Do not remove the fan tray for more than 30 minutes, otherwise a

tamper event will occur.
For more information about replacing either a PSU or the fan tray module, see the
Installation Sheet that accompanies the replacement part or the Physical Security
chapter of the Connect User Guide.
Breaking the security seal or dismantling the nShield Connect voids

your warranty cover, and any existing maintenance and support
agreements.
Mains power plugs on UK cordsets contain a 5A fuse (BS1362). Only
replace with the same type and rating of fuse. If a replacement fuse

fails immediately, contact Support. Do not replace with a higher value
fuse.
If the product has to be moved for maintenance then all movement should occur in
accordance with the
before or after maintenance, then, it should be stored in accordance with the guidance
outlined in Environment.

10.4. Solo XC fan and battery maintenance

The fan and battery can be replaced should either malfunction or the battery has
reached the end of its useful life. Replacing the battery and/or fan whilst the card is
powered down will not cause a tamper of any sort. See
tamper events. The replacement procedure is described in the Solo Installation User
Guide.
If the product has to be moved for maintenance then all movement should occur in
accordance with the
before or after maintenance, then, it should be stored in accordance with the guidance
outlined in Environment.

10.5. Maintenance mode

Firmware upgrades of the module are only allowed when the module is in maintenance
mode. Refer to the Installation and User Guides for more information on setting the
module into maintenance mode.
nShield® Security Manual
HSM and Card Reader
HSM and Card Reader
Location. Similarly, if the Connect is stored
Physical Security
Location. Similarly, if the Solo XC is stored
for guidance on
68 of 90
