Manuale di installazione
Installation manual
Installationsanleitung
Manuel d'installation
Manual de instalación
FORCE 825/I
I
Dissuasore di sosta e passaggio
GB
Parking and passage rising bollard
D
Poller gegen unrechtmäßiges Parken und Durchfahren
F
Borne escamotable anti-stationnement et anti-accès
Disuasor de tránsito de aparcamiento y de paso
E
Made in Italy
Brevettato
Patented
Advertisement
Related Manuals for Rise FORCE 825/I
Summary of Contents for Rise FORCE 825/I
- Page 1 FORCE 825/I Made in Italy Manuale di installazione Dissuasore di sosta e passaggio Installation manual Brevettato Parking and passage rising bollard Patented Installationsanleitung Poller gegen unrechtmäßiges Parken und Durchfahren Manuel d'installation Borne escamotable anti-stationnement et anti-accès Manual de instalación Disuasor de tránsito de aparcamiento y de paso...
- Page 2 Declaration of conformity The undersigned Mr. Luigi Benincà, legal representative of the company Rise S.r.l. - Via del Capitello, 42 - 36035 Marano Vicentino (VI) – in the capacity of manufacturer declares that the product: FORCE 825/I complies in all its components with Directives:...
-
Page 3: Technical Data
We thank you for having chosen one of our FORCE model automatic rising bollards. All articles in the Rise range are the fruit of long experience in the sector of mechanical and electronic automations. This is why today we are able to offer extremely innovative and reliable automatic rising bollards that, thanks to their per- formance, ef ciency and durability, fully satisfy the nal customer’s requirements. - Page 4 Assembly instructions - FORCE 825/I 1 - Place the 4 side elements vertically as in the image alongside. 2 - Using the round head screws provided, assemble the hexagonal structure. It is very important to assemble the 4 elements vertically and on a surface that ensures excellent atness so as to obtain a reliable support surface for the closing ange.
- Page 5 Assembly instructions - FORCE 825/I 4 - Fix the upper ange using the round head screws provided. Attention: The screw heads must be placed on the upper part of the flange (inside the case). This way the foundation case is complete. See gure alongside.
- Page 6 Assembly instructions - FORCE 825/I 7 - Dopo aver posizionato la cassa, assicurarsi di coprire il vano aperto, per tutto il tempo in cui il dissuasore non è inserito, con adeguata chiu- sura atta ad impedire incidenti che possano coinvolgere persone o cose.
- Page 7 Assembly instructions - FORCE 825/I 11 - The cable must be recovered while the bollard comes near the foun- dation case (ref A). Important: In this phase the connector must be free to slide inside of the corrugated sheath. For this reason is it necessary for the segment be-...
- Page 8 Assembly instructions - FORCE 825/I 13 - After positioning the bollard inside the case, remove the lifting eye¬bolts and, using the same holes, position the blocks on the pipe guide ring. The blocks are necessary in order to lift the bollard without the treadable M10x40 TCEI ange.
- Page 9 Spare parts list - FORCE 825/I FORCE 825I FORCE 825 Description Cod. Retro re ector sticker R9686019 Retro re ector sticker (825I) R9686039 Cylinder cover R9686020 Control unit R9686003 24Vdc motor with encoder and electronic brake R9686029 Treadable ange R9686021...
