SpaceControl User Manual
Updated December 11, 2019
SpaceControl is a miniature key fob controlling the security system at a
distance up to 1300 meters absent any obstacles. It allows to set the Ajax
security system in the armed, night or disarmed mode, as well as switch on an
alarm.
As it is the two-way communication, you will know whether the system has
received the SpaceControl command.
Operating as part of the Ajax security system, the key fob is connected to the
hub
via the protected
Jeweller
protocol. In addition, the key fob can be used to
control any third party security central unit through the
uartBridge
or
ocBridge
Plus
integration module.
The fob is set up through the iOS and Android-based
mobile application for
smartphones
or web application.
The Ajax system is self-sustaining, but the user can connect it to the monitoring
station of a security company.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpaceControl and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX Systems SpaceControl

Summary of Contents for AJAX Systems SpaceControl

  • Page 1 SpaceControl User Manual Updated December 11, 2019 SpaceControl is a miniature key fob controlling the security system at a distance up to 1300 meters absent any obstacles. It allows to set the Ajax security system in the armed, night or disarmed mode, as well as switch on an alarm.

  • Page 2: Functional Elements

    Buy key fob SpaceControl Functional elements 1. System arming button 2. System disarming button 3. Night mode button 4. Panic button (activates the alarm) 5. Light indicators 6. The hole for attaching the key fob Buttons can be assigned when using a key fob with hub and Ajax uartBridge. At the moment, the feature of modi cation of commands (and deactivation) of the key fob buttons when using with the Ajax hub is not available.
  • Page 3 To disconnect the actuated security system (siren), press the disarming mode (C) on the key fob. Operational Indication Depending on the rmware version, the SpaceControl key fob LEDs indicate the status with red or green light. The key fob reports its status only after any button is pressed.
  • Page 4 The central LED lights up green for The system has executed the key fob command approximately half a second when a key fob with firmware version 3.18 and later is used The system has not executed the key fob command — integrity veri cation is enabled in the system and one of the devices is faulty The central LED lights up red for approximately half a second when a key fob with rmware...
  • Page 5 2. Go to the Ajax application. 3. Switch on the hub and check the internet connection (via Ethernet cable and/or GSM network). 4. Ensure that the hub is disarmed and does not start updates by checking its status in the mobile application. Only users with administrative privileges can add the device to the hub.
  • Page 6 1. Devices 2. SpaceControl Parameter Value Battery Charge Battery level of the key fob Panic Button Panic button status Firmware Firmware version of the key fob Device ID Device identi er Setting Up the key fob 1. Devices 2. SpaceControl...
  • Page 7 Setting Value First eld Device name, can be edited Selecting the virtual room to which the device is Room assigned Selection of a security group that the key fob manages. You can select All groups or a single group. Arming/disarming permission ��...

  • Page 8: Tech Specs

    When cleaning the key fob body use any means suitable for equipment maintenance. Do not use for cleaning SpaceControl any substances containing alcohol, acetone, gasoline and other active solvents. The pre-installed battery provides up to 5 years of operation of the key fob during normal use (one arming and disarming of the security system per day).

  • Page 9: Complete Set

    2. Battery CR2032 (pre-installed) 3. Quick Start Guide Warranty Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed battery. If the device does not work correctly, you should rst contact the support...
