Summary of Contents for barbas Unilux-7 40

  • Page 1 Installation and maintenance manual Unilux-7 40 Serial number: Production date:...
  • Page 2 Barbas Bellfires BV. This document could contain technical inaccuracies or typographical errors. Barbas Bellfires BV reserves the right to revise this document from time to time in the contents thereof.
  • Page 3: Table Of Contents

    About this document................6 How to work with this document....................6 Warnings and cautions used in this document................6 Related documentation........................6 Description....................7 Overview of the Unilux-7 40......................7 Intended use..........................9 Installation examples........................9 Safety.....................11 Safety instructions for installation....................11 Safety instructions with regard to the environment..............
  • Page 4 Removal of the interior of the combustion chamber......30 Technical data..................34 Technical data..........................34 Dimensions ................... 36 10.1 Frameless appliance........................36 10.2 Appliance with built-in frame...................... 38 10.3 Appliance with classic frame......................40 10.4 Appliance with classic frame and 45º flue connector..............42 Warranty Terms..................44 Unilux-7 40...
  • Page 5: Declaration Of Performance

    Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5)
  • Page 6: About This Document

    Installation • Maintenance This document refers to the Unilux-7 40 as 'the appliance'. This document is an essential part of your appliance. Read it carefully before you do work on the appliance. Keep it in a safe place. The original instructions of the document are in English. All other language versions of the document are translations of the original instructions.
  • Page 7: Description

    Description Description Overview of the Unilux-7 40 The Unilux-7 40 is available with a screened glass door or with a steel frame door. Door handle Ash tray (under the grate) Glass Ceramic panels Primary air inlet - Top flue connector...
  • Page 8 Lower baffle (ceramic) Air wash inlet Connection for external combustion Upper baffle (steel) Figure 2. Bottom view of the Unilux-7 40 with screened door Connection for external combustion Rear flue connector Figure 3. Rear view of the Unilux-7 40 Unilux-7 40...
  • Page 9: Intended Use

    Installation examples Note: The illustrations shown in this paragraph are typical installation examples. Combustion air inlet Convection air outlet Convection air inlet Air supply to the room Chimney Figure 4. Installation in an existing fireplace Unilux-7 40...
  • Page 10 Description External combustion air inlet Air supply to the room Convection air inlet Ventilation air inlet Chimney Convection/ventilation air outlet Convection air outlet Figure 5. Installation with external combustion air supply in a new fireplace surround Unilux-7 40...
  • Page 11: Safety

    Dispose of ceramic heat-resistant glass as household waste. Do not dispose of ceramic heat-resistant glass in a glass recycling container. • Dispose of an obsolete appliance according to instructions of the authorities or the fitter. • Obey the local regulations. Unilux-7 40...
  • Page 12: Clearances

    Attention: Make sure there is a 3 mm clearance between the appliance and the surrounding construction, to allow for expansion of the appliance during use. Unilux-7 40...
  • Page 13 Table 3: dimensions and minimum clearances to a flammable wall Description Insulation plate 25 mm Air gap 25 mm Thickness plate 100 mm Air gap / Spacer 25 mm A+B+C 150 mm 125 mm Minimum 3 mm clearance between appliance and surrounding construction Unilux-7 40...
  • Page 14: Clearance To Flammable Floor (Under The Appliance)

    Make sure the total area of the convection air outlet opening is minimum 300 cm Chimney enclosure Insulation plate (false ceiling) Convection air outlet opening Insulation plates Flammable ceiling Figure 7. Clearances to flammable ceiling - Front view Unilux-7 40...
  • Page 15: Clearances To Non-Flammable Walls

    Attention: Make sure there is a 3 mm clearance between the appliance and the surrounding construction, to allow for expansion of the appliance during use. Unilux-7 40...
  • Page 16 Table 5: Minimum dimensions between appliance and non-flammable walls Insulation plate 25 mm Air gap 20 mm Thickness plate 25 mm Air gap / Spacer 20 mm A+B+C 65 mm 45 mm Minimum 3 mm clearance between appliance and surrounding construction Unilux-7 40...
  • Page 17: Clearances To A Non-Flammable Ceiling

    Make sure the total area of the convection air outlet opening is minimum 300 cm Chimney enclosure Insulation plate (false ceiling) Convection air outlet opening Insulation plates Non-Flammable ceiling Figure 9. Clearances to non-flammable ceiling - Front view Unilux-7 40...
  • Page 18: Clearances In Front Of The Appliance

    Minimum 50 cm between ceiling and chim- ceiling ney enclosure Clearances in front of the appliance Do not put flammable items within minimum 180 cm radius from the appliance. Non-flammable floor plate Appliance Unilux-7 40...
  • Page 19 Example to find the correct minimum depth of a non-flammable floor plate If the measured distance between the bottom of the visible part of the appliance is 20 cm, according to the graph the minimum depth of the floor plate is 47 cm. Unilux-7 40...
  • Page 20: Installation

    Make sure the total ventilation air inlet openings have a minimum area of 450 cm . (2 inlet openings of minimum 225 • Make sure the total ventilation air outlet openings have a minimum area of 450 cm . (2 outlet openings of minimum 225 cm Unilux-7 40...
  • Page 21: Requirements On The Chimney

    Make sure the inner walls of the open fireplace are not damaged. Put a layer of ceramic wool against the inner walls of the fireplace opening. Refer to chapter for specifications. Put an appropriate chimney adapter on the existing chimney. Unilux-7 40...
  • Page 22 Ceramic insulation Existing open fireplace Combustion air inlet Flue gas pipe Chimney adapter Figure 11. Chimney adapter Put a layer of ceramic wool around the flexible flue pipe. Remove the interior of the appliance. Refer to chapter for instructions. Unilux-7 40...
  • Page 23: Install The Appliance

    Put a layer of ceramic wool on the top of the appliance. Refer to chapter specifications of the ceramic wool. Put all the interior parts in the correct position in the appliance. Refer to chapter instructions. Unilux-7 40...
  • Page 24: Final Check On The Appliance

    The external air supply connection is only available when ordered with the appliance. • It is strongly recommended to install a valve in the external combustion air supply pipe, to avoid debris in the pipe and to avoid water vapor condensation in the appliance when not in use. Unilux-7 40...
  • Page 25: Connect The Optional External Air Supply (Bottom Connection)

    The external air supply connection is only available when ordered with the appliance. • It is strongly recommended to install a valve in the external combustion air supply pipe, to avoid debris in the pipe and to avoid water vapor condensation in the appliance when not in use. Unilux-7 40...
  • Page 26: Connect The Flue Gas Pipe

    Make sure that all mechanical connections of the flue system are correctly used. Make sure that all of the flue system is gas-tight, Insulate any non-insulated pipes with ceramic insulation wool. Refer to for the material requirements. Unilux-7 40...
  • Page 27: Insulate The Appliance

    Build the fireplace around the appliance. Install the fitting boxes of the ventilation air outlets. If applicable, install the fitting boxes of the convection air outlets If applicable, install the decorative frame on the appliance. Unilux-7 40...
  • Page 28: Final Check On The Appliance

    Make sure the door closes and opens easy. Make sure the control lever moves easy to left and right without undue noise. Make sure all ceramic plates and the baffles are in the correct position. Contact your dealer if the final check shows a defect. Unilux-7 40...
  • Page 29: Maintenance

    Clean the inside of the appliance with a soft brush. Clean the metal parts on the outside of the appliance with a dry lint free cloth. Use Barbas heat resistant paint spray to repair lacquer damage. Combustion air supply Make sure that the inlet of the pipe of the external combustion air supply is not blocked by leaves or other debris.
  • Page 30: Removal Of The Interior Of The Combustion Chamber

    (refer to step 5 of this instruction). Remove the door Open the door completely. Remove the bottom Lift the grate and remove from the combustion chamber. Lift the left and right steel bottom plate and remove from the combustion chamber. Unilux-7 40...
  • Page 31 Make sure the nut stays attached to the socket screw. Push up the front of the heat shield (1) and pull it forward (2) and move downward to a vertical position (3). Remove the upper baffle from the appliance. Unilux-7 40...
  • Page 32 Move the left side panel a little upward and inwards (1) and remove it from the appliance (2). Move the right side panel a little upward and inwards (3) and remove it from the appliance (4). Remove the log guards Lift the front log guard and remove from the combustion chamber. Unilux-7 40...
  • Page 33 Remove the ceramic back panel. Move the bottom of the ceramic back panel forward and remove it from the appliance. Note: To put the parts of the combustion chamber interior back, do the above instructions in opposite order. Unilux-7 40...
  • Page 34: Technical Data

    Technical data Technical data Technical data Name Barbas Model Unilux-7 40 Tested in accordance with EN 13229:2001-A2:2004 EN16510-1 annex D, E, F Energy efficiency index Energy efficiency class Fuel Wood logs, Wood briquettes Nominal fuel load 1.3 kg Nominal heat output (net)
  • Page 35 Front glass • Heat resistant ceramic glass The specific precautions that shall be taken • Installation and maintenance manual when the local space heater is assembled, in- • User manual stalled or maintained, are listed in the attached documents: Unilux-7 40...
  • Page 36: Dimensions

    Dimensions Dimensions 10.1 Frameless appliance Figure 13. Dimensions of frameless appliance with screened glass door Unilux-7 40...
  • Page 37 Dimensions Figure 14. Dimensions of frameless appliance with steel frame door Unilux-7 40...
  • Page 38: Appliance With Built-In Frame

    Dimensions 10.2 Appliance with built-in frame Figure 15. Dimensions of appliance with built-in frame and screened glass door Unilux-7 40...
  • Page 39 Dimensions Figure 16. Dimensions of appliance with built-in frame and metal frame door Unilux-7 40...
  • Page 40: Appliance With Classic Frame

    Dimensions 10.3 Appliance with classic frame Figure 17. Dimensions of appliance with classic frame and screened glass door Unilux-7 40...
  • Page 41 Dimensions Figure 18. Dimensions of appliance with classic frame and metal frame door Unilux-7 40...
  • Page 42: Appliance With Classic Frame And 45º Flue Connector

    Dimensions 10.4 Appliance with classic frame and 45º flue connector Figure 19. Dimensions of appliance with classic frame, 45º flue connector and screened glass door Unilux-7 40...
  • Page 43 Dimensions Figure 20. Dimensions of appliance with classic frame, 45º flue connector and metal frame door Unilux-7 40...
  • Page 44: Warranty Terms

    Complaints will only be accepted if they are reported to the Barbas dealer, together with the serial number of the Barbas appliance which is stated on the front of the manual. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted.
  • Page 45 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Barbas appliance, a similar warranty applies from the moment of purchase for a period of two years.
  • Page 46 Warranty Terms Unilux-7 40...
  • Page 47 Warranty Terms Unilux-7 40...
  • Page 48 Your Barbas dealer 001 - 25.03.2021 - 351078...
