USER MANUAL
PL E ASE R EAD T H E INS T RUC T IONS CA R E F ULLY BE F OR E R I DI NG
NINGBO VSETT INTELLIGENT TECHNOLOGY CO., LTD
DDM
Sport
TEMPERATURE CONTROL
NFC
OFF - ROAD
DUAL MOTOR
HYDRAULIC BRAKE

Advertisement

Table of Contents
loading

Related Manuals for Ningbo VSETT8

Summary of Contents for Ningbo VSETT8

  • Page 1 PL E ASE R EAD T H E INS T RUC T IONS CA R E F ULLY BE F OR E R I DI NG Sport TEMPERATURE CONTROL OFF - ROAD DUAL MOTOR HYDRAULIC BRAKE NINGBO VSETT INTELLIGENT TECHNOLOGY CO., LTD...

  • Page 2: Table Of Contents

    CONTENT GENERAL INFORMATION · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · VSETT RANGE-CONTROL LAYOUT,FUNCTIONS AND SPECIFICATIONS 2~13 ·...
  • Page 3 READ THIS MANUAL BEFORE USING IMPORTANT INFORMATION WHY IS IT NECESSARY TO READ THIS MANUAL BEFORE OPERATING? This manual was written to help you undertsand the proper use and maintenance of the VSETT line of Electric Scooter. It is important to understand the functions and features of the new VSETT before operating it as it will allow you to enjoy the most of it from the first and every ride.
  • Page 4 VSETT8 TURN SIGNAL SWITCH FOLDABLE HANDLE BAR MAX SPEED TELESCOPING BAR 38-42KMH BATTERY 48V 15.6AH LED LIGHTS 48V 19.2AH LG NFC KEY LOCK 48V 21.0AH LG MAX RANGE 80KM ECO /100KM ECO / 110KM ECO ADJUSTABLE FRONT AND REAR SUSPENSION...
  • Page 5 VSETT8 Model VSETT 8 Battery 48V 15.6AH / 48V 19.2AH / 48V 21.0AH Tire Front:8.5*3 inch pneumatic tire, Rear:8*2 inch solid tire Brakes Front and rear drum brakes+Electric brake Max Range 80km/100km/110km Top Speed (Limited to) 38-42KM/H Weight 21KG Suspension...
  • Page 6 VSETT8+ TURN SIGNAL SWITCH FOLDABLE HANDLE BAR DDM SWITCH MAX SPEED 40-45KM/H NFC KEY LOCK TELESCOPING BAR LED LIGHTS BATTERY 48V 16.0AH LG MAX RANGE DUAL MOTORS: 50KM SINGLE MOTOR: 90KM ELECTRONIC BRAKING + DRUM BRAKES + (FRONT+REAR) FOLDING UNIT...
  • Page 7 VSETT8+ Model VSETT 8+ Battery 48V 16.0AH Tire 8 *2 Inch solid tire Brakes Front and rear drum brakes+Electric Brake Max Range Dual drive: 50KM / Single drive: 90KM Top Speed (Limited to) 40-45KM/H Weight 25KG Suspension Front and rear adjustable shock absorption...
  • Page 8 VSETT9 MAX SPEED 40-45km/h ELECTRONIC BRAKE FOLDABLE HANDLE BAR MECHANICAL BRAKE LEVERS NFC KEY LOCK ELECTRONIC HORN TURN SIGNAL SWITCH FOLDING UNIT ELECTRONIC BRAKE + MECH DISC BRAKE SYSTEM MAX RANGE 55KM ECO / 70KM ECO / 80KM ECO THE HOOK: BATTERY FIX HOOK AND 52V 13.0AH / 52V 16.0AH / 52V 17.5AH...
  • Page 9 VSETT9 Model VSETT 9 Battery 52V 13AH/52V 16AH/52V 17.5AH Tire 8.5*3 Inch pneumatic tire Brakes Front and rear disc brakes + Electric Brake Max Range 55km/70km/80km Top Speed (Limited to) 40-45KM/H Weight 23KG Suspension Front and rear adjustable shock absorption Lights Front spotlight+Rear brake light+Front and rear turn signal Controller...
  • Page 10 VSETT9+ MAX SPEED 48-53KM CONTROLLER 48V 23A X 2 ELECTRONIC BRAKE + MECH DISC BRAKE SYSTEM DDM SWITCH NFC KEY LOCK ERGONOMIC FOLDABLE HANDLEBAR ELECTRONIC HORN MECHANICAL BRAKE LEVERS TURN SIGNAL SWITCH MAXIMUM RARGE: RUGGED FOLDING LEVER SINGLE MOTOR 70KM/90KM/100KM DUAL MOTOR 40KM/50KM/55KM MOTOR POWER 650W X 2...
  • Page 11 VSETT9+ Model VSETT 9+ Battery 48V 15.6AH / 48V 19.2AH / 48V 21.0AH Tire 8.5*3 Inch pneumatic tire Brakes Front and rear disc brakes + Electric Brake Max Range Top Speed (Limited to) 48-53KM/H Weight 25KG Suspension Front and rear adjustable shock absorption Lights Front spotlight + Rear brake light+Front and rear turn signal Controller...
  • Page 12 VSETT10+ MAX SPEED 80KM/H（SPORT） ELECTRONIC BRAKE + HYDRAULIC BRAKE SYSTEM CONTROLLER 60V, (30A-35A)*2 DDM SWITCH FOLD THE HANDLE HYDRAULIC BRAKE LEVERS MAXIMUM RANGE DRIVE 130KM/160KM/185KM TURBO BOOST DUAL DRIVE 65KM/80KM/90KM NFC KEY LOCK RUGGED FOLDING LEVER ERGONOMIC FOLDABLE HANDLEBAR MOTOR POWER 1400W X 2 ELECTRONIC HORN TURN SIGNAL SWITCH...
  • Page 13 VSETT10+ Model VSETT 10+ Battery 60V 20.8AH / 60V 25.6AH / 60V 28.0AH Tire 10*3 inch pneumatic tire Brakes Front and rear hydraulic brakes + electric brake Max Range Single motor 130KM/160KM/185KM Dual motors 65KM/80KM/90KM Top Speed (Limited to) Dual Mode: 65-70KM/H Sport Mode:75-80KM/H Weight 36KG Suspension...
  • Page 14 VSETT11+ MAX SPEED 85KM/H(SPORT) ELECTRONIC BRAKE + HYDRAULIC BRAKE SYSTEM TURN SIGNAL SWITCH LED HEADLIGHT HYDRAULIC BRAKE LEVERS TURBO BOOST CONTROLLER NFC KEY LOCK 60 V (40-45A) *2 SINGLE AND DOUBLE DRIVE SWITCH MAX RANGE SINGLE DRIVE 160KM/220KM ELECTRONIC HORN DUAL DRIVE 80KM/110KM MOTOR POWER 1500W X 2...
  • Page 15 VSETT11+ Model VSETT 11+ MODEL Battery 60V 31.2AH/60V 42AH Tire 11*4 Inch Brakes Electric Brake+Automatic power off function+Front and rear hydraulic brakes Max Range(Single Motor) 160KM/220KM Max Range(Dual Motors) 80KM/110KM Max Speed Dual Mode: 70-75KM/H Sport Mode:80-85KM/H Weight 58KG Suspension Front -Rear Hydraulic Suspensions / Patented Hydraulic suspension Lights LED lights + Double LED headlights and taillights + Brake lights + Turn signal...

  • Page 16: Intelligent Temperature Control Management System

    Intelligent temperature control management system INTELLIGENT TEMPERATURE CONTROL MANAGEMENT SYSTEM 2~3min Limited protection measures Intelligent overheat protection The motor controller/s fitted to your VSETT electric Should you resume riding and a second overload event is scooter feature overload protection. Should the controller triggered,the management system will enter a longer temperature exceed the safety threshold, the management protection cycle.
  • Page 17 Intelligent temperature control management system VSETT series electric scooter intelligent temperature control system （A 75KG load was tested according to the summer climate in Ningbo, China） Erial number Model First protection First protection Limit protection Limit protection temperature time temperature duration （According to the local...

  • Page 18: Vsett Display Operation And Programming

    Vsett display operation and porgramming Speed Level Throttle Speed (KM/H) Mode / Enter Battery Indicator + Button - Button Current voltage value NFC card area Token IR Reader Basic operation: 1、Function 1. Displayed content Speedometer / Odometer / Trip meter / Battery level / Cruise-control active light / Gear ondocator / Fault warning light 2.
  • Page 19 Vsett display operation and porgramming 3.1 Speed display area Unit： MPH, KM/H The speed signal is taken from the Hall signal inside the motor.Sent to controller by controller(Time of single Hall period,unit:1MS).The display calculate the true speed based on wheel diameter and signal data calculate the true speed(The motor Holzer also needs to set the number of magnetic steel) 3.2 Vehicle power gear adjustment，...
  • Page 20 Vsett display operation and porgramming Display P-Codes(programming codes) To accsee this menu,long-press .Use button to scroll through P-codes, to change parameterd P01：Backlight brightness:The 1 level is the darkest，Level 3 brightest；Default: 3 P02：Mileage: unit,0：KM；1：MILE；Default: KM P03: Voltage level: 24V，36V，48V，52V，60V, Default:52V P04: Dormancy time:0 means no dormancy;Other numbers are dormant time.The range is 1-60 minute.Default:5 P05: Reserve P06: Wheel diameter: The unit is inch.
  • Page 21 Vsett display operation and porgramming 2、Introduction of buttons and interfaces 1. When it is shutdown, long-press hold button continuously for 2s to turn on the power. When it is power on ,It can change interface between the ODO、TRIP、VOL, by pressing for short time.
  • Page 22 Vsett display operation and porgramming 3、Card binding instructions 1.The instrument is not bound to ID card: After starting up, the LCD displays the normal contents, and the card swiping area displays the power voltage. At this time, the meter can directly enter the working state.
  • Page 23 Vsett display operation and porgramming 3. The instrument has been bound with ID card: after starting up, the LCD displays card, the power voltage is not displayed in the card swiping area, and the swiping indicator flashes, indicating that the card needs to be swiped to start up. At this time, the accelerator does not work. The diagram below: Note:Due to the upgrade of the company's products, some of the displayed contents of the products you get may be different from the instruc- tions, but it will not affect your normal use.
  • Page 24 Vsett display operation and porgramming 1. Horn 8. Displayer 2. Single motor dual motor switching 9. Handle Folding Mechanism 3. NFC 10. Stem Folding Mechanism 4. Voltage Meter 11. Turbo / NOz Button 5. Long-press Lights on 12. Brake 6. Positive Button / Turn on the light 13.
  • Page 25 Vsett display operation and porgramming Text Long-press the power button [7] for 2 seconds to turn on/off the scooter. then use NFC card to active it The scooter Power On/Off turns off automatically if not used for 90 seconds While stationary, and with the power on, Long-press(press and hold for 2s) the [5] & [6] button to cycle through the Speed Control three different speed levels 1 to 3.Use the throttle to control the speed within each speed level.
  • Page 26 Vsett display operation and porgramming TURNING IT ON Press the for 3 seconds and wait to be prompted for the Token (Card). Tap the Token (Card) to the IR reader NFC PSETTING Press and hold both simultaneously for 3 seconds to access the P Setting interface. CHANGING OF SPEED Press the once or the...
  • Page 27 Vsett display operation and porgramming SPORT: TURBO Press the once to activate the Dual Drive Motor function. Pressing it again will allow Single Drive Motor Function DDM: DUAL / SINGLE DRIVE Press the more power, faster, last for two minutes, can't close in the middle, can restart after five minutes Press the once to activate the horn.

  • Page 28: Folding Handle Bars

    Folding handle bar Turn the handle screw anti - clockwise Once loosen, pull the screw catch away to loose the mechanism from each other Simultaneously fold the handle bar down Finish Folding handle bar...
  • Page 29 Folding handle bar Loosen the safety screw Plate opening and folding buckle Pull up safety pin Once the main lever is released, ensure that the Insert buckle capture is also released Folding handle bar...

  • Page 30: Suspension Adjustment

    Suspension adjustment SUSPENSION ADJUSTMENT 1. Firstly, Please loosen the bottom screw (as shown in Figure A) 2. Secondly, Please open the colored block on the back (front) pedal (as shown in Figure B below) 3. Thirdly, Please Use the combination tool to rotate the screw on the back (front) pedal (Figure B) to the appropriate position 4.

  • Page 31: Battery And Charging

    Battery and charging BATTERY - Do not operate the scooter while charging - Do not store the scooter over a long period of time with an almost empty battery. - From time to time, discharge the battery by riding. Have the battery recharge again and make sure to not leave battery fully empty.
  • Page 32 Battery and charging It is important to fully charge the battery before your first use of the scooter. First Charge Your scooter’s battery comes with these built-in features: 1. Balanced charging protection: During charging, the battery automatically balances the voltage among the internal cells to protect each cell. 2.

  • Page 33: Pre Ride Checks

    Pre ride checks PRE RIDE CHECKS The tire is pressurized to the standard value on Brakes are working properly the tire Quick release of handlebar is tight Ensure folding mechanism is fully locked in place with a CLICK sound PRE RIDE CHECKS...

  • Page 34: Warning

    WARNING! Certain countries of regions require safety devices or gear. It is your responsibility to know the state laws and follow them. However, we strongly recommend safety gears to be dorned before opera- tingthe device. TIRE AIR PRESSURE: THE TIRE IS PRESSURIZED TO THE STANDARD VALUE ON THE TIRE SAFETY GEAR Helmet: Most common and serious injuries from riding are head injuries.

  • Page 35: Limited Warranty

    Limited Warranty Limited Warranty BY USING THIS PRODUCT YOU AGREE TO THIS LIMITED WARRANTY. PLEASE READ THIS LIMITED WARRANTY CAREFULLY. To benefit from the limited warranty, the customer is advised to read Vsett Warranty terms together with the “care and maintenance” sections provided in the user manual. This limited warranty applies to the extent permitted by law and unless restricted or prohibited by law.
  • Page 36 5. Defects or malfunctions of the product not notified by customer during the Warranty Period. 6. Products which have had their serial numbers removed or tampered with. 7. This Limited Warranty is in lieu of all other warranties, express or implied either in fact or by operations of law, statutory or otherwise, including, but not limited to any implied warranty of marketability or fitness for a particular use.
  • Page 37 ERROR CODE Error Code Fault Diagnostic Step Resolution Normally ok; Turn off and on Normal Status the scooter to see if the error Normally ok persists Give the brake lever a few Check brake lever on hard presses to ensure that it Brake handlebar and see if brake is not stuck;...

  • Page 38: Error Codes

    ERROR CODES Error Code Fault Diagnostic Step Resolution Check if back screw or Tighten back screw or Turnstile Fault magnet has come loose in replace magnet in the throttle the throttle/LCD Controller Fault Replace controller Replace controller Unplug and plug in LCD connector and see if issue Change of wiring hardness Communication...

  • Page 39: Included In The Box

    Included in the box SERIAL NUMBER ITEM QUANTITY Charger Combination tool Instruction book NFC card Reflective sticker Included in the box...

  • Page 40: After-Sales Service

    After-sales service For any problem listed in following table,our distributor will provide perfect after-sales service within the scope of warranty. Part Quality issue Warranty period Remarks Seriously broken rubber wheel hub,faulty motor Free repair 12 months Motor Unable to use with normal conditions 3 months Free repair Accelerator...
  • Page 41 (DDMMYY) Start date of warramty extension Start date of warramty extension (DDMMYY) Start date of warramty extension (DDMMYY) User information: Name: Contact number: Email: Address: Product information: Mode: Repair station: Date of return: Fault description: Fault Cause: Signature of the repairer: IAfter-sales service...
  • Page 42 NEW MODELS ARE COMING SOON Web:www. vsett.com Facebook:VSETT Instagram:vsett.escooters YouTube:VSETT E-mail:sales@vsett-scooter.com USER MANUAL NINGBO VSETT INTELLIGENT TECHNOLOGY CO., LTD...

This manual is also suitable for:

Vsett8+Vsett9Vsett10+Vsett11+
