Summary of Contents for Plantronics Savi Office WO200
Page 1
Savi Office WO200 ™ Wireless Headset System with Optional HL10 Lifter ™ User Guide...
Page 2
Welcome Congratulations on purchasing your new Plantronics product. This guide contains instructions for setting up and using your Savi Office WO200 (WO1 Base and WH200/WH210 Headset) Wireless Headset System. Please refer to the separate safety instructions for important product safety information prior to installation or use of the product.
6.1 Installing USB Cable ... 12 6.2 Installing PerSono Suite Software 6.3 Making a Test Call with PC ... 12 Plantronics Savi User Guide 7 Using Your Savi Office Professional Wireless Headset System ... Powering up Headset Placing, Answering and Ending Calls with Desk Phone Placing, Answering and Ending Calls with PC ...
Slide the headset over and behind your ear, then press gently toward your ear. Rotate the microphone boom until it is pointed toward your mouth. Plantronics Savi User Guide the headset can be converted for wearing on left ear as follows: a. Rotate the microphone boom up.
[+] to increase the volume and the volume down button [-] to decrease the volume. Plantronics Savi User Guide If the dial tone still does not sound clear, adjust the Configuration Switch until the dial tone sounds the best.
If you hear a dial tone the lifter is set correctly and needs no adjustment. Remove the protective strips from the 3 mounting tapes on the underside of the lifter. Plantronics Savi User Guide Gently place the lifter on the desk phone in the pre- determined position. Press firmly to adhere.
Slide extender arm onto lifter. Stabilizers can be shifted left and right. Position stabilizers on outsides of handset to gently grip the phone. Plantronics Savi User Guide Ringer Microphone Stabilizers Use ringer microphone when the telephone speaker is not located directly under the handset.
Click on the graphic of the CD labeled “PerSono Suite Software”. Follow installation instructions shown on screen. Plantronics Savi User Guide 6.3 Making a test Call with PC ensure the PerSono Suite software is running on your PC. You will see a headset icon in the lower right portion of the PC tray bar when PerSono Suite software is running.
** To place, answer, and end calls with desk phones that have a headset button and without a handset lifter, you will need to press the headset button on the desk phone instead of removing the handset from the cradle. Plantronics Savi User Guide Call Control Button...
* Desk phone and PC audio links have to be brought up by the headset or base. You cannot initiate an audio link via the Audio Control Screen in the PerSono Suite software. Plantronics Savi User Guide Without PerSono Suite Software 1. Short press call control button on headset** or short press base PC talk button 2.
The subscription light will turn solid red for four seconds and then go to it’s previous state. Plantronics Savi User Guide Placing the Headset in Sleep Mode If you won’t be using the headset for a long duration and the...
The Savi WO200 Office system will provide up to 6 hours of talk time. Talk time will be reduced when operating in wideband mode and/or if the headset is used consistently at a far distance from the base.
Clicking a blinking red PC or desk phone icon will turn it back to green, indicating the device is active again. Plantronics Savi User Guide examples All devices idle...
Page 19
PC talk button on the base. PC Talk Button Plantronics Savi User Guide Launch your media player on your PC and start playing multimedia. Click on the red desk phone icon to bring the desk phone off hold and your multimedia will now be mixed with your desk phone audio.
“Manage API Access Control” screen will pop up stating that “Another program is trying to access Skype”. the name of the program will appear as “PerSonoSuite.exe” with the publisher “Plantronics, Inc.” You must select “Allow this program to use Skype” and click OK.
Over-the-air subscription allows a headset to be subscribed to the base without physically docking the Subscription headset. Required when conferencing various models of Plantronics Savi headsets. When over-the-air subscription is set to ON you can subscribe a headset to your base without physically docking the headset into the charge cradle.
Page 23
PC audio has been set up. When this parameter is set to ON, the PC ringtone will be heard on both the PC speaker as well as the headset. Plantronics Savi User Guide Default Settings...
Windows. • See a list of supported softphones running on your PC. • See which Plantronics device is attached to your PC and working with PerSono Suite software. • Customize how you want the PerSono Suite software to manage your multimedia when a call begins/ends.
Updates All the required software and firmware for your Plantronics device can be remotely updated if and when updates are available. You can control how frequently the system will check for available updates.
Base power supply is plugged into a power strip. Plug the power supply into the wall directly. Talk time performance is Battery is wearing out. Call Plantronics at (800) 544-4660 for factory service information or contact significantly degraded even us at www.plantronics.com/support.
Page 27
No audio connection to PC. Unplug USB and power cables from base. Reconnect power cable first. Wait for power LED to illuminate, then re-connect USB cable. Quit and then re-start your PC audio or softphone application. Plantronics Savi User Guide...
