20L/25L
DEHUMIDIFIER
---------------------------------------------------------------------------------------------------
EN USER INSTRUCTION & OPERATION MANUAL
ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL
USUARIO
DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG
FR MANUEL D'UTILISATION ET D'UTILISATION
IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO
LOW NOISE
≤45dB(A)
TIMER
0-24 HOURS
CHILD-LOCK
FUNCTION
POWER
CORD
1.5M
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for netta OL20-BD030AM
Summary of Contents for netta OL20-BD030AM
- Page 1 20L/25L DEHUMIDIFIER LOW NOISE ≤45dB(A) TIMER 0-24 HOURS CHILD-LOCK FUNCTION POWER CORD 1.5M --------------------------------------------------------------------------------------------------- EN USER INSTRUCTION & OPERATION MANUAL ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL USUARIO DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG FR MANUEL D'UTILISATION ET D'UTILISATION IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO...
- Page 2 Thank you for purchasing this NETTA product. Please read the user manual carefully before operating this appliance. We will update our instruction manuals if necessary. For the most up-to-date user manual, please visit our official website: www.nettadirect.com. You can download a copy of up to date user manuals at any time in electronic format.
-
Page 3: Safety And Warnings
Safety and Warnings Regular Check-Ups Intended Use Ensure the power cable and NETTA Design is for domestic and plug are not damaged before indoor use only. This product is not plugging into a socket. intended for use by people who have... - Page 4 General Warnings • This appliance can be used by children aged from 8 years and above, by people with reduced physical, sensory or mental capabilities and/or by people with lack of experience or knowledge if they have been given supervision and/or instruction concerning operating the device in a safe manner and understanding the hazards involved.
- Page 5 • No open flames, cigarettes or other possible sources of ignition should be used in the vicinity of the device. • Component parts are designed for propane. They should only be replaced with identical repair parts. • Failure to abide by these warnings could result in an explosion, death, injury and/or property damage.
- Page 6 • Do not climb or sit on the unit. • Do not insert fingers or other objects into the air outlet. • Do not touch the air inlet or the aluminium fins of the unit. • Do not operate the unit if it has been dropped, damaged, or is showing signs of product malfunction.
- Page 7 • The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area specified for operation. • Any person who is involved with working or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorizes the competence to handle refrigerants safely in according with an industry-recognised assessment specification.
- Page 8 • If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Use a dry powder or CO2 fire extinguisher. • No person carrying out work in relation to a refrigerant system which involves exposing any pipework that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
-
Page 9: Product Overview
Product Overview... -
Page 10: Installing The Product
Installing the Product Location Place the unit on a firm, level surface in an area with at least 30cm of free space around it to allow proper air circulation. Never install the unit where it could be subject to heat sources (such as radiators, stoves, etc), in an area where oil or water may be splashed, direct sunlight, mechanical vibration or shock, excessive dust, lack of ventilation (such as a bookcase) or an... - Page 11 Installing the Product Operating the Device Safely • Check the device after unpacking for any damage or scratches on • Operate this unit in an ambient temperature from 5°C to 35°C. • Do not use outdoors. This device is intended for indoor residential applications only.
-
Page 12: Operating The Product
Operating the Product Three-Colours Indicator Light • If the ambient humidity is below 45%, the light will show blue. • If the ambient humidity is between 45%-65%, the light will show green. • If the ambient humidity is above 65%, the indicator light will show red. - Page 13 Mode Button Press the Mode button to switch between ‘Auto’ and ‘Continuous’ dehumidifying modes. Auto Mode: When the ambient humidity is more than 3% over the set humidity, the fan and compressor will start working. When the ambient humidity is less than 3% over the set humidity, the fan and compressor will stop working.
- Page 14 In ‘Sleep’ mode, when the water tank is full, the machine will not alarm but rather the water tank full indicator light will be on (red) to remind you that the water tank is full and needs emptying. Press and hold the ‘Sleep/Reset’ button for 3 seconds to reset the air filter.
-
Page 15: Cleaning, Maintenance And Storage
Add Button Press this button to set the timer and humidity levels. To adjust the humidity, press this button once to add 5% humidity. The humidity increases in the following sequence: 30% - 35% - 40% - 45% - 50% - 55% - 60% - 65% - 70% - 75% - 80% - 30%. To adjust the timer, select ‘Timer’... - Page 16 Drainage There are two ways of removing water collected by the unit. A. Manual Drainage: Empty the water tank manually. B. Continuous Drainage: Use gravity to drain water by attaching a drain hose. Manual Drainage The water tank will fill up and shut the unit down once it is full. It will only run again once you empty the water tank and re-install it.
- Page 17 Pull out the water tank. Empty the water tank. Replace the empty tank back into the unit.
- Page 18 Warning! 1. Do not discard the magnets and plastic rivets in the tank. Otherwise, the dehumidifier cannot be started, or the machine will not automatically stop working when the water tank is full, and the condensed water will overflow and possibly cause damage to your property.
- Page 19 Maintenance Before cleaning and maintaining the machine, be sure to turn off the machine and unplug the power to avoid electric shock. Cleaning the Air Filter (Every 2 Weeks) Dust collects on the filter and restricts the airflow. The restricted airflow reduces the efficiency of the system and if it becomes blocked it can cause damage to the unit.
-
Page 20: Troubleshooting
Troubleshooting SYMPTOM INSPECTION SOLUTION Check the power Insert the power cord connection is secure. securely into the wall outlet. Check if the ‘Water Empty the water tank The unit is not Tank Full’ indicator and re-install operating. light is on. correctly. - Page 21 Humidity sensor Clean or replace the Error Code – E2. failed or dampened. humidity sensor. This is normal. The Display when room compressor and fan Error Code – CL. temperature is below will stop working under these 5℃. conditions. This is normal. The Display when room compressor and fan temperature is below...
-
Page 22: Spare Parts And Repairs
You can also find this code on the back of this User Manual. For our Repair Service, please contact our customer support with email on support@nettadirect.com they will provide with more details of repair service with NETTA. Disposal of Product IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. - Page 23 Copyrights NETTA and its logo including images and contents in this manual and website is copyrighted. All intellectual property rights belong to NETTA owner CONSUMABLE DIRECT LIMITED. ANY UNAUTHORISED USE, MODIFICATION or DISTRIBUTION of the NETTA logo, website image, and its contents (from website, manuals) will violate worldwide copyright, trademark and associated laws.
