MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Diary of Changes Issue 1.0…………………………………………………………………………..…8 September 2002 First issue in new format Issue 2.0…………………………………………………………………………..……….13 April 2003 Applied TMWP 3.2 Improved all drawings Added Figure 19: Loom and Connector Positioning.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Coin Box Removal 1. Place the hopper in front of you as shown, (looking at the outside of the ‘Coin Box’). Refer to Figure 2. Remove the 2 locking nuts which hold the ‘Low Level Sense Plate’ wires to the studs.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Refer to Figure 6. Gently lift the ‘Coin Box’ away from the rest of the hopper. NOTE:- The ‘Logic Board’ & ‘Stirrer’ are located in the ‘Coin Box’. 7. As the ‘Coin Box’ is being removed, carefully slide the ‘Logic Board’ out. The stirrer may stay with the ‘Coin Box’...
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Low Level Sense Plate Removal 1. First, remove the ‘Coin Box’, see section 2. Refer to Figure Figure 4: Low level stud assembly 2. Remove the 2 remaining nuts & washers from the sense plate studs.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 High/Top Level Sense Plate Replacement The ‘High’ & ‘Top’ level sense plates can be accessed without removing the ‘Coin Box’. Refer to Figure Figure 6: High & Top level studs Irrespective of which plate is fitted :- 1.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Refer to Figure 5. Place the relevant sense plate in position. Figure 7: High & Top level sense positions 6. To re-assemble, follow steps 1 to 4, above, in reverse.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Exit Window Replacement 1. First, remove the ‘Coin Box’, see section 2. This will then enable access to the ‘Exit Window’ 2. Unscrew & remove the 2 fixing screws.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Logic Board Replacement 1. First, remove the ‘Coin Box’, section 2. This will then enable access to the ‘Logic Board’. Figure 9: Logic Board position 10 way ribbon IDC socket (CONN 1).
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 End Plate Removal 1. Place the hopper in front of you as shown, (looking at the outside of the ‘End Plate’). Refer to Figure 2. Remove the 9 screws indicated (B), which hold the ‘End Plate’ to the ‘Centre Plate’.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Track Plate Removal 1. First, remove the ‘End Plate’, section 7. Refer to Figure 2. The ‘Elevator Track’ & ‘Final Drive Gear’ can now be removed by lifting up & away from the ‘Centre Plate’.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 Track Plate Assembly The following 3 sketches show how to take the ‘Track Plate’ apart. Figure 12: Track Plate dismantling The following 3 sketches show how to assemble the ‘Track Plate’.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 10. Track Plate Replacement 1. The yellow shaded area, in Figure 14, is the ‘track plate’ guide path. Figure 14: Track Plate positioning 2. Once the ‘track plate’ is in position, turn the track through 720 to ensure it is seated in the guide path correctly.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 11. Final Drive Gear Replacement 1. Once the ‘Elevator Track’ is in place, the ‘Final Drive Gear’ can be fitted by placing the gear over its mounting spindle, while lining the teeth up with the secondary drive gear, adjust the ‘Elevator Track’...
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 14. Motor Replacement 1. Remove the ‘Coin Box’. Section 2. 2. Unsolder the red & black wires from the motor. NOTE: The black wire connects to the terminal marked with a RED dot.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 15. Loom Replacement 1. Remove the ‘Coin Box’. Section 2. 2. Unsolder the red & black wires from the motor. NOTE: The black wire connects to the terminal marked with a RED dot.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 16. Coin Box Assembly 1. Firstly, locate the ‘Stirrer’ in the ‘Coin Box’ as shown in Figure Figure 20: Stirrer position 2. Line up the ‘Centre Plate’ & ‘Coin Box’ as shown below.
MKIV Universal Hopper Service Manual TSP053.doc Issue 2.1 – June 2004 6. Lift the ‘Centre Plate’ to meet the ‘Coin Box’. Figure Figure 22: Coin Box Assembly (2) 7. Align the ‘centre plate’ & ‘coin box’ & push together. 8. Turn the hopper over & refit the screws.
Page 22
This manual is intended only to assist the reader in the use of this product and therefore Money Controls shall not be liable for any loss or damage whatsoever arising form the use of any information or particulars in, or any incorrect use of the product.
