- Page 1 User Manual User Manual 1 Bowl Juice Dispenser Gear Driven 30 Qt. Comm ercial Mixer Model: RDM-31 Shifting gears while this unit is Model: MX30 running will void warranty. 02/2022 07/2014 Please read an d keep thes e instructions. Indoo r use only.
-
Page 2: Table Of Contents
User Manual User Manual TABLE OF CONTENTS GENERAL INFORMATION ....1 PARTS OVERVIEW & TECHNICAL DATA ..3 OPERATING INSTRUCTIONS . - Page 3 User Manual User Manual IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: Read all instructions Close supervision is necessary when any appliance is used by or near children. Make sure the appliance is OFF when not in use, before putting on of taking off parts, and before cleaning.
-
Page 4: Parts Overview & Technical Data
User Manual PARTS OVERVIEW & TECHNICAL DATA Model Voltage (V) Dimension Cover Capacity Power (W) (Hz) (Inch) Stainless steel valve RDM-31 1 x 3 Gal 7x18x25 R134a 120/60 Tap gasket Tank Tap lever Footstock Motor mounting plate Motor Control panel sticker... -
Page 5: Operating Instructions
User Manual User Manual OPERATING INSTRUCTIONS Positioning Do not install the appliance in the area where a water jet could be used. Place machine on a horizontal and sturdy surface. Please install the appliance in locations where it can be overseen by trained personnel. - Page 6 User Manual User Manual OPERATING INSTRUCTIONS Observe The appliance is suitable for an ambient temperature rangeing between 16˚C–32˚C. Cleaning For health standard and good quality of beverages, clean tanks, lids, and the mixing paddles / pumps as often as possible. Caution: Do not clean the appliance by water jet.
-
Page 7: Cleaning & Maintenance
User Manual User Manual CLEANING & MAINTENANCE Disassembling and Assembling the tank: To disassemble and assemble the tanks or to change the rubber tank gaskets. Disconnect the unit by removing the plug. Remove the cover from the tank. Remove the mixing paddle from its shaft. For the pump disassembling follow the instructions reported on the diagram (FIG.6) Lift container with both hands by a light,... -
Page 8: Wiring Diagram
User Manual User Manual WIRING DIAGRAM Item Description Main Switch 120V 60H Mixer / Pump motor Switch Thermostat Compressor Relay Electric Motor Thermal Protector Item Description Compressor Condenser Filter Boiler Evaporator Distributor Capillary coils High Pressure Side Liquid Line Gear Driven 30 Qt. Comm ercial Mixer Low Pressure Side Thermostat... -
Page 9: Troubleshooting
User Manual User Manual TROUBLESHOOTING PROBLEM CAUSE SOLUTION Plug is not in Insert plug into main socket Main switch is not on the “I” position Switch main switch to “I” position No power to machine Power cord is broken Replace power cord The Main Switch is broken Replace main switch Compressor does not start...
