CONTROLS

1a) Microphone 1 input
Allows you to connect a microphone with a 6,3mm connector
1b) Balanced microphone 1 input
Connector for a balanced microphone
1c) Microphone control
Is Used control to set the volume level of the microphone 1
(6,3mm or balanced)
2a) Microphone 1 input
Allows you to connect a microphone with a 6,3mm connector
2b) Balanced microphone 1 input
Connector for a balanced microphone
2c) Microphone control
Use this control to set the volume level of the microphone 1
(6,3mm or balanced)
3a) RCA Line-In
Allows you to connect an external audio device (CD, radio, DVD, etc.), with RCA connectors.
3b) Cannon Line-In
Allows you to connect an external audio device (CD, radio, DVD, etc.), with a Cannon
connector.
3c) Control
Use this control to set the volume level of the Line-In signal
4) Volume control
Set the volume level
5 Treble
Use it to set the treble level
6) Bass
Use it to set the bass level
7a) Signal output
Use this jack to connect another amplifier or even another powered speaker cabinet in
cascade, using a 6,3mm connector
7b) Signal output
Use this jack to connect other amplifier or even another powered speaker cabinet in cascade,
using a Cannon connector
8) AC 110/220 Voltage Selectable
9) AC power
to connect the AC power cord
4
