- Page 1 KR-S61A User Manual 1 12 SECURITURK www.securiturk.com www.elektronik-guvenlik.com Document Note: S20212K00021...
- Page 2 KR-S61A User Manual 2 12 KR-S61A is a lock for drawers and cabinets. Battery powered KR-S61A is powered by Mifare cards out of the box. It is a secret lock application as it stays in the drawer and cabinet. Usage In Private Use: When the user card is read into the lock, the lock is unlocked.
-
Page 3: Product View
KR-S61A User Manual 3 12 PRODUCT VIEW LOCK BODY LOCK HOOK CARDS (13.56MHz Mifare) DIMENSIONS SECURITURK www.securiturk.com www.elektronik-guvenlik.com Document Note: S20212K00021... - Page 4 KR-S61A User Manual 4 12 PARAMETER Material ABS for lock body shell, Acrylic & PC for panel Load current < 200mA Power consumption Locked-rotor current < 350mA Standby current < 20mA Statistic current < 50uA @3V 123A rechargeable lithium battery Working voltage Voltage: 2.1V~3.3V...
-
Page 5: Functions And Features
Users can use their own cards that are compatible with our lock, but function cards only can be Mifare 1 card. USE The KR-S61A can be used in 3 different modes. You have to decide for yourself the way of use that best suits your needs. 1. PUBLIC USE (Factory in this setting) 2. - Page 6 KR-S61A User Manual 6 12 PUBLIC USE Lock keeps unlocking under public mode, manager card should be programmed first(manager card can use for emergency unlock). Any card to lock and same card to unlock. SECURITURK www.securiturk.com www.elektronik-guvenlik.com Document Note: S20212K00021...
- Page 7 KR-S61A User Manual 7 12 Set lock into public mode The factory is in this setting, if you are going to use it in this mode, you do not need to make this setting. Pressing button “3” for 2 Lock will prompt with “di”...
-
Page 8: Private Mode
KR-S61A User Manual 8 12 Private Mode Lock keeps locking under private mode, manager card and user card should be programmed first(manager card only for programming user card). Push the door to close, and use the user card to unlock. - Page 9 KR-S61A User Manual 9 12 Set manager card Pressing Lock will keep Lock will Set manager Swipe an button “1” for flashing in prompt with card empty card 2 seconds green “di” successfully Notice: 1. While green light is flashing, user can set manager card continuously. One lock can have max 10pcs manager cards.
- Page 10 KR-S61A User Manual 10 12 Set lock into limited public mode Lock will prompt Set into limited Pressing button with “di di di” and public mode green light “3” for 2 seconds successfully flashes Set manager card Pressing Lock will keep...
- Page 11 KR-S61A User Manual 11 12 Notice: 1. While green light is flashing, user can set manager card continuously. One lock can have max 10pcs manager cards. 2. Manager card cannot be used for emergency unlock, just for setting user card.
- Page 12 KR-S61A User Manual 12 12 WARM TİPS 3. Light shines in blue means batteries are nearly run out, please change new batteries in time. 4. One lock can have max 10pcs manager cards, 10pcs delete cards and 30pcs user cards.
