See3CAM_130 Getting Started Manual 24-Oct-2016 e-con Systems India Pvt Ltd Floor, RR Tower – IV, Super A-16 & A-17, Thiru-Vi-Ka Industrial Estate, Guindy, Chennai - 600 032. www.e-consystems.com See3CAM_130 Getting Started Manual Revision 1.0 Monday, October 24, 2016 www.e-consystems.com | Subject to change without notice...
See3CAM_130 Getting Started Manual 24-Oct-2016 Contents Revision History............................. 3 Introduction............................. 4 Scope...............................4 Disclaimer............................... 4 Description.............................. 4 Setting up the See3CAM_130......................5 See3CAM_130 to PC Host Interconnecting Cable..............5 Connecting the board with Host....................6 6.2.1 Identification of USB3.1 GEN_1 Connector................6 6.2.2 Insertion of USB Cable in Connector...................6 6.2.3...
See3CAM_130 Getting Started Manual 24-Oct-2016 See3CAM_130 1 Revision History Date Description Author 24-Oct-2016 Initial Draft Camera Team www.e-consystems.com | Subject to change without notice Page 3 of 9...
4 Disclaimer The specifications of See3CAM_130 camera board and instructions on how to connect this board with PC are provided as reference only and e-con Systems reserves the right to edit/modify this document without any prior intimation of whatsoever. 5 Description The See3CAM_130 is a one board solution of size 80mm x 15mm.
2. USB3.1 GEN_1 Type A to Type C Cable 6.1 See3CAM_130 to PC Host Interconnecting Cable The USB 3.1 GEN_1 A to Type C cable is used to connect See3CAM_130 camera board to the PC will be supplied by e-con Systems. www.e-consystems.com | Subject to change without notice...
The location of USB Type C (CN2) connector on See3CAM_130 is shown in below figure Figure 3: Location of USB3.1 GEN_1 Connector 6.2.2 Insertion of USB Cable in Connector The USB3.1 GEN_1 Cable provided by e-con Systems should be inserted with USB Type C connector as shown in below figure. www.e-consystems.com...
See3CAM_130 Getting Started Manual 24-Oct-2016 Figure 4: USB cable inserted in USB3.1 GEN_1 Type C connector 6.2.3 Connecting the board to Host Identify a USB 3.1 GEN_1 port. The port which has the below logo is USB 3.1 GEN_1 Port. Figure 5: SuperSpeed USB 3.1 GEN_1 Logo The USB3.1 GEN_1 cable needs to be inserted to SuperSpeed USB3.1 GEN_1 port of PC or Laptop.
Page 8
See3CAM_130 Getting Started Manual 24-Oct-2016 Figure 7: Connecting USB3.1 GEN_1 Cable to Superspeed Port After the insertion of USB3.1 GEN_1 Cable with USB 3.1_GEN_1 / Type C connector on the board and USB Host, the LED (D1) will glow in Red colour. This indicates that the board is powered ON.
See3CAM_130 Getting Started Manual 24-Oct-2016 Figure 9: Status LED indicating Camera streaming 6.2.4 Ensuring the device connected to Host properly After the insertion of board to Host, you can confirm that See3CAM_130 is properly connected to Host from Imaging Devices. Go to Control Panel ...
