- Page 1 User Manual User Manual 2 & 3 Bowl Juice Dispenser Models: RDM-32 , RDM-33 02/2022 Please read and keep these instructions. Indoor use only WWW.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual Index General information ..........3 Parts overview and technical data ....... 4 Operating instructions ........5 - 6 Cleaning and maintenance ......7 - 8 Wiring diagram ........... 9 Trouble shooting ..........10 WWW.AvantcoEquipment.com... -
Page 3: General Information
User Manual Important Safeguards 1. When using electrical appliances, basic safety precautions should always be followed including the following: 2. Read all instructions 3. Close supervision is necessary when any appliance is used by or near children. 4. Make sure the appliance is OFF when not in use, before putting on or taking off parts, and before cleaning. -
Page 4: Parts Overview And Technical Data
User Manual Parts Overview Model Voltage (V) Dimension Capacity Power (W) (Hz) (Inch) RDM-32 2 x 3 Gal 120/60 17x18x25 R134a Technical data RDM-33 2 x 3 Gal 24x18x25 R134a 120/60 Cover Stainless steel valve Tap gasket Tank Tap lever... -
Page 5: Operating Instructions
User Manual Operating Instructions Positioning 1. Do not install the appliance in the area where a water jet could be used. 2. Place machine on a horizontal and sturdy surface. 3. Please install the appliance in locations where it can be overseen by trained personnel. - Page 6 User Manual Operating Instructions How To Use: Before using, the tanks and taps of the appliance should be cleaned carefully Filling To ensure correct usage of the machine ensure that the liquid level of the tank does not go below 3-4 Qt (please use the level lines on the tank for reference).
-
Page 7: Cleaning And Maintenance
User Manual Beverage Temperature Adjustment (FIG.5) 4. The motor and stirrer for each bowl can be operated independently using the relevant switch on the right hand side of the unit. 5. To switch off the cooling to a selected bowl, press the relevant bowl number on the control panel for 3 seconds. - Page 8 User Manual Cleaning and Maintenance Disassembling and Assembling the tanks: Fig. 6 To disassemble and assemble the tanks or to change the rubber tank gaskets : 1. Disconnect the unit by removing the plug. 2. Remove the cover from the tank. 3.
-
Page 9: Wiring Diagram
User Manual Wiring diagram 3 BOWL JUICER LEGEND LEGEND DESCRIPTION DESCRIPTION POWER SWITCH POWER SWITCH NTC1 SH2 / SH3 / SH4 MOTOR SWITCH SH2 / SH3 / SH4 MOTOR SWITCH NTC2 NTC3 M3 / M4 / M5 M3 / M4 / M5 PUMP MOTOR PUMP MOTOR TEMPERA... -
Page 10: Troubleshooting
User M an ual Troubleshooting Trouble Possible causes Solution Symptom Possible reasons Solution Remark Plug is not in. Insert plug into mains socket Main switch is not on the “I” Switch main switch to “I” position. No power to position.
