- Page 1 TB 28 BT DT istruzioni per l’uso instructions for use instrucciones de uso instructions d’utilisation gebrauchsanweisung TB28BT DT_(DC)_IM_20190712...
- Page 2 TB 28 BT DT 3 - 10 ITALIANO 11 - 18 ENGLISH 19 - 26 ESPAÑOL 27 - 34 FRANÇAIS 35 - 42 DEUTSCH TB28BT DT_(DC)_IM_20190712...
- Page 3 Please read these instructions and the Safety section carefully before using your refrigerator. TB28 BT DT 366 mm 650 mm TECHNICAL FEATURES DIMENSIONS MODEL PRODUCT REFRIGERANT TEMPERATURE HXLXP VOLTAGE WEIGHT CLASS GAS AND CHARGE RANGE (mm) R134a 0,040 Kg TB28 BT -18°C ̴...
- Page 4 TB 28 BT DT INSTRUCTIONS WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING! Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 5: Installation
INSTALLATION - Place the refrigerator on a dry, sheltered, flat surface and away from any edges. The refrigerator must not be used unsheltered, in the open air or exposed to splashing or rain. - Your refrigerator requires good ventilation, especially around the back of the refrigerator, allow a gap of at least 15 cm around the sides, back and top. -
Page 6: Electronic Control
TB 28 BT DT ELECTRONIC CONTROL The device is equipped with a multi-level battery monitor that protects your vehicle battery against excessive discharging when the device is connected to the on-board DC supply. If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level. -
Page 7: Control Panel Use
CONTROL PANEL USE SETTINGS When the fridge is switched off: • Keep pressed on “ ” to turn on/off the left box • Keep pressed on “ ” to turn on/off the right box • Keep pressed on “ ” to turn on/off both boxes. When the fridge is switched on, keep pressed on the lighted button to switch off the appliance. - Page 8 TB 28 BT DT DISPLAY • When the device is switched on, the LEDs, the digital screen and the buttons flash for 2 seconds. • When the appliance is switched off, the buttons are lighted off. • When the appliance is switched on, the buttons and the display are lighted on.
-
Page 9: Off-S E T Valu E
OFF-S E T VALU E This is the information needed to align the temperature shown on the display with the actual temperature inside the refrigerated compartment. Each off-set can be adjusted within a range of from -10 to +10. After running the refrigeration system for a few hours, place a digital thermometer (not supplied) inside the compartment and check that the temperature shown on the display coincides with the temperature shown on the digital thermometer. -
Page 10: Maintenance
The power supply cable must be replaced only by qualified technical personnel and in any case by an fter sales service authorised by the Manufacturer. Indel B is not liable in any way if you do not comply strictly with all the previsions in this manual. FAULTS When there is error for the fridge, there will be code on the display. - Page 11 TB 28 BT DT INSTRUCCIONES ¡ADVERTENCIA! Mantenga las aberturas de ventilación, en el aparato o en la estructura integrada, libres de obstrucción. ¡ADVERTENCIA! No utilice dispositivos mecánicos u otros medios para acelerar el proceso de descongelación que no sean los recomendados por el fabricante.
