Multiplex RX-5 slim M-LINK Operating Instructions

These operating instructions are an integral part
!
of the product, and contain important information
and safety notes. Please store them in a safe place,
where you can find them at any time, and pass
them on to the new owner if you sell the receiver.
1. S
PECIFICATION
Order No.
Reception system
Servo channel count
Servo signal
frame rate
Signal resolution
Current drain
Aerial length
Operating voltage
Operating
temperature range
Weight
Dimensions
2. S F
PECIAL EATURES

Small, all-purpose 5-channel receiver exploiting 2.4 GHz
M-LINK technology, ideal for indoor models.

HOLD / FAIL-SAFE function.

Integral SET button and LED:
For binding, FAIL-SAFE programming, RESET and
operating status information.
3. S N
AFETY OTES
!
Please read the instructions before using the receiver.
!
Use the receiver only for the intended applications
( 4.).
!
Ensure the power supply is of adequate capacity ( 5.).
!
Observe the installation notes ( 8.).
!
Carry out regular range checks ( 9.).
4. A
PPLICATION
The RX-5 slim M-LINK is a radio control receiver intended
exclusively for use in model sport applications. It is prohibited to
use it for other applications, such as man-carrying vehicles or
industrial installations.
The RX-5 slim M-LINK was designed with minimum possible
size and weight as top priority, and for technical reasons such a
unit cannot offer the same reception characteristics as a larger,
technically more sophisticated and more expensive receiver. In
the interests of safety we recommend that you use a larger
receiver wherever space permits. Under normal conditions it is
certainly possible to obtain excellent reception characteristics
with a small receiver such as the RX-5 slim M-LINK provided
that all the RC system components are carefully arranged, and
the receiver aerial correctly deployed.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten (Gölshausen) • www.multiplex-rc.de
Operating Instructions
RX-5 slim M-LINK 2.4 GHz receiver
RX-5 slim M-LINK
# 1-01190
2.4 GHz AFHSS M-LINK
5
Fast response: 14 ms
Standard: 21 ms
(according to transmitter)
12-bit, 3872 steps
(according to transmitter)
approx. 30 mA (excl. servos)
40 mm
3.5 V ... 9.0 V
 2S LiPo / LiIo
- 20 °C ... + 55 °C
4.3 g
approx. 34.0 x 17.5 x 7.5 mm
The RX-5 slim M-LINK 2.4 GHz receiver can only be used in
conjunction with transmitters which use MULTIPLEX M-LINK
transmission technology.
5. P S
OWER UPPLY
The RX-5 slim M-LINK receiver works with a wide range of
voltages from 3.5 V ... 9.0 V, i.e. with receiver batteries con-
sisting of 4 to 6 NiXX cells or 2S LiPo / 2S LiIo batteries.
! Note: ensure that the power supply is adequate
A power supply system in good condition and of adequate
capacity for the specific application plays an indispensable role
in the safe operation of any model:

Use only high-quality receiver batteries of adequate capacity.
Balance and maintain them carefully, and charge them fully.

Ensure that all cables are of adequate conductor cross-
section. Keep all wiring as short as possible, and use the
absolute minimum of plug / socket connections.

Use high-quality switch harnesses exclusively.

Brief collapses in the power supply voltage (lasting a few
milli-seconds) have no adverse effect on the receiver. Longer
voltage collapses to below 3.5 V may cause a receiver reset,
resulting in a brief interruption in reception. This may be due
to a receiver battery which is almost flat, too weak or
defective, cables of inadequate cross-section, poor-quality
connectors or an overloaded or defective BEC system.
6. R C
ECEIVER ONNECTIONS
This receiver employs the UNI connector system, which is com-
patible with the connector systems used by most radio control
manufacturers.
The receiver sockets are marked as follows:
! When connecting the receiver battery, servos, speed
controllers ... it is essential to ensure that the
connectors are plugged in correctly, and feature
compatible. Pin assignments: !
