INSTALLATION GUIDE
9dLD Locator, Version D
1.

Introduction

NOTE: This document applies to 9dLD Location Device with Art. No.: 9dLD2-AB.
The 9dLD Location Device is DECT based and is used in the Ascom IP-DECT System when
location function is required. The handsets within the system can be programmed to measure
the radio signal of the 9dLD, and evaluate whether it is the best location. The location
information is transmitted together with an alarm and gives an indication of the position of the
handset.
Technical Data
Supply voltage
12 – 24 V DC
IMPORTANT: Protect the unit against current exceeding 20 A. Use power cables
Required tools
• Screwdrivers for Phillips and slotted screws
• 16.5 mm drill for drilling antenna cable entry holes
• 12.5 mm drill for drilling power cable entry holes
• 5.5 mm hex nut spanner for the antenna
• Cutting pliers
• Spanner for 8 mm hexnuts
• PDM Windows version
• A handset with DECT Location feature, that is registered in the system
1.1

Regulatory Compliance Statements (EU and EFTA only)

This equipment is in compliance with the essential requirements and other relevant provisions
of Radio Equipment Directive 2014/53/EU and Directive (RoHS3) 2015/863 amending 2011/65/
EU.
The complete Declaration of Conformity is available at the following website:
https://www.ascom-ws.com/doc/
1.2

Regulatory Compliance Statements (USA only)

FCC Compliance Statements
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the transmitting antenna.
• Increase the separation between the equipment and Receiver.
• Connect the equipment into an outlet on a circuit different from that to which the transmitter
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
TD 92775EN / 14 December 2020 / Ver. D
Power consumption
0.7 W
with cross-section 3 mm
2
.
1
