The same number of devices using 12 AWG wire will
produce only a 2 volt drop. The same number of devices
using 18 AWG wire will produce an 8 volt drop. Consult
your panel manufacturer's specifications, as well as the
sounder's operating voltage to determine the acceptable
voltage drop.
NOTE: If class "A" wiring is installed the wire length may
be up to 4 times the single wire length in this cal-
culation.
Table 1: Current Draw Measurements and
Sound Output Guide
Speed Selection
Switch Power
Speed Selection Setting
FAST (exit) 10 4 Watt
FAST (exit) 10 2 Watt
FAST (exit) 10 1 Watt
FAST (exit) 10 1 / Watt
2
FAST (exit) 10 1 / Watt
4
MED1 9 4 Watt
MED1 9 2 Watt
MED1 9 1 Watt
MED1 9 1 / Watt
2
MED1 9 1 / Watt
4
MED2 8 4 Watt
MED2 8 2 Watt
MED2 8 1 Watt
MED2 8 1 / Watt
2
1
MED2 8 / Watt
4
SLOW 7 4 Watt
SLOW 7 2 Watt
SLOW 7 1 Watt
SLOW 7 1 / Watt
2
SLOW 7 1 / Watt
4
NOTE 1: S ound output measured in anechoic room at 10 feet.
NOTE 2: S ound output measured in a reverberant room at 10 feet.
Installation
Consult the Directional Sound Applications Guide for
information regarding the appropriate mounting locations
of directional sounders.
Switch Settings
Selections are made via DIP switches on the back of
the sounder. Switch positions 7-10 are used to select the
pulse pattern of the sounder. Switch 10 is used to mark
the perimeter exit locations (fastest pulse). The remaining
settings are used for egress routing to the perimeter exit.
The egress route would originate with the "slow" (switch
7) tone and follow "medium 2" (switch 8) to "medium 1"
(switch 9) and finally the exit point "fast" (switch 10). If
D550-10-00
Maximum DC Audibility Audibility
Operating (dBA) (dBA)
Current (16 to (16 to
(mA RMS) 33V) 33V)
(16 to 33V) Note 1 Note 2
225 85 78
114 82 76
75 79 73
62 76 69
49 73 66
221 85 77
112 82 74
74 79 71
61 76 68
48 73 65
203 85 78
103 82 75
68 79 73
56 76 69
44 73 66
189 85 76
96 82 73
63 79 70
52 76 67
41 73 64
firealarmresources.com
more than one switch is selected the sounder will default
to the fastest selected setting.
Switch positions 5 and 6 are used to select additional
tone pulses that can be inserted in between bursts of the
directional sound pulses. The additional tone pulse will
be inserted on every 6th directional sound pulse. These
switches should be used when the sounder will be placed
near a stairway to guide a building occupant up or down
the stairs. Switch setting 5 inserts a down sweep indicat-
ing the presence of a downward stairway. Switch setting 6
inserts an up sweep indicating the presence of an upward
stairway. If switch positions 5 and 6 are both set to "on"
this will insert a special tone for use near areas of refuge.
The area of refuge tone should be used if the directional
sounder is marking an area of refuge. This tone provides
a distinct signal indicating that the sounder is not mark-
ing an exit. If both switches are set to "off" the sounder
will default to no additional tones. In this case only the
directional sound pulses will be heard. See Table 2 for tone
selection options.
Table 2: Additional Tone Selection Guide
Switch Switch
Position 5 Position 6
Setting Setting
on on
on off
off on
off off
Switch setting 4 enables a directional sound device to
become disabled when used in conjunction with devices
with dry contacts such as heat sensors or control modules.
The sounder has a set of input terminals that can be con-
figured for an "active open" or "active closed" state. When
the switch is in the "on" position, the sounder is "on"
when the disable connection is closed. When the switch is
in the "off" position, the sounder is "on" when the disable
connection is open. See Table 3 for operation modes.
Table 3: Enable/Disable Function Logic Table
Switch
Position 4
Setting
on
on
off
off
There are five different power settings for the sound output
pressure. Switch settings 1, 2, and 3 set the power setting
for the sounder. Switch 1 selects the 2 watt setting, switch 2
selects the 1 watt setting, switch 3 selects the
If all three switches are "off" this selects the 4 watt setting and
if all three switches are "on" this selects the
2
Sound Output
Refuge
DOWN Stairs
UP Stairs
no tones
Terminals 3 Sound
& 4 Output
open disabled
closed enabled
open enabled
closed disabled
1 / watt setting.
2
1 / watt setting.
4
