V I L A M O N T E
FREESTANDING TUB FAUCET
GRIFO PARA TINA SIN EMPOTRAR VILAMONTE
SKU: 948665
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, tub, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the faucet for shipping damage.
If any damage is found, contact our Customer
Relations team at 1-800-221-3379.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados al grifo, plomería,
bañera, pared, ni por daños personales que ocurran
durante la instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Retire el grifo del empaque y verifique que no se hayan
producido daños durante el envío. Si encuentra algún
daño, comuníquese con nuestro equipo de Servicio al
cliente al 1-800-221-3379.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
TOOLS AND MATERIALS:
HERRAMIENTAS Y MATERIALES:
Safety Glasses
Adjustable Wrench
Gafas de seguridad
H6 Hex Wrench
H6 Llave hexagonal
1
Hacksaw
Llave Ajustable
Sierra para
metales
REVISED 10/4/2019
CODES: SHVLFS2000G
1.800.221.3379
