Summary of Contents for Radio Shack Projection Clock Radio 12-591
- Page 1 12-591 User’s Guide Daytime/Nighttime • Atomic-Controlled Projection Clock Radio Thank you for purchasing your Projection Clock Radio from RadioShack. Please read this user’s guide before installing, setting up, and using your new Projection Clock Radio.
-
Page 2: Table Of Contents
Important Safety Instructions...3 Package contents ... 5 Features ... 5 Setup ... 6 Power Your Radio ... 6 Setting Time ... 10 Setting Alarms ... 11 Using the alarm ... 11 Operation ... 12 Tune to a Frequency ... 12 Preset Memory ... -
Page 3: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. The lightning symbol is intended to alert you to the presence of uninsulated, dangerous voltage within this product’s enclosure that might be of sufficient magnitude to constitute a risk of electric shock. - Page 4 no objects filled with liquids, such as vases, shall be placed on apparatus. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus.
-
Page 5: Package Contents
Package contents • Radio • User’s Guide • Quick Start Features • Projects time on the ceiling or wall • Automatically adjusts the brightness of the beam based on ambient lighting conditions • Time synchronizes with the U.S. government’s atomic clock, sets itself, and stays accurate •... -
Page 6: Setup
Setup Power Your Radio Connect the AC plug to a standard wall outlet. Install batteries for backup power. In the event of a power interruption, the backup batteries will retain your radio presets, the clock and alarm times in the memory only (normal clock, display and radio operation excluded): 1. - Page 7 Image Rotate Adjust the projection angle. TIME ZONE Select your time zone. Projection Focus Adjust the image focus. PROJECTOR HI/MED/ AUTO/OFF • Turn projector on/off • Select brightness level DST AUTO/OFF Turn daylight savings on/off. LOCK TIME/DATE Slide to TIME/DATE to set time manually. Slide to LOCK to save.
- Page 8 Light sensor Helps to detect light levels to automatically adjust projector brightness. See page 14, Using the projector. M 1/ M 2 Turn on or stop alarm 1 or alarm 2. WAVE Hold down about 10 seconds to turn on/off the atomic clock function.
- Page 9 SNOOZE/LIGHT • Stop the alarm for 10 minutes when the alarm sounds. • Briefly turn on the backlight /projector image. • Press and hold for 3 seconds to change backlight brightness level. Turn on/off the radio. FM/AM/AUX Select the desired frequency. SLEEP Select a sleep timer in 60, 30, 15 minute increments.
-
Page 10: Setting Time
• If you do not plan to use the radio for a long time, remove the batteries. Batteries can leak chemicals that can damage electronic parts. Setting Time Your clock attempts to synchronize with the atomic time signal automatically when you first turn it on and whenever you press RESET. The reception icon e flashes while it is searching for a signal. -
Page 11: Setting Alarms
7. Press SET to confirm. The year flashes. 8. Press or to select the year. 9. Press SET to confirm and slide LOCK TIME/DATE to LOCK to save the setting. Setting Alarms 1. Hold down SET until the time display of ALARM 1 flashes. 2. -
Page 12: Operation
• To deactivate the alarm, press the alarm time and alarm mode disappear. Operation Press G to turn on the radio. The last frequency appears. Tune the Radio 1. Press FM/AM/AUX to toggle between FM, AM and auxiliary input. 2. To manually find a frequency, press or until the desired frequency sounds. To auto scan a frequency, hold down ... -
Page 13: Find A Preset Station
. Press MEMORY to store the frequency and select the next preset frequency. 4. Repeat step 2–3 to store other preset frequencies. Find a Preset Station 1. Press MEMORY to recall the previous used memory frequency. 2. Press MEMORY again to go to the next preset frequency. Sleep Timer You can set your radio to turn off automatically after a predetermined period. -
Page 14: Using The Projector
. Adjust the sound control on your device. 4. Press POWER to turn off the radio. Using the Projector Project the current time, date, or radio frequency on a wall or ceiling, and rotate the projection +/- 90 degrees. • AUTO – The projection brightness changes according to the ambient brightness. In order for auto light detection to work properly, make sure you do not cover or obstruct the light sensor (see page 8.) •... -
Page 15: Additional Information
Additional Information Specifications Power supply ... 120V AC Output power ... 200 mW FM Frequency ...87.5 – 107.9 MHz, 200 kHz step AM Frequency ... 530 – 1700 kHz, 10 kHz step Size (L x W x H) ... 4.9 x 3.1 x 5.8 in (12.5 x 7.8 x 14.7 cm) Weight ... -
Page 16: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 17: Limited Warranty
Limited Warranty RadioShack warrants this product against defects in materials and workmanship under normal use by the original purchaser for ninety (90) days after the date of purchase from a RadioShack-owned store or an authorized RadioShack franchisee or dealer. RADIOSHACK MAKES NO OTHER EXPRESS WARRANTIES. This warranty does not cover: (a) damage or failure caused by or attributable to abuse, misuse, failure to follow instructions, improper installation or maintenance, alteration, accident, Acts of God (such as floods or lightning), or excess voltage or current;... - Page 18 LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RADIOSHACK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 20 Protect the environment by recycling used electronics. Go to E-CyclingCentral.com to find an electronic recycling center near you. ©2009. RadioShack Corporation. All rights reserved. RadioShack and RadioShack.com are trademarks used by RadioShack Corporation. Printed 06A09 in China 12-591...
