19 LIP SEAL 100.OP09...
-
Page 8: Components Olivance Pn S
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.8 Components Olivance PN S • • Castellari S.r.l. road Lasie 16/E IMOLA (WILL) - Page 9 OLIVANCE PN - PN S - PN T - PN X - PN XT OLIVANCE PN-S POS. SET CODE SET DESCRIPTION PACK 100.OP01K CYLINDER BODY SET 100.OP47 GIGLER Ø2 100.OP40 THREADED SOAKING STOP OP14 POLYURETHANE WASHER OP19 LIP SEAL 100.OP09...
-
Page 10: Olivance Pn T Components
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.9 Olivance PN T Components • • Castellari S.r.l. road Lasie 16/E IMOLA (WILL) - Page 11 OLIVANCE PN - PN S - PN T - PN X - PN XT OLIVANCE PN-T POS. SET CODE SET DESCRIPTION PACK 100.OP01K CYLINDER BODY SET 100.OP47 GIGLER Ø2 100.OP40 THREADED SOAKING STOP OP14 POLYURETHANE WASHER OP19 LIP SEAL 100.OP60...
-
Page 12: Olivance Pn X Components
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.10 Olivance PN X Components • • Castellari S.r.l. road Lasie 16/E IMOLA (WILL) - Page 13 OLIVANCE PN - PN S - PN T - PN X - PN XT OLIVANCE PN-X POS. SET CODE SET DESCRIPTION PACK 100.OP01K CYLINDER BODY SET 100.OP47 GIGLER Ø2 100.OP40 THREADED SOAKING STOP OP14 POLYURETHANE WASHER OP19 LIP SEAL VE100145...
-
Page 14: Olivance Pn Xt Components
OLIVANCE PN - PN S - PN T - PN X - PN XT 1.11 Olivance PN XT Components • • Castellari S.r.l. road Lasie 16/E IMOLA (WILL) - Page 15 OLIVANCE PN - PN S - PN T - PN X - PN XT OLIVANCE PN-XT SET CODE SET DESCRIPTION PACK 100.OP01K CYLINDER BODY SET 100.OP47 GIGLER Ø2 100.OP40 THREADED SOAKING STOP OP14 POLYURETHANE WASHER OP19 LIP SEAL 100.OP60 PISTONE PER PN-T...
-
Page 16: Safety And Prevention
OLIVANCE PN - PN S - PN T - PN X - PN XT SAFETY AND PREVENTION It is very important to read this manual carefully in order to be able to minimize the risks due to a reckless or incorrect use of the machines covered by the manual. -
Page 17: Ecology And Pollution
OLIVANCE PN - PN S - PN T - PN X - PN XT At the end of maintenance and repair operations, before restarting the machines, the technical manager must ensure that the work is completed, the safety restored and that the protections have been reassembled. -
Page 18: Maintenance And Cleaning
OLIVANCE PN - PN S - PN T - PN X - PN XT enough to close the tap in the opposite position to the ignition position. In the event that the machine is temporarily unused, it is important to place it in a stable horizontal position, in order to avoid risky falls. -
Page 19: Solving Common Problems (See Website)
Via Lasie 16/E - 40026 IMOLA (BO) ITALY I declare under my sole responsibility that the electric rakes Olivance PN, Olivance PN S, Olivance PN T, Olivance PN X, Olivance PN XT comply with the essential safety and health protection requirements required by Directive 2006/42/EC of the European Parliament and of the Council. - Page 20 ® Via Lasie 16/E - 40026 IMOLA (Bo) Tel. +39 0542.43659 - +39 0542 628142 Fax +39 0542.41448 - +39 0542 626930 www.castellarisrl.com - info@castellarisrl.com...
