Lippert Insight Back-up
Camera LCD Display Kit
Installation and Owner's Manual
(For Aftermarket Applications)
Lippert Insight
Back-up Camera
LCD Display Kit
Installation and
Owner's Manual
(For Aftermarket Applications)
Lippert Insight Camera LCD 7" Display Kit
Kit #
Kit #
Description
Description
2020112848
Insight LCD 7" Display
2
2
2
2
3
4
5
6
7
1
CCD-0004028
Rev: 04.28.22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Insight 2020112848 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lippert Insight 2020112848

Summary of Contents for Lippert Insight 2020112848

  • Page 1: Table Of Contents

    Installation and Owner’s Manual (For Aftermarket Applications) Lippert Insight Back-up Camera LCD Display Kit Installation and Owner’s Manual (For Aftermarket Applications) Lippert Insight Camera LCD 7” Display Kit Kit # Kit # Description Description 2020112848 Insight LCD 7” Display Table of Contents Introduction .

  • Page 2: Introduction

    (For Aftermarket Applications) Introduction Parts List The Lippert Insight Back-up Camera LCD Display Kit is a 7” camera display, mounting arm and USB power cord that streams wireless video from your Lippert back-up camera. Additional information about this product can be obtained from lci1.com/support...

  • Page 3: Installation

    (For Aftermarket Applications) Installation 5. Once mounting arm is secure in desired area, attach the 1. Remove the Lippert Insight Back-up Camera LCD 7” display screen to the mounting arm by sliding the slots Display Kit from the packaging. located on the back of the display over the tabs on the 2.

  • Page 4: Operation

    Lippert Insight Back-up Camera LCD Display Kit Installation and Owner’s Manual (For Aftermarket Applications) Operation 5. Exit vehicle and proceed to camera location on the back 1. Turn on tow vehicle marker/running lights to ensure that of the unit (Fig.10A).

  • Page 5: Screen Menu

    Lippert Insight Back-up Camera LCD Display Kit Installation and Owner’s Manual (For Aftermarket Applications) Screen Menu Settings: Allows setting of the display to go to sleep after selected System Info: Shows current amount of time. Gives option to view camera paired, current software wireless strength and image latency.

  • Page 6: Troubleshooting

    Cycle power to unit. disconnection and reconnection of shore power and the 7-way connector, or by turning the running/marker lights on and off. If further assistance is required, please contact the Lippert Customer Care Center at 432-LIPPERT (432-547-7378). lippert.com 432-LIPPERT (432-547-7378) CCD-0004028 Rev: 04.28.22...

  • Page 7: Notes

    Lippert Insight Back-up Camera LCD Display Kit Installation and Owner’s Manual (For Aftermarket Applications) Notes Notes lippert.com 432-LIPPERT (432-547-7378) CCD-0004028 Rev: 04.28.22...
  • Page 8 (For Aftermarket Applications) Notes Manual information may be distributed as a complete document only, unless Lippert Components provides explicit consent to distribute individual parts. All manual information is subject to change without notice. Revised editions will be available for free download at lippert.com.
