- Page 1 See3CAM_130 DFU Application User Manual Version 1.1 e-con Systems 6/1/2017...
- Page 2 Disclaimer e-con Systems reserves the right to edit/modify this document without any prior intimation of whatsoever. © Copyright e-con Systems. 2017. All rights reserved.
-
Page 3: Table Of Contents
Contents INTRODUCTION TO FIRMWARE INSTALLING THE SEE3CAM_DFU APPLICATION 1 - W ELCOME CREEN 2 - I NSTALLATION ELECTION 3 - R EADY TO NSTALL INDOW 4 - A TTACHING THE EVICE USING THE SEE3CAM_DFU APPLICATION 1 - D EVICE ELECTION 2 - F IRMWARE ELECTION... -
Page 4: Introduction To Firmware
See3CAM device. This document highlights the process of updating a new firmware in the See3CAM product. In future to add new functionalities to the See3CAM device, e-con Systems will release new firmware binary. You can update this firmware into the See3CAM device by using the See3CAM_DFU application. -
Page 5: Installing The See3Cam_Dfu Application
Step 2 - Installation Path Selection To select the installation path, you can either use the default installation path C:\Program Files\e-con Systems\See3Cam_DFU\ or can change to another installation path by clicking the Change button. After choosing the installation path, you can click the Next button as shown below. -
Page 6: Step 3 - Ready To Install Window
To begin the installation, you can click the Install button as shown below. Figure 3: Ready to Install Window Step 4 - Attaching the Device After the installation of See3CAM_DFU application, you can view the completion window as shown below. © Copyright e-con Systems. 2017. All rights reserved. - Page 7 Figure 4: Completion Window When you click the Finish button, you can exit the Setup Wizard and the See3CAM device will be attached to the PC. See3CAM_130 DFU Application User Manual...
-
Page 8: Using The See3Cam_Dfu Application
In this case, the device connected is See3CAM_130(VID_2560,PID_C0D0_0) as shown below. Figure 5: Device Selection If no devices are connected for update, No Device Connected label will be displayed as shown below. © Copyright e-con Systems. 2017. All rights reserved. -
Page 9: Step 2 - Firmware Selection
Figure 6: Drop-Down List Empty when no See3CAM_130 is Connected Step 2 - Firmware Selection Click the Browse button and select the firmware image as shown below. Figure 7: Firmware File Selection Window You can verify the product name and firmware version before proceeding. To view the firmware image, click the Open drop-down list as shown in above image. - Page 10 Figure 9: Switching to Firmware Update Mode and Erasing the Old Firmware The application reads the firmware file and updates it into the device. The progress of updating firmware is shown below. © Copyright e-con Systems. 2017. All rights reserved.
-
Page 11: Step 4 - Firmware Update Complete
Figure 10: Firmware Update in Progress Warning: Do not disturb the USB connection or unplug the camera when the firmware update is in process. Step 4 - Firmware Update Complete Once the progress bar reaches 100%, the device will automatically reset and gets detected with new firmware as shown below. - Page 12 Firmware Download Failed! message as shown below. Figure 13: Firmware Update Failure In this case, the device is connected as e-conDFU_USB_1_HUB_0(VID_2560, PID_DF00_0 as shown below. © Copyright e-con Systems. 2017. All rights reserved.
- Page 13 Figure 14: Device in e-con DFU Mode You can again follow the steps 1 to 4 to retry the firmware update process. See3CAM_130 DFU Application User Manual...
-
Page 14: Troubleshooting
USB connection. Do not disturb the USB connection or unplug the camera when the firmware update is in process. Please retry Step 1 - Device Selection to Step 4 - Firmware Update Complete for firmware update process. © Copyright e-con Systems. 2017. All rights reserved. -
Page 15: Faq
In this sample application, e-con Systems have separated the RGB and IR data. 5. I am using e-con Systems See3CAM in Matlab and I need support on how to acquire image from the tool. e-con Systems does not test See3CAMs in Matlab environment. If you need support in Matlab tool, then please write to techsupport@e-consystems.com... - Page 16 If you have purchased any of e-con Systems product then please write to techsupport@e-consystems.com with the Sales Order number or email id of the purchaser to get the source code. If you are new to e-con System, then please write to sales@e-consystems.com...
-
Page 17: What's Next
What’s Next? After understanding the usage of DFU application, you can refer to the following documents to understand more about See3CAM_130. • e-CAMView Streaming Application User Manual of See3CAM_130 • Firmware Release Notes of See3CAM_130 See3CAM_130 DFU Application User Manual... -
Page 18: Glossary
Glossary USB: Universal Serial Bus. © Copyright e-con Systems. 2017. All rights reserved. -
Page 19: Support
Support Contact Us If you need any support on See3CAM_130 product, please contact us using the Live Chat option available on our website - https://www.e-consystems.com/ Creating a Ticket If you need to create a ticket for any type of issue, please visit the ticketing page on our website - https://www.e-consystems.com/create-ticket.asp To know about our Return Material Authorization (RMA) policy, please visit the RMA... - Page 20 Revision History Date Description Author 29-May-2017 Initial Draft Camera Dev Team 01-June-2017 Added changes for other See3CAMs Camera Dev Team © Copyright e-con Systems. 2017. All rights reserved.
