- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 3 0 600 Q UEEN BED REVISION 0: 04/03/2019 COASTERFURNITURE.COM REVISION 2: 09/29/2019 PAGE 1 OF 7...
- Page 2 306009QB1 ITEM : ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.Please check to see that all hardware and parts are present prior to start of assembly. 3.Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
- Page 3 ITEM : 30 6 0 0 9 Q B2 FOOTBOARD 1PC BED RAIL 2PCS SLAT SUPPORT 1PC 2PCS SLAT 26PCS SLAT SUPPORT WITH LEVELER 3PCS PLASTIC CONNECTOR 13PCS COASTERFURNITURE.COM 3 0F 7...
- Page 4 306009QB2 ITEM : HARDWARE PACKAGE FIGURE DESCRIPTION QUANTITY FIGURE QUANTITY DESCRIPTION Threaded bolt 8PCS Wrench 14mm M8*90mm Spring Washer Allen wrench 12PCS Flat Washer Allen wrench bolt 4PCS 4PCS Ø8*Ø18*2mm M8*30mm Flat Washer Plastic Washer 5PCS 8PCS Ø35mm*2mm Ø8*Ø22*2mm Nut Ø8*13mm 8PCS All above hardware pack is located in 306009QB2 COASTERFURNITURE.COM...
- Page 5 STEP 1 STEP 2 STEP 3 COASTERFURNITURE.COM 5 OF 7...
- Page 6 STEP 4 STEP 5 STEP 6 COASTERFURNITURE.COM 6 OF 7...
- Page 7 PRODUCT/PART DIMENSIONS PAGE 7 OF 7 COASTERFURNITURE.COM...
