Multiplex RX-5 M-LINK Operating Instructions Manual

These operating instructions are an integral part
!
of the product, and contain important information
and safety notes. Please store them in a safe place,
where you can find them at any time, and pass
them on to the new owner if you sell the receiver.
1. S
PECIFICATION
Order No.
Reception system
Servo channel count
Servo frame rate
Signal resolution
Current drain
Aerial length
of which feed cable approx. 17 cm and
Operating voltage
Operating
temperature range
Weight
Dimensions
2. S F
PECIAL EATURES

High-quality 5-channel / 7-channel receivers assembled
using the latest SMT methods, exploiting MULTIPLEX
2.4 GHz M-LINK technology.

Supplementary signal pre-amplification:
For maximum sensitivity and great range.

In-line connectors arranged on the front and back:
Ultra-compact dimensions: suitable for models with very little
internal space.

HOLD / FAIL-SAFE function.

Integral SET button and LED:
For binding, FAIL-SAFE programming, RESET and
displaying operating status information.

Telemetry / feedback channel capability:
Receiver battery voltage and connection quality
= standard features.
Integral sensor interface for connecting external sensor
modules via MSB (MULTIPLEX Sensor Bus).

Prepared for two-receiver operation:
Diversity lead (# 8 5070) required.

Prepared for serial servo output:
Servo outputs as sum signal – SRXL-MULTIPLEX.
The receiver's first twelve channels are carried by a three-
cord lead (# 8 5070) via the receiver's B/D socket, e.g. for
power supply / servo management systems, or for flybarless
systems in model helicopters.

Prepared for selecting one sensor address as "priority
address":
The selected sensor value is updated at a faster rate than all
the other sensor values.
Operating Instructions for RX-5 M-LINK /
RX-7 M-LINK 2.4 GHz receivers
RX-5 M-LINK RX-7 M-LINK
# 5 5817 # 5 5818
2.4 GHz FHSS M-LINK
Frequency Hopping Spread Spectrum
MULTIPLEX-LINK
5
Fast Response: 14 ms
Standard: 21 ms
12-bit, 3872 steps
Approx. 45 mA (excl. servos)
Total: approx. 20 cm,
active aerial section approx. 3 cm
3.5 V ... 9.0 V
 4 - 6 NiCd / NiMH (NiXX) cells
 2S LiPo / LiIo (LiXX)
- 20 °C ... + 55 °C
13 g
Approx. 54.0 x 22.5 x 11.5 mm

Integral error counter / data logger:
For voltage and signal errors.

Compatible with the MULTImate (# 8 2094).

Integral PC interface:
Carry out updates and adjustment using the MULTIPLEX
Launcher PC program in conjunction with the UNI USB PC
lead (# 8 5149).
3. S
AFETY
!
Please read the instructions before using the receiver.
!
Use the receiver only for the intended applications
( 4.).
!
Ensure the power supply is of adequate capacity ( 6.).
7
!
Observe the installation notes ( 13.).
!
Carry out regular range checks ( 14.).
4. A
PPLICATIONS
The RX-5 M-LINK and RX-7 M-LINK 2.4 GHz receivers (abbre-
viated to RX-5/7 M-LINK in this document) are radio control
receivers intended exclusively for use in model sport. It is
prohibited to employ them for other purposes such as full-size
(people-carrying) vehicles or industrial installations.
Typical applications for RX-5 M-LINK and RX-7 M-LINK re-
ceivers:

Gliders and electric gliders up to about 2.50 m wingspan

Small to medium-sized RC helicopters with rotor diameters
up to about 1 m

Model aircraft with electric and I.C. power systems and
wingspans up to about 1.60 m

RC model cars

RC model boats

RX-5/7 M-LINK 2.4 GHz receivers can only be operated in
conjunction with transmitters which utilise MULTIPLEX M-
LINK transmission technology.
5. P
OWER
RX-5/7-DR M-LINK receivers work within a broad range of vol-
tages from 3.5 V ... 9.0 V, i.e. they can be used with receiver
batteries consisting of four to six NiXX cells or 2S LiPo / 2S LiIo
(LiXX).
!
Note: if you intend to use a five-cell or six-cell NiXX battery,
or a 2S LiPo or 2S LiIo pack, it is essential to check that all the
servos, gyros and other components connected to the system
are approved for use with this higher operating voltage.
! Note: ensure that the power supply is adequate
A power supply system in good condition and of adequate capa-
city for the specific application plays an indispensable role in the
safe operation of any model:

Use only high-quality receiver batteries of adequate capacity.
Balance and maintain them carefully, and charge them fully.

Ensure that all cables are of adequate conductor cross-
section. Keep all wiring as short as possible, and use the
absolute minimum of plug / socket connections.

Use high-quality switch harnesses exclusively.

Brief collapses in the power supply voltage (lasting a few
milli-seconds) have no adverse effect on the receiver. Longer
voltage collapses to below 3.5 V may cause a receiver reset,
resulting in a brief interruption in reception. This may be due
to a receiver battery which is almost flat, too weak or
