Page 1: Digital Camera
Digital Camera EX-Z850 User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/.
Page 2: Introduction
INTRODUCTION INTRODUCTION Unpacking Check to make sure that all of the items shown below are included with your camera. If something is missing, contact your dealer as soon as possible. Rechargeable Lithium Ion Camera CD-ROM • Note that the shape of the AC adaptor depends on the area where you purchased the camera. Special AC Adaptor (Inlet Type) (AD-C52G) USB Cradle...
Page 3: Table Of Contents
INTRODUCTION Contents INTRODUCTION Unpacking ... 2 Features ... 10 Precautions ... 14 QUICK START GUIDE First, charge the battery! ... 19 To configure display language and clock settings ... 20 To record an image ... 21 To view a recorded image ... 22 To delete an image ...
Page 4 INTRODUCTION Using the Flash ... 67 Flash Unit Status Changing the Flash Intensity Setting Using Flash Assist Using the Self-timer ... 73 Specifying Image Size ... 76 Specifying Image Quality ... 77 OTHER RECORDING FUNCTIONS Selecting the Focus Mode ... 79 Using Auto Focus Using the Macro Mode Using Pan Focus...
Page 5 INTRODUCTION Instant Movie Setups (MOVIE BEST SHOT Mode) ... 123 Displaying MOVIE BEST SHOT Sample Scenes Individually Creating Your Own MOVIE BEST SHOT Setup Recording a Short Movie Recording a Past Movie Shooting with the REC Light ... 130 Recording Audio ... 131 Adding Audio to a Snapshot Recording Your Voice Using the Histogram ...
Page 6 INTRODUCTION Adding Audio to a Snapshot ... 177 To re-record audio Playing Back a Voice Recording File ... 179 Displaying Camera Images on a TV Screen ... 180 Selecting the Video Output System DELETING FILES Deleting a Single File ... 183 Deleting All Files ...
Page 7 INTRODUCTION USING A MEMORY CARD Using a Memory Card ... 204 To insert a memory card into the camera To replace the memory card Formatting a Memory Card Copying Files ... 207 To copy all the files in built-in memory to a memory card To copy a specific file from a memory card to built-in memory...
Page 8 INTRODUCTION USING THE CAMERA WITH A COMPUTER Using the Camera with a Windows Computer ... 238 Selecting the Software You Need Computer System Requirements Managing Images on a PC Retouching, Reorienting, and Printing a Snapshot Playing a Movie Editing a Movie Viewing User Documentation (PDF Files) User Registration Exiting the Menu Application...
Page 9 EX-Z850. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or losses suffered by you or any third party due to the use of Photo Loader and/or Photohands.
Page 10: Features
INTRODUCTION I LCD Panel The LCD panel is a product of the latest LCD manufacturing technology that provides a pixel yield of 99.99%. This means that less than 0.01% of the total pixels are defective (they do not turn on or always remain turned on).
Page 11 • Restoring an Old Photograph (page 113) You can use the procedure in this section to restore an old, faded photograph with the color provided by modern digital camera technology. • ID Photo Feature (page 116) After recording a portrait, you can print a page that contains a number of different versions in standard ID photo dimensions.
Page 12 INTRODUCTION • Movie recording with audio (page 118) VGA size, 30 fps, MPEG-4 format • A choice of movie recording functions (page 118) In addition to a Movie mode for normal movie recording, you can also use the MOVIE BEST SHOT mode to select one of the built-in sample movie scenes for setup for the scene you selected.
Page 13 INTRODUCTION • Support for SD memory cards and MMC (MultiMedia Cards) for memory expansion (page 203) • Digital Print Order Format (DPOF) (page 211) Images can be printed easily in the sequence you want using a DPOF compatible printer. DPOF can also be used when specifying images and quantities for printing by professional print services.
Page 14: Precautions
• Never try to open the case of the camera or attempt your own repairs. High-voltage internal components create the risk of electric shock when exposed. Always leave maintenance and repair work up to a CASIO authorized service center. • Keep the small parts and accessories of this camera out of the reach of small children.
Page 15 Next, remove the camera’s battery and/or unplug the AC adaptor power cord from the power outlet, and contact your dealer or nearest CASIO authorized service center. • Never use the camera inside of an aircraft or in any other area where its use is prohibited.
Page 16: Data Error Precautions
I Data Error Precautions • Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in file memory.
Page 17: Operating Conditions
INTRODUCTION I Operating conditions • This camera is designed for use in temperatures ranging from 0°C to 40°C (32°F to 104°F). • Do not use or keep the camera in the following areas. — In areas subject to direct sunlight —...
Page 18: Caring For Your Camera
INTRODUCTION I Power Supply • Use only the special NP-40 rechargeable lithium ion battery to power this camera. Use of any other type of battery is not supported. • This camera does not have a separate battery for the clock. The date and time will reset whenever the camera is not supplied power by the battery and/or the USB cradle for about 24 hours.
Page 19: Quick Start Guide
QUICK START GUIDE QUICK START GUIDE First, charge the battery! Load the battery into the camera (page 35). Stopper Place the camera onto the USB cradle to charge the battery (page 37). • Note that the shape of the AC adaptor depends on the area where you purchased the camera.
Page 20: To Configure Display Language And Clock Settings
QUICK START GUIDE To configure display language and clock settings • Be sure to configure the following settings before using the camera to record images. See page 51 for details. • If you make a mistake when setting the language or clock with the following procedure, you will need to use the camera’s menu to individually change the language (page 198) or clock (page 194) settings.
Page 21: To Record An Image
QUICK START GUIDE To record an image See page 54 for details. Snapshot mode icon Green operation lamp Focus frame Before using a commercially available memory card, be sure to first format it using the camera’s formatting procedure. For details about formatting a memory card, see page 206.
Page 22: To View A Recorded Image
QUICK START GUIDE To view a recorded image See page 150 for details. Press [ ] (PLAY). • This enters the PLAY (playback) mode. Use [ ] and [ ] to scroll through the images. To delete an image 2, 3, 4, 5 Press [ ] (PLAY).
Page 23: Getting Ready
The following table defines the terminology used in this manual. This term as used in this Means this: manual: “camera” The CASIO EX-Z850 Digital Camera “file memory” The location where the camera is currently storing images you record (page 56) “battery”...
Page 24: General Guide
GETTING READY I File Memory The term “file memory” in this manual is a general term that refers to the location where your camera is currently storing the images you record. File memory can be any one of the following three locations. •...
Page 25 GETTING READY I Back Finder Operation lamp ] (PLAY mode) button ] (REC mode) button Mode dial Strap ring [SET] button I Side [SET] [ ][ ][ ][ ] [DISP] button [MENU] button Monitor Screen Speaker ] (Continuous shutter) button [EX] button...
Page 26 GETTING READY I Bottom Stopper Memory card slot Battery compartment Battery cover Connector Tripod screw hole * Use this hole when attaching to a tripod.
Page 27: Usb Cradle
GETTING READY USB Cradle Simply placing your CASIO digital camera onto the USB cradle lets you perform the following tasks. • Battery charging (page 37) • Viewing of images using the Photo Stand slideshow feature (page 174). • TV connectability for viewing of images on a television screen (page 180).
Page 28: Monitor Screen Contents
GETTING READY Monitor Screen Contents The monitor screen uses various indicators and icons to keep you informed of the camera’s status. • Note that the example screens in this chapter are for illustrative purposes only. They do not exactly match the screen contents actually produced on the camera.
Page 29 GETTING READY REC modes (page 54) • Snapshots: Image quality (page 77) Snapshot F : Fine BEST SHOT N : Normal E : Economy Aperture Priority AE • Movies: Image quality Shutter Speed Priority AE (page 119) Manual Exposure NORMAL : Normal Movie MOVIE BEST SHOT REC Light indicator...
Page 30 GETTING READY Digital zoom indicator (page 65) ISO sensitivity (page 142) Aperture value (pages 31, 58, 93, 96) Shutter speed value (pages 31, 58, 95, 96) Zoom indicator (page 65) • Left side indicates optical zoom. • Right side indicates digital zoom. NOTE •...
Page 31 GETTING READY Aperture value (pages 93, 96) Use this item to adjust the aperture. • The aperture value is displayed in the exposure panel when the mode dial is set to “A” (aperture priority AE) or “M” (manual exposure). Shutter speed (pages 95, 96) Use this item to adjust the shutter speed.
Page 32: Play Mode
GETTING READY PLAY Mode PLAY mode file type Folder name/File name (page 185) Snapshot Example : When a file named Movie CIMG0023.JPG is stored in a folder MOVIE BEST SHOT named 100CASIO Short Movie 100-0023 Past Movie Folder name Audio Snapshot •...
Page 33: Changing The Contents Of The Monitor Screen
GETTING READY IMPORTANT! • Some information may not display properly if you display an image that was recorded using a different digital camera model. Changing the Contents of the Monitor Screen Each press of [DISP] changes the contents of the monitor screen as shown below.
Page 34 GETTING READY I PLAY Mode Indicators on Histogram/Details on Indicators off IMPORTANT! • Pressing [DISP] will not change monitor screen contents during standby or recording of an audio snapshot. • The monitors screen cannot be turned off while the camera is in a REC mode using a BEST SHOT scene or with movie recording paused.
Page 35: Attaching The Strap
GETTING READY Attaching the Strap Attach the strap to the strap ring as shown in the illustration. Strap ring IMPORTANT! • Be sure to keep the strap around your wrist when using the camera to protect against accidentally dropping it. •...
Page 36 GETTING READY Orienting the battery with its towards the battery compartment, push the stopper out of the way with the side of the battery as you load it into the camera. NP-40 • Push the bottom of the battery, and make sure that the stopper securely locks the battery in place.
Page 37: To Charge The Battery
GETTING READY To charge the battery Connect the bundled AC adaptor to the [DC IN 5.3V] connector of the USB cradle, and then plug it in to a household power outlet. • Note the shape of the AC adaptor depends on the area where you purchased the camera.
Page 38 GETTING READY NOTE • The AC adaptor is designed for operation on power ranging from 100V AC to 240V AC. Note, however, that the shape of the power cord plug varies according to country or geographic area. It is up to you to find out if the shape of the AC adaptor power cord plug is compatible with local power outlets when traveling abroad.
Page 39 GETTING READY IMPORTANT! • Use only the USB cradle (CA-31) that comes with the camera or the optionally available charger (BC-30L) to charge the special NP-40 rechargeable lithium ion battery. Never use any other charging device. • Use only the bundled AC adaptor. Never use any other type of AC adaptor.
Page 40: Low Battery Indicator
• If the same symptoms occur again when you place the camera on the USB cradle after taking the above steps, contact a CASIO authorized service center. I Low Battery Indicator The following shows how the battery capacity indicator on the monitor screen changes as battery power is used.
Page 41: To Replace The Battery
GETTING READY I Tips to Make the Battery Last Longer • If you do not need the flash while recording, select (flash off) for the flash mode. See page 67 for more information. • Enable the Auto Power Off and the Sleep features (page 47) to protect against wasting battery power when you forget to turn off the camera.
Page 42: Power Supply Precautions
Be sure to read the following Safety Precautions before using the battery for the first time. NOTE • The term “battery” in this manual refers to the CASIO NP-40 Rechargeable Lithium Ion Battery. • Use only the USB cradle (CA-31) that comes with the...
Page 43 Prolonged contact with battery fluid can cause skin irritation. G PRECAUTIONS DURING USE • The battery is designed for use with this CASIO digital camera only. • Use only the USB cradle that comes with the camera or the specified optional charger to charge the battery.
Page 44 Doing so creates the risk of fire and electric shock. • Should the cord of the AC adaptor become damaged (exposed internal wiring), contact your dealer or nearest CASIO authorized service center. A damaged AC adaptor cord creates the risk of fire or electric shock.
Page 45: Turning The Camera On And Off
GETTING READY • Use the AC adaptor where it will not be splashed with water. Water creates the risk of fire and electric shock. • Do not place a vase or any other container Caution! filled with liquid on top of the AC adaptor. Water creates the risk of fire and electric shock.
Page 46: To Turn Off The Camera
GETTING READY NOTE • Pressing [ ] (REC) to turn on the camera enters the REC mode, while pressing [ the PLAY mode. • Pressing [ ] (PLAY) while in a REC mode switches to the PLAY mode. The lens retracts about 10 seconds after switching modes.
Page 47: Configuring Power Saving Settings
GETTING READY Configuring Power Saving Settings You can configure the settings described below to conserve battery power. Sleep : Automatically turns off the monitor screen if no operation is performed for a specified amount of time in a REC mode. Performing any button operation causes the monitor screen to turn back Auto Power Off : Turns off power if you do not perform any operation for a specified amount of...
Page 48: Using The On-Screen Menus
GETTING READY • The Auto Power Off and Sleep features are disabled in the following cases. — When the camera is connected to a computer or some other device through the USB cradle — While a slideshow is in progress —...
Page 49 GETTING READY Press [MENU]. [MENU] [SET ] Settings G Menu Screen Operations Selection cursor (indicates the currently selected item) When you want to do this: Move between tabs Move from the tab to the settings Move from the settings to the tab Move between the settings Display the options...
Page 50 GETTING READY Press [ ] or [ ] to select the tab you want, and then press [SET] to move the selection cursor from the tab to the settings. Use [ ] and [ ] to select the feature whose setting you want to configure, and then press [ ].
Page 51: Configuring Display Language And Clock Settings
GETTING READY Configuring Display Language and Clock Settings Be sure to configure the following settings before using the camera to record images. • Display language • Home city • Date Style • Date and time Note that the current date and time settings are used by the camera to generate the date and time that are stored along with image data, etc.
Page 52: To Configure Display Language And Clock Settings
GETTING READY To configure display language and clock settings Press the power button, [ ] (PLAY) to turn on the camera. Use [ ], [ ], [ ], and [ ] to select the language you want, and then press [SET]. : Japanese English : English...
Page 53 GETTING READY Use [ ] and [ ] to select the date format setting you want, and then press [SET]. Example: December 24, 2006 To display the date like this: Select this format: 06/12/24 YY/MM/DD 24/12/06 DD/MM/YY 12/24/06 MM/DD/YY Set the current date and the time.
Page 54: Basic Image Recording
Recording an Image Specifying the Recording Mode Your CASIO digital camera has eight recording modes, each of which is described below. Before recording an image, use the mode dial to select the recording mode that suits the type of image you are trying to record.
Page 55: Aiming The Camera
BASIC IMAGE RECORDING NOTE Snapshot mode icon • The icon of the. currently selected recording mode (like for the Snapshot mode) is displayed on the monitor screen. Aiming the Camera Use both hands to hold the camera still when shooting an image.
Page 56: Recording An Image
BASIC IMAGE RECORDING IMPORTANT! • Make sure your fingers and the strap do not block the flash, microphone, AF assist light/REC light/self- timer lamp or lens. AF assist light/REC light/ Flash self-timer lamp Microphone NOTE • Moving the camera as you press the shutter button or while the Auto Focus operation is being performed (when you press the shutter button half way) can cause blurring of the image.
Page 57 BASIC IMAGE RECORDING Press the power button or [ on the camera. Power button • This causes an image or a message to appear on the monitor screen, and then enters the currently selected recording mode. • If the camera is in the PLAY mode when it turns on, the message “There are no files.”...
Page 58 BASIC IMAGE RECORDING Press the shutter button half way to focus the image. • When you press the shutter button half way, the camera’s Auto Focus feature automatically focuses the image, and displays the shutter speed value, the aperture value, and the ISO sensitivity.
Page 59 BASIC IMAGE RECORDING *1 The size of the opening (aperture) that allows light passing through the lens to reach the CCD. A larger aperture value indicates a smaller opening for light to pass through. The camera adjusts this setting automatically. *2 The amount of time the shutter remains open, allowing light passing through the lens to reach the CCD.
Page 60: Recording Precautions
BASIC IMAGE RECORDING You can turn the AF assist light on or off. It is recommended that you turn off the AF assist light when recording images of nearby people, etc. In a REC mode, press [MENU]. Use [ ] and [ ] to select the “REC” tab. Use [ ] and [ ] to select “AF Assist Light”, and then press [ ].
Page 61: About Auto Focus
BASIC IMAGE RECORDING • When recording a dimly lit subject while “Auto” is selected for the ISO sensitivity setting (page 142), the camera increases sensitivity and uses a faster shutter speed. Because of this, you need to guard against camera movement if you have flash turned off •...
Page 62: Using The Optical Viewfinder
BASIC IMAGE RECORDING I About the REC Mode Monitor Screen • The image shown on the monitor screen in a REC mode is a simplified image for composing purposes. The actual image is recorded in accordance with the image quality setting currently selected on your camera.
Page 63: Using Zoom
BASIC IMAGE RECORDING • Since the monitor screen shows exactly what will be recorded, always use it for composing images in the Macro and Manual Focus modes. Using Zoom Your camera is equipped with two types of zoom: optical zoom and digital zoom. Normally, the camera automatically switches over to digital zoom after you reach the maximum limit for optical zoom.
Page 64 BASIC IMAGE RECORDING Zoom out Compose the image, and then press the shutter button. NOTE • The optical zoom factor also affects the lens aperture. • Use of a tripod is recommended to protect against hand movement when using the telephoto setting (zoom in).
Page 65: Digital Zoom
BASIC IMAGE RECORDING Digital Zoom Digital zoom digitally enlarges the part of the image at the center of the image screen. The range of digital zoom is 3X to 24X (in combination with optical zoom). IMPORTANT! • When you perform a digital zoom operation, the camera manipulates the image data to enlarge the center of the image.
Page 66 BASIC IMAGE RECORDING Release the zoom controller momentarily, and then slide it towards (telephoto) side again to move the zoom pointer into the digital zoom range. • The zoom pointer will also stop when you move the pointer back to the switch over point to re-enter the optical zoom range.
Page 67: Using The Flash
BASIC IMAGE RECORDING Using the Flash Perform the following steps to select the flash mode you want to use. • The approximate effective range of the flash is shown below. Wide Angle Optical Zoom: Approximately 0.1 to 4.3 meters (0.33´ to 14.1´) (ISO Sensitivity: Auto) Telephoto Optical Zoom: Approximately 0.5 to 2.4 meters (1.6´...
Page 68 BASIC IMAGE RECORDING To do this: Have the flash fire automatically when required (Auto Flash) Turn off the flash (Flash Off) Always fire the flash (Flash On) Always use high-intensity flash, regardless of exposure (High-power Flash) • You can increase sensitivity, which will brighten subjects that are further away, as required.
Page 69 BASIC IMAGE RECORDING I Flash On Select (Flash On) as the flash mode when backlighting causes your subject to appear dark, even though there is enough light to keep the flash from firing automatically. This will cause the flash to fire and illuminate your subject whenever you press the shutter button (daylight synchro flash).
Page 70: Flash Unit Status
BASIC IMAGE RECORDING IMPORTANT! • Note the following important points when using red- eye reduction. — Red-eye reduction does not work unless the people in the image are looking directly at the camera during the pre-flash. Before pressing the shutter button, call out to the subjects so they all look at the camera while the pre-flash operation is performed.
Page 71: Changing The Flash Intensity Setting
BASIC IMAGE RECORDING Changing the Flash Intensity Setting Perform the following steps to change the flash intensity setting. In a REC mode, press [MENU]. Use [ ] and [ ] to select the “Quality” tab. Use [ ] and [ ] to select “Flash Intensity”, and then press [ ].
Page 72: Use And To Select The Setting You Want, And Then Press [Set]
BASIC IMAGE RECORDING Use [ ] and [ ] to select the setting you want, and then press [SET]. To do this: Select this setting: Turn on flash assist Auto Turn off flash assist IMPORTANT! • Flash assist may not produce the desired result for some types of subjects.
Page 73: Using The Self-Timer
BASIC IMAGE RECORDING • When the flash is turned off ( ), mount the camera on a tripod to record images in an area where available lighting is dim. Recording images under dim lighting without the flash can cause digital noise, which makes images appear coarse.
Page 74 BASIC IMAGE RECORDING To do this: Specify a 10-second self-timer Specify a 2-second self-timer Specify Triple Self-timer Disable the self-timer • This causes an indicator identifying the selected self-timer type to appear on the monitor screen. • With the Triple Self-timer, the camera records a series of three images in the sequence described...
Page 75 BASIC IMAGE RECORDING AF assist light/ Press the shutter REC light/self-timer lamp button to record the image. • When you press the shutter button, the AF assist light/REC light/ self-timer lamp flashes and the shutter releases after the self-timer reaches the end of its countdown (about 10 seconds or two seconds).
Page 76: Specifying Image Size
BASIC IMAGE RECORDING Specifying Image Size “Image size” is the size of the image, expressed as the number of vertical and horizontal pixels. A “pixel” is one of the many tiny dots that make up the image. More pixels provide finer detail when an image is printed, but a higher pixel count also causes the image’s file size to be larger.
Page 77: Specifying Image Quality
BASIC IMAGE RECORDING • The above print sizes are all approximate values when printing at a resolution of 200 dpi (dots per inch). Use a larger setting when you want to print at a higher resolution or when you plan to produce a larger size print. •...
Page 78 BASIC IMAGE RECORDING To get this: Select this setting: High image quality, large file Fine size Normal image quality and Normal normal file size Low image quality, small file Economy size IMPORTANT! • Actual file size depends on the type of image you record.
Page 79: Selecting The Focus Mode
OTHER RECORDING FUNCTIONS OTHER RECORDING FUNCTIONS Selecting the Focus Mode You can select one of five different focus modes: Auto Focus, Macro, Pan Focus, Infinity, and Manual Focus. In a REC mode, press [ ] • Each press of [ ] ( cycles thorough the focus mode settings in the sequence shown below.
Page 80: Using Auto Focus
OTHER RECORDING FUNCTIONS Using Auto Focus As its name suggests, Auto Focus focuses the image automatically. The automatic focus operation starts when you press the shutter button down half way. The following is the Auto Focus range. Range: 40cm to ∞ (1.3´ to ∞) •...
Page 81 OTHER RECORDING FUNCTIONS NOTE • When proper focusing is not possible because the subject is closer than the Auto Focus range, the camera automatically switches to the Macro mode range (page 83). • Whenever you perform an optical zoom operation (page 63) while recording with Auto Focus, a value will appear on the monitor screen as shown below to tell you the focusing range.
Page 82: Specifying The Auto Focus Area
OTHER RECORDING FUNCTIONS I Specifying the Auto Focus Area You can use the following procedure to change the Auto Focus area used in the Auto Focus mode and the Macro mode. Note that the configuration of the focus frame changes in accordance with the Auto Focus area you select.
Page 83: Using The Macro Mode
OTHER RECORDING FUNCTIONS • Spot • Focus frame • Free [SET] Focus point Multi Using the Macro Mode Use the Macro mode when you need to focus on close up subjects. The following shows the approximate focus range in the Macro mode. Range: 10cm to 50cm (3.9˝...
Page 84: Using Pan Focus
OTHER RECORDING FUNCTIONS IMPORTANT! • Use of the flash along with the Macro mode can cause the light of the flash to become blocked, which can produce unwanted shadows in your image. Using Pan Focus Pan Focus can be used in a movie mode (Movie, MOVIE BEST SHOT) to focus on a particular subject and record without using Auto Focus.
Page 85: Using The Infinity Mode
OTHER RECORDING FUNCTIONS IMPORTANT! • Pan Focus can be used in a movie mode (Movie, MOVIE BEST SHOT) only. It is disabled in all other modes. • Whenever you perform an optical zoom operation (page 63) prior to movie recording, a value range will appear on the monitor screen as shown below to tell you the focusing range.
Page 86 OTHER RECORDING FUNCTIONS While watching the image on the monitor screen, use [ ] and [ ] to focus. To do this: Do this: Focus in on the subject Press [ ]. Focus out on the subject Press [ ]. •...
Page 87: Using Focus Lock
OTHER RECORDING FUNCTIONS Using Focus Lock Focus lock is a technique you can use to focus on a subject that is not located within the focus frame when you record an image. You can use focus lock in the Auto Focus mode and the Macro mode ( Using the monitor screen, compose the...
Page 88: Exposure Compensation (Ev Shift)
OTHER RECORDING FUNCTIONS Exposure Compensation (EV Shift) Exposure compensation lets you change the exposure setting (EV value) manually to adjust for the lighting of your subject. This feature helps to achieve better results when recording a backlit subject, a strongly lit subject indoors, or a subject that is against a dark background.
Page 89: Adjusting White Balance
OTHER RECORDING FUNCTIONS IMPORTANT! • When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation. NOTE • Performing an EV shift operation while using multi- pattern metering (page 143) will cause the metering mode to switch automatically to center weighted metering.
Page 90: Use And To Select The Setting You Want, And Then Press [Set]
OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the setting you want, and then press [SET]. When shooting under these conditions: Normal conditions Outdoor daylight on a clear day Outdoor daylight on an overcast or rainy day, in the shade of a tree, etc. In the shade of a building or any other area where the color temperature is high...
Page 91: Configuring The White Balance Setting Manually
OTHER RECORDING FUNCTIONS Configuring the White Balance Setting Manually Certain complex light sources or other environmental conditions can make it impossible to obtain good results when “Auto” or one of the fixed light source settings is selected for white balance. Manual white balance lets you configure the camera for a particular light source and other conditions.
Page 92: Specifying The Exposure Mode
OTHER RECORDING FUNCTIONS • This starts the white balance adjustment procedure. The message “Complete” appears on the monitor screen after white balance adjustment is complete. Press [SET]. • This registers the white balance settings and returns to the currently selected recording mode. NOTE •...
Page 93 OTHER RECORDING FUNCTIONS Wide Aperture In a REC mode, align the mode dial with “A” (Aperture Priority). Aperture value Small Aperture Press [SET] to select the aperture value in the exposure panel, and then use [ ] and [ ] to change the setting.
Page 94: Using Shutter Speed Priority Ae
OTHER RECORDING FUNCTIONS Press the shutter button half way. • This causes the camera to configure shutter speed automatically in accordance with the aperture value you selected. Then it focuses the image. • The shutter speed and aperture values on the monitor screen will turn amber when you press the shutter button half way if the image is over-exposed or under-exposed.
Page 95 OTHER RECORDING FUNCTIONS In a REC mode, align the mode dial with “S” (Shutter Speed Priority). Shutter speed Press [SET] to select the shutter speed value in the exposure panel, and then use [ ] and [ ] to change the setting. Slow Shutter speed 60 seconds...
Page 96: Setting Exposure Settings Manually
OTHER RECORDING FUNCTIONS Setting Exposure Settings Manually In the M mode (manual exposure), you can adjust shutter speed and aperture manually. In a REC mode, align the mode dial with “M” (Manual). ISO sensitivity Aperture value Press [SET] to select the aperture value in the exposure panel, and then use [ ] and [ ] to change the setting.
Page 97: Exposure Mode Recording Precautions
OTHER RECORDING FUNCTIONS Exposure Mode Recording Precautions • You may not be able to achieve the brightness you want when recording an image that is very dark or very bright. If this happens, use the M mode (manual exposure) to adjust the aperture or shutter speed manually.
Page 98: Using The Normal-Speed Continuous Shutter Mode
OTHER RECORDING FUNCTIONS Using the Normal-Speed Continuous Shutter Mode Holding down the shutter button continuously records images, as long as there is memory available to store them. In a REC mode, press Use [ ] and [ ] to select “ Cont.”, and then press [SET].
Page 99: Using The High-Speed Continuous Shutter Mode
OTHER RECORDING FUNCTIONS Using the High-Speed Continuous Shutter Mode Holding down the shutter button while high-speed continuous shutter is selected records up to three images at high speed. In a REC mode, press [ Use [ ] and [ ] to select “ Cont.”, and then press [SET].
Page 100: Using The Zoom Continuous Shutter Mode
OTHER RECORDING FUNCTIONS Using the Zoom Continuous Shutter Mode The zoom continuous shutter mode displays a selection boundary that you can use to select an area in the monitor screen. Then when you press the shutter button, the camera records the monitor screen image and the area enclosed in the selection boundary, digitally zoomed to twice its normal size.
Page 101 OTHER RECORDING FUNCTIONS 25-shot Stop Action Images (Using the Multi Continuous Shutter Mode) Use the following procedure to record 25 consecutive stop- action shots at high speed and combine them into a single image. In a REC mode, press [ Use [ ] and [ ] to select “...
Page 102: Continuous Shutter Precautions
OTHER RECORDING FUNCTIONS Continuous Shutter Precautions • Starting a continuous shutter operation causes the exposure and focus settings to be fixed at the levels for the first image. The same settings are applied to all subsequent images. • Continuous shutter cannot be used in combination with any of the following features.
Page 103: Using The Best Shot Mode
OTHER RECORDING FUNCTIONS Using the BEST SHOT Mode Simply select one of a collection of built-in sample scenes and the camera sets up for the scene you selected for beautiful snapshots every time. I Example Sample Scene • Portrait • Scenery •...
Page 104 OTHER RECORDING FUNCTIONS Use [ ], [ ], [ ], and [ ] to select the sample scene you want, and then press [SET]. • Use [ ], [ ], [ ], and [ ] to move the selection boundary around the display. Scrolling left while the selection boundary is in the upper left or scrolling right while it is in the lower right corner will scroll to another screen of 12-sample scenes.
Page 105: Displaying Sample Scenes Individually
OTHER RECORDING FUNCTIONS • When recording the image of a night scene, fireworks, or some other image using a slow shutter speed, use of a tripod is recommended to prevent hand movement. NOTE • Operation guidance and the currently selected BEST SHOT scene appear on the display for about two seconds if the camera is in the BEST SHOT mode when you turn it on.
Page 106: Creating Your Own Best Shot Setup
OTHER RECORDING FUNCTIONS . Use [ ] and [ ] to select the sample scene you want, and then press [SET]. . Press the shutter button to record the image. Creating Your Own BEST SHOT Setup You can use the procedure below to save the setup of an snapshot you recorded as a BEST SHOT scene.
Page 107 OTHER RECORDING FUNCTIONS IMPORTANT! • BEST SHOT user setups are located in the camera’s built-in memory following the built-in sample scenes. • Selecting a user snapshot setup displays the indicator “U” in the upper right corner of the monitor screen, followed by a number (that indicates the setup number).
Page 108: Reducing The Effects Of Hand Or Subject Movement
OTHER RECORDING FUNCTIONS To delete a BEST SHOT user setup . In a REC mode, align the mode dial with “ and then press [SET]. Move the zoom controller to switch from the 12-scene screen to the sample scene. Use [ ] and [ ] to display the user setup you want to delete.
Page 109 OTHER RECORDING FUNCTIONS Using the Menu Screen 1. In a REC mode, press [MENU]. 2. Select the “REC” tab, select “Anti Shake”, and then press [ ]. 3. Use [ ] and [ ] to select “Auto”, and then press [SET].
Page 110: Shooting With High Sensitivity
OTHER RECORDING FUNCTIONS Shooting with High Sensitivity Higher sensitivity makes it possible to record brighter images, without using flash, even when there is not enough lighting available to obtain normal exposure. In a REC mode, align the mode dial with “ and then press [SET].
Page 111: Recording Images Of Business Cards And Documents (Business Shot)
OTHER RECORDING FUNCTIONS Recording Images of Business Cards and Documents (Business Shot) Recording a business card, document, whiteboard, or similarly shaped object from an angle can cause the subject to appear misshaped in the resulting image. Business Shot automatically corrects the shape of rectangular objects to make them appear like the camera was positioned directly in front of them.
Page 112: Before Recording With Business Shot
OTHER RECORDING FUNCTIONS Before recording with Business Shot • Before recording, compose the image so outline of the item you want to record fits entirely within the monitor screen. • Make sure the object is against a background that allows its outline to stand out, and that it fills the monitor screen to the maximum extent possible.
Page 113: Before Trying To Restore An Old Photograph
OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the candidate you want to correct. Use [ ] and [ ] to select “Correct”, and then press [SET]. • Selecting “Cancel” in place of “Correct” stores the original image as-is, without correcting it.
Page 114: To Restore An Old Photograph
OTHER RECORDING FUNCTIONS NOTE • When the camera is at an angle to the old photograph, one side of the recorded image may appear longer than the side opposite from it. This is called “keystoning,” which is caused by the difference in distance from the camera lens to each side of the photograph.
Page 115 OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the contour candidate you want to correct. Use [ ] and [ ] to select “Trim”, and then press [SET]. • This displays a cropping boundary on the monitor screen. •...
Page 116: Recording An Id Photo
OTHER RECORDING FUNCTIONS IMPORTANT! • Digital zoom is disabled while recording an old photograph. However, you can use optical zoom. • The camera will not be able to recognize an old photograph in the following cases. — When part of the photograph extends outside of the monitor screen —...
Page 117 OTHER RECORDING FUNCTIONS • The initial temporary image is not stored in camera memory. The final image is stored in camera memory when you perform step 5. Adjust the position of the subject as described below. To do this: Select this setting: Shift the subject up or down Press [ ] or [ ].
Page 118: Printing An Id Photo
OTHER RECORDING FUNCTIONS Printing an ID Photo Printing an ID photo will print five versions of the same image in the sizes shown below on a single sheet of paper. Then you can cut out the image(s) you want to use. 30 ×...
Page 119: Specifying Movie Image Quality
“Past Movie” to use past movie. • You can play movie files on your computer using Windows Media Player 9. • Installing CASIO AVI Importer component on your Macintosh makes it possible to use QuickTime to playback movies recorded with the camera (page 256).
Page 120: Recording A Standard Movie (Movie Mode)
OTHER RECORDING FUNCTIONS Approximate Setting Data Rate Higher 4.0 megabits (640 × 480 pixels) Quality per second Normal 2.1 megabits (640 × 480 pixels) per second Lower 745 kilobits (320 × 240 pixels) Quality per second Recording a Standard Movie Frame Rate (Movie Mode) 30 frames/...
Page 121: Movie Recording Precautions
OTHER RECORDING FUNCTIONS Point the camera at the subject and then press the shutter button. • This starts movie recording, which is indicated by “ ” on the monitor screen. • Movie recording continues as long as remaining memory capacity allows.
Page 122 OTHER RECORDING FUNCTIONS — Auto Focus is not performed in the case of the Pan Focus ( ), Manual Focus ( ) and Infinity ( focus modes, and so no confirmation tone sounds. In the case of the Manual Focus mode, you cannot adjust focus settings while recording is in progress.
Page 123: Instant Movie Setups
OTHER RECORDING FUNCTIONS Instant Movie Setups (MOVIE BEST SHOT Mode) Simply select one of a collection of built-in sample movie scenes and the camera sets up for the scene you selected. In a REC mode, align the mode dial with “ and then press [SET].
Page 124: Displaying Movie Best Shot Sample Scenes Individually
OTHER RECORDING FUNCTIONS NOTE • Turning on the camera while it is in the MOVIE BEST SHOT Mode will cause operation guidance and the currently selected sample scene to appear on the monitor screen for about two seconds. Displaying MOVIE BEST SHOT Sample Scenes Individually You can use the following procedure to display the MOVIE BEST SHOT sample scenes individually, so you can view...
Page 125: Creating Your Own Movie Best Shot Setup
OTHER RECORDING FUNCTIONS Creating Your Own MOVIE BEST SHOT Setup You can use the procedure below to save the setup of a movie you recorded as a MOVIE BEST SHOT scene. After that, you can recall the setup whenever you want to use it. In a REC mode, align the mode dial with “...
Page 126: Recording A Short Movie
OTHER RECORDING FUNCTIONS I To delete a MOVIE BEST SHOT user setup In a REC mode, align the mode dial with “ and then press [SET]. Move the zoom controller to switch from the 12-scene screen to the sample scene. Use [ ] and [ ] to display the user setup you want to delete.
Page 127 OTHER RECORDING FUNCTIONS I To record a Short Movie In a REC mode, align the mode dial with “ Use [ ], [ ], [ ], and [ ] to select the “Short Movie” scene, and then press [SET]. • Selecting the “Short Movie” scene causes “ appear on the monitor screen.
Page 128 OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the MOTION PRINT layout format you want, and then press [SET]. To do this: Store a capture of the image at the point the shutter button is pressed to start Short Movie recording, and display it on a background of eight frames...
Page 129: Recording A Past Movie
OTHER RECORDING FUNCTIONS Recording a Past Movie Past Movie uses a 5-second buffer that is continually updated. Pressing the shutter button starts recording from five seconds prior to the point the button is pressed. Use Past Movie when you want to make sure you do not miss fast-moving action.
Page 130: Shooting With The Rec Light
OTHER RECORDING FUNCTIONS Shooting with the REC Light AF assist light/REC light/ You can turn on the camera’s self-timer lamp REC light (AF assist light/REC light/self-time lamp) when shooting where lighting is dim. You can turn on the REC light while shooting snapshots to help framing.
Page 131: Recording Audio
OTHER RECORDING FUNCTIONS IMPORTANT! • You also can use [ ] ( ) to cycle through REC light settings (“Auto” “On” “Off”) while movie recording is in progress. • Never look directly into the AF assist light/REC light/ self-timer lamp or point it directly into the eyes of others.
Page 132 OTHER RECORDING FUNCTIONS In a REC mode, press [MENU]. Select the “REC” tab, select “Audio Snap”, and then press [ ]. Use [ ] and [ ] to select “On” and then press [SET]. • This enters the Audio Snapshot mode. •...
Page 133: Recording Your Voice
OTHER RECORDING FUNCTIONS Recording Your Voice Voice Recording provides quick and easy recording of your voice. • Audio Format: WAVE/ADPCM recording format This is the Windows standard format for audio recording. The file extension of a WAVE/ADPCM file is “.WAV”. •...
Page 134: Using The Histogram
OTHER RECORDING FUNCTIONS I Audio Recording Precautions • Take care that you do not block the microphone with your fingers. • Good recording results are not possible when the camera is too far from the subject. • Pressing the power button or pressing [ recording and stores any audio recorded up to that point.
Page 135 OTHER RECORDING FUNCTIONS • An RGB histogram that shows the distribution of R (red), G (green), and B (blue) components is also displayed. This histogram can be used to determine whether there is too much or too little of each of the color components in an image.
Page 136 OTHER RECORDING FUNCTIONS • A centered histogram indicates that there is good distribution of light pixels and dark pixels. This type of histogram results when the overall image is at optimal lightness. IMPORTANT! • Note that the above histograms are shown for illustrative purposes only.
Page 137: Rec Mode Camera Settings
OTHER RECORDING FUNCTIONS REC Mode Camera Settings The following are the settings you can configure before recording an image using the REC mode. • L/R key setting (key customization) • Grid on/off • Image Review on/off • Icon Help on/off •...
Page 138: Turning The On-Screen Grid On And Off
OTHER RECORDING FUNCTIONS IMPORTANT! • While recording a snapshot or movie, you can use [ ] and [ ] to set the functions assigned to them. However, you cannot set the self-timer during movie recording. Turning the On-screen Grid On and Off You can display gridlines on the monitor screen to help you compose images and ensure that the camera is straight when recording.
Page 139: Turning Image Review On And Off
OTHER RECORDING FUNCTIONS Turning Image Review On and Off Image review displays the images you record on the monitor screen as soon as you record them. Use the following procedure to turn image review on and off. In a REC mode, press [MENU]. Select the “REC”...
Page 140: Specifying Power On Default Settings
OTHER RECORDING FUNCTIONS Use [ ] and [ ] to select the setting you want, and then press [SET]. To do this: Display guidance text when you select an icon on the monitor screen. Turn off Icon Help IMPORTANT! • The icons listed below do not appear on the display while Icon Help is turned off.
Page 141 OTHER RECORDING FUNCTIONS Function Flash Focus White Balance AF Area Setting when camera is Metering turned off Self-timer Flash Intensity Digital Zoom Last Auto Focus position that was in MF Position effect before you switched to manual focus Zoom Position* * Only the optical zoom position is remembered.
Page 142: Specifying Iso Sensitivity
OTHER RECORDING FUNCTIONS IMPORTANT! • Note that BEST SHOT mode settings take priority over mode memory settings. If you turn the camera off while in the BEST SHOT mode, all settings except for “Zoom Position” will be configured according to the BEST SHOT sample scene when you turn it back on again, regardless of mode memory on/off settings.
Page 143: Selecting The Metering Mode
OTHER RECORDING FUNCTIONS IMPORTANT! • Under certain conditions, a high shutter speed in combination with a high ISO sensitivity setting can cause digital noise (graininess), which makes an image appear rough. For clean, good-quality images, use the lowest ISO sensitivity setting possible. •...
Page 144 OTHER RECORDING FUNCTIONS Multi (Multi pattern) Multi (Multi pattern) metering divides the image into sections and measures the light in each section for a balanced exposure reading. The camera automatically determines shooting conditions according to the measured lighting pattern, and makes exposure settings accordingly.
Page 145: Specifying Outline Sharpness
OTHER RECORDING FUNCTIONS Using the Filter Function The camera’s filter function lets you alter the tint of an image when you record it. In a REC mode, press [MENU]. Select the “Quality” tab, select “Filter”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 146: Specifying Color Saturation
OTHER RECORDING FUNCTIONS Specifying Color Saturation Use the following procedure to control the intensity of the image you are recording. In a REC mode, press [MENU]. Select the “Quality” tab, select “Saturation”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 147: Date Stamping Snapshots
OTHER RECORDING FUNCTIONS Date Stamping Snapshots You can have the snapshot’s recording date only, or date and time stamped in the lower right corner of the image. In a REC mode, press [MENU]. Select the “Set Up” tab, select “Timestamp”, and then press [ ].
Page 148: Resetting The Camera
OTHER RECORDING FUNCTIONS Resetting the Camera Use the following procedure to reset all of the camera’s settings to their initial defaults as shown under “Menu Reference” on page 259. Press [MENU]. Select the “Set Up” tab, select “Reset”, and then press [ ]. Use [ ] and [ ] to select “Reset”, and then press [SET].
Page 149: Using The Shortcut Menu (Ex Menu)
OTHER RECORDING FUNCTIONS Using the Shortcut Menu (EX Menu) Pressing [EX] displays a shortcut menu that you can use to configure image size, white balance, ISO sensitivity, and AF area settings. In a REC mode, press [EX]. Use [ ] and [ ] to select the item you want, and then use [ ] and [ ] to scroll through the available settings.
Page 150: Basic Playback Operation
The actual display image appears a short while after the preview image. This does not apply to images copied from another digital camera. Image quality Image size Date and time...
Page 151: Playing An Audio Snapshot
PLAYBACK Playing an Audio Snapshot Perform the steps below to display an audio snapshot (indicated by ) and play its audio. In the PLAY mode, use [ ] and [ ] until the image you want is displayed. Press [SET]. •...
Page 152: Zooming The Display Image
PLAYBACK Zooming the Display Image Perform the following procedure to zoom the image currently on the monitor screen up to eight times its normal size. In the PLAY mode, use [ ] and [ ] to display the image you want. Shift the zoom controller towards ) to enlarge the...
Page 153: Resizing An Image
PLAYBACK Resizing an Image You can resize a recorded image to one of three sizes. In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Resize”, and then press [ ]. • Note that this operation is possible only when a snapshot image is on the monitor screen.
Page 154: Cropping An Image
PLAYBACK IMPORTANT! • Resizing an image creates a new file that contains the image in the size you select. The file with the original image also remains in memory. • Note that you cannot resize the following types of images. —...
Page 155 PLAYBACK Move the zoom controller left and right to zoom the image. • The part of the image displayed on the monitor screen is the cropped part. Use [ ], [ ], [ ], and [ ] to to scroll the part to be cropped up, down, left, and right.
Page 156: Keystone Correction
PLAYBACK Keystone Correction Use the following procedure to correct the snapshot of a blackboard, document, poster, photograph, or other rectangular object that is out of square because it was recorded at an angle. • Performing keystone correction on an image causes a new (corrected) version (1600 ×...
Page 157: Using Color Restoration To Correct The Color Of An Old Photograph
Color of an Old Photograph Color restoration let you correct the old color of a photograph shot with a digital camera. This function is useful for correcting existing old photographs, posters, etc. • Performing color restoration on an image causes a new (restored) version (1600 ×...
Page 158 PLAYBACK Move the zoom controller left and right to zoom the cropping boundary. • Resize the cropping boundary as required to crop the area you want. Use [ ], [ ], [ ], and [ ] to move the cropping boundary to the location you want, and then press [SET].
Page 159: Adjusting White Balance Of A Recorded Image
PLAYBACK Adjusting White Balance of a Recorded Image You can use the white balance setting to select a light source type for a recorded image, which will affect the colors of the image. In the PLAY mode, use [ ] and [ ] to display the image whose white balance setting you want to change.
Page 160 PLAYBACK • Normally, the initially selected white balance setting on the above menu is the one that was used when you originally recorded the image. If you used the “Auto” or “Manual” white balance setting when you recorded the image, “Cancel” will be selected (page 89).
Page 161: Adjusting Image Brightness
PLAYBACK Adjusting Image Brightness Use the following procedure to adjust the brightness of snapshots. In the PLAY mode, use [ ] and [ ] to scroll through images and display the one whose brightness you want to adjust. Press [MENU]. Select the “PLAY”...
Page 162: Playing A Movie
PLAYBACK IMPORTANT! • Adjusting the brightness of an image creates a new image with the new brightness level. The original image also remains in memory. • The brightness of the following types of images cannot be adjusted. — Movie images and voice recording file icon —...
Page 163 PLAYBACK To do this: Do this: Fast forward or fast reverse playback Press [ ] or [ ]. • Each press increases the speed one more step. Return fast forward or fast reverse movie playback to normal Press [SET]. speed Pause movie playback Press [SET].
Page 164: Playing Back A Movie With Anti Shake
PLAYBACK Playing Back a Movie with Anti Shake Use the following procedure when you want to play back a movie with Anti Shake. Anti Shake is particularly useful when you have the camera connected to a TV for viewing, since the effects of camera movement are more evident on a big screen.
Page 165: Editing A Movie
PLAYBACK Editing a Movie Use the procedure in this section to edit and delete movies. Editing operations let you cut everything before or after a specific frame, or to cut everything between two frames. IMPORTANT! • Cut operations cannot be undone. Make sure you really want to cut the part of the movie you are specifying before executing the cut operation.
Page 166 PLAYBACK Display the frame where you want the cut to be located. To do this: Do this: Fast forward or fast reverse Press [ ] or [ ]. playback Pause or unpause movie Press [SET]. playback Scroll paused playback one Press [ ] or [ ].
Page 167 PLAYBACK I To cut everything between two specific frames While the movie is playing, press [SET]. • This will pause movie playback. Press [ ]. • You can also display the same screen while in the PLAY mode, by pressing [MENU], selecting the “PLAY”...
Page 168: Capturing A Still Image From A Movie
PLAYBACK Referring to step 4, search for the cut end screen. When the cut end screen is displayed, press [ ]. • The red portion of the indicator bar shows what part will be cut. Use [ ] and [ ] to select “Yes”, and then press [SET].
Page 169 PLAYBACK I To capture a still image from a movie In the PLAY mode, use [ ] and [ ] to scroll through movies on the monitor screen and display the one that contains the frames you want. Press [MENU]. Select the “PLAY”...
Page 170: Displaying The 9-Image View
PLAYBACK Displaying the 9-image View The following procedure displays nine images on the monitor screen at the same time. In the PLAY mode, shift the zoom controller towards ( • This displays the 9-image screen with the image that was on the monitor screen in step 2 in the center, with a selection boundary around it.
Page 171: Displaying The Calendar Screen
PLAYBACK Displaying the Calendar Screen Use the following procedure to display a 1-month calendar. Each day shows the first file recorded on that day, which makes it easy to find the file you want. In the PLAY mode, press [ ] ( •...
Page 172: Playing A Slideshow
PLAYBACK Playing a Slideshow A slideshow automatically plays back images in sequence at a fixed interval. In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Slideshow”, and then press [ ]. Use the screen that appears to configure the image, time, interval, and effect settings.
Page 173 PLAYBACK • Pattern 1, 2, 3 Applies a preset effect when transitioning from one image to another. • Random Effect Randomly applies the preset patterns (1, 2, and 3). • OFF Effects turned off. Use [ ] and [ ] to select “Start”, and then press [SET].
Page 174: Using The Photo Stand Feature
“Images” setting is “Favorites” or “ Only”, or when the slideshow “Interval” setting is “MAX”, “1 sec”, or “2 sec”. • Images copied from another digital camera or a computer may take longer time to appear than the slideshow interval time you specify.
Page 175: Rotating The Display Image
PLAYBACK • Pressing [MENU] displays a screen for configuring slideshow settings. To restart the slideshow, press [MENU] while the menu screen is displayed, or select “Start” and then press [SET]. • During audio playback, you can adjust volume by pressing [ ] and then using [ ] and [ ]. To stop the Phot Stand slideshow, press [PHOTO] again.
Page 176 • You may not be able to rotate a digital image that was recorded with another type of digital camera. • You cannot rotate the following types of images. — Movie images and the voice recording file icon —...
Page 177: Adding Audio To A Snapshot
PLAYBACK Adding Audio to a Snapshot The “after-recording” feature lets you add audio to snapshots after they are recorded. You can also re-record the audio of an audio snapshot (one with a • Audio Format: WAVE/ADPCM recording format This is the Windows standard format for audio recording. The file extension of a WAVE/ADPCM file is “.WAV”.
Page 178: To Re-Record Audio
PLAYBACK To re-record audio In the PLAY mode, use [ ] and [ ] to scroll through snapshots until the one whose audio you want to re-record is displayed. Press [MENU]. Select the “PLAY” tab, select “Dubbing”, and then press [ ]. Use [ ] and [ ] to select “Delete”, and then press [SET].
Page 179: Playing Back A Voice Recording File
PLAYBACK Playing Back a Voice Recording File Perform the following steps to play back a voice recording file. In the PLAY mode, use [ ] and [ ] to display the voice recording file (a file with you want to play. Press [SET].
Page 180: Displaying Camera Images On A Tv Screen
PLAYBACK Displaying Camera Images on a TV Screen You can display recorded images on a TV screen. To display camera images on a TV, you need a television equipped with a video input terminal, USB cradle, and the AV cable that comes with the camera. Connect one end of the AV cable that comes with the camera to the [AV OUT] port of the USB cradle, and the other end to the video...
Page 181: Selecting The Video Output System
PLAYBACK IMPORTANT! • Make sure that “Power On” or “Power On/Off” is selected for the camera’s power on/off functions (page 201) when you connect to a TV to view images. • All icons and indicators that appear on the monitor screen also appear on the TV screen.
Page 182 PLAYBACK IMPORTANT! • Images will not display properly if you select the wrong video system. • This camera supports the NTSC and PAL video systems only. Images will not display properly if you use a TV (monitor) that is designed for a different video system.
Page 183: Deleting Files
DELETING FILES DELETING FILES You can delete a single file, or you can delete all files currently in memory. IMPORTANT! • Note that file deletion cannot be undone. Once you delete a file, it is gone. Make sure you really do not need a file anymore before you delete it.
Page 184: Deleting All Files
DELETING FILES Deleting All Files In the PLAY mode, press [ ] ( Use [ ] and [ ] to select “All Files Delete”, and then press [SET]. Use [ ] and [ ] to select “Yes”. • To exit the file delete operation without deleting anything, select “No”.
Page 185: File Management
FILE MANAGEMENT FILE MANAGEMENT The file management capabilities of the camera make it easy to keep track of images. You can protect files against deletion and store the files you want in the camera’s built-in memory. Folders Your camera automatically creates folders in its built-in memory or on the memory card.
Page 186: Protecting Files
FILE MANAGEMENT Protecting Files Once you protect a file it cannot be deleted (page 183). You can protect files individually or you can protect all files in memory with a single operation. IMPORTANT! • Even if a file is protected, it still will be deleted by a memory card format operation (page 206) or a built- in memory format operation (page 202).
Page 187: To Protect All Files In Memory
FILE MANAGEMENT To protect all files in memory In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Protect”, and then press [ ]. Use [ ] and [ ] to select “All Files : On”, and then press [SET]. •...
Page 188 FILE MANAGEMENT Use [ ] and [ ] to select “Save”, and then press [SET]. • This displays the names of the files in built-in memory or on the loaded memory card. Use [ ] and [ ] to select the file you want to copy to the FAVORITE folder.
Page 189: To Display A File In The Favorite Folder
FILE MANAGEMENT To display a file in the FAVORITE folder In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Favorites”, and then press [ ]. Use [ ] and [ ] to select “Show”, and then press [SET]. •...
Page 190: To Delete A File From The Favorite Folder
FILE MANAGEMENT To delete a file from the FAVORITE folder In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “Favorites”, and then press [ ]. Use [ ] and [ ] to select “Show”, and then press [SET]. Press [ ] ( Use [ ] and [ ] to select the file you want to delete from the FAVORITE folder.
Page 191: Other Settings
OTHER SETTINGS OTHER SETTINGS Configuring Sound Settings You can configure different sounds to play whenever you turn on the camera, press the shutter button half-way or all the way, or perform a key operation. To configure sound settings Press [MENU]. Select the “Set Up”...
Page 192: To Set The Audio Volume Level For Movie And Audio Snapshot Playback
OTHER SETTINGS To set the audio volume level for movie and audio snapshot playback Press [MENU]. Select the “Set Up” tab, select “Sounds”, and then press [ ]. Use [ ] and [ ] to select “ Use [ ] and [ ] to specify the playback volume setting you want, and then press [SET].
Page 193: Specifying The File Name Serial Number Generation Method
OTHER SETTINGS IMPORTANT! • You can select any one of the following types of image as the startup image. — The camera’s built-in image — A snapshot — The image only of an audio snapshot • Only one image can be stored in startup image memory at one time.
Page 194: Setting The Clock
OTHER SETTINGS Setting the Clock Use the procedures in this section to select a Home Time Zone, and to change its date and time settings. If you want to change the time and date setting only without changing the Home Time Zone, perform the procedure under “To set the current time and date”...
Page 195: To Set The Current Time And Date
OTHER SETTINGS To set the current time and date Press [MENU]. Select the “Set Up” tab, select “Adjust”, and then press [ ]. Set the current date and the time. To do this: Do this: Change the setting at the current Press [ ] or [ ].
Page 196: Using World Time
OTHER SETTINGS Using World Time You can use the World Time screen to select a time zone and instantly change the time setting of the camera’s clock when you go on a trip, etc. World Time lets you select one of 162 cities in 32 time zones.
Page 197: Editing The Date And Time Of An Image
OTHER SETTINGS Use [ ], [ ], [ ], and [ ] to select the geographical area you want, and then press [SET]. Use [ ] and [ ] to select the city you want, and then press [SET]. When the setting is the way you want, press [SET] to apply it and exit the setting screen.
Page 198: Changing The Display Language
OTHER SETTINGS To do this: Do this: Change the value at the cursor Press [ ] or [ ]. location Move the cursor between settings Press [ ] or [ ]. Toggle between 12-hour and 24- Press [DISP]. hour timekeeping When all the settings are the way you want, press [SET] to apply them.
Page 199: Changing The Brightness Of The Monitor Screen
OTHER SETTINGS Changing the Brightness of the Monitor Screen You can use the following procedure to change the brightness of the monitor screen. Press [MENU]. Select the “Set Up” tab, select “Screen”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET].
Page 200: Changing The Usb Port Protocol
OTHER SETTINGS Changing the USB Port Protocol You can use the procedure below to change the communication protocol of the camera’s USB port when connecting to a computer, printer, or other external device. Select the protocol that suits the device to which you are connecting.
Page 201: Configuring [ ] (Rec) And [ ] (Play) Power
OTHER SETTINGS Configuring [ ] (REC) and [ Power On/Off Functions You can use the following procedures to configure [ (REC) and [ ] (PLAY) so power turns on and/or off whenever they are pressed. Press [MENU]. Select the “Set Up” tab, select “REC/PLAY”, and then press [ ].
Page 202: Formatting Built-In Memory
OTHER SETTINGS Formatting Built-in Memory Formatting built-in memory deletes any data stored in it. IMPORTANT! • Note that data deleted by a format operation cannot be recovered. Check to make sure you do not need any of the data in memory before you format it. •...
Page 203: Using A Memory Card
USING A MEMORY CARD USING A MEMORY CARD You can expand the storage capabilities of your camera by using a commercially available memory card (SD memory card or MultiMediaCard). You can also copy files from built-in memory to a memory card and from a built-in memory card to built-in memory.
Page 204: Using A Memory Card
USING A MEMORY CARD Using a Memory Card IMPORTANT! • Make sure you turn off the camera before inserting or removing a memory card. • Be sure to orient the card correctly when inserting it. Never try to force a memory card into the slot when you feel resistance.
Page 205: To Replace The Memory Card
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your dealer or nearest CASIO authorized service center. • Never remove a card from the camera while the green operation lamp is flashing. Doing so can cause the file save operation to fail, and even damage the memory card.
Page 206: Formatting A Memory Card
USING A MEMORY CARD Formatting a Memory Card Formatting a memory card deletes any data already stored on it. IMPORTANT! • Be sure to use the camera to format a memory card. Formatting a memory card on a computer and then using it in the camera can slow down data processing by the camera.
Page 207: Copying Files
USING A MEMORY CARD I Memory Card Precautions • If a memory card starts to behave abnormally, you can restore normal operation by reformatting it. However, we recommend that you always take along more than one memory card whenever using the camera far away from the home or office.
Page 208: To Copy All The Files In Built-In Memory To A Memory Card
USING A MEMORY CARD To copy all the files in built-in memory to a memory card Load the memory card into the camera. Turn on the camera. Next, enter the PLAY mode and press [MENU]. Select the “PLAY” tab, select “Copy”, and then press [ ].
Page 209: To Copy A Specific File From A Memory Card To Built-In Memory
USING A MEMORY CARD To copy a specific file from a memory card to built-in memory Perform steps 1 through 3 of the procedure under “To copy all the files in built-in memory to a memory card”. Use [ ] and [ ] to select “Card and then press [SET].
Page 210: Printing Images
PRINTING IMAGES PRINTING IMAGES A digital camera provides you with a variety of different ways to print the images it records. The three main printing methods are described below. Use the method that best suits your needs. I Professional Print Service The camera’s DPOF feature lets you specify which images...
Page 211: Dpof
The letters “DPOF” stand for “Digital Print Order Format”, which is a format for recording on a memory card or other medium which digital camera images should be printed and how many copies of the image should be printed. Then you can print on a...
Page 212: To Configure Print Settings For A Single Image
PRINTING IMAGES To configure print settings for a single image In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “DPOF”, and then press [ ]. Use [ ] and [ ] to select “Select images”, and then press [ ]. Use [ ] and [ ] to display the image you want.
Page 213: To Configure Print Settings For All Images
PRINTING IMAGES To configure print settings for all images In the PLAY mode, press [MENU]. Select the “PLAY” tab, select “DPOF”, and then press [ ]. Use [ ] and [ ] to select “All images”, and then press [ ]. Use [ ] and [ ] to specify the number of copies.
Page 214: Using Pictbridge Or Usb Direct-Print
PRINTING IMAGES • If you take a memory card to a professional print service, be sure to tell them that it includes DPOF settings for the images to be printed and the number of copies. If you don’t, the printing service may print all images without regard to your DPOF settings, or date printing may not be performed.
Page 215 PRINTING IMAGES Press [MENU]. Select the “Set Up” tab, select “USB”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET]. When connecting to this type of Select this setting: device: Computer or USB DIRECT- Mass Storage (USB...
Page 216 PRINTING IMAGES Turn off the camera, and then set the camera on the USB cradle. Turn on the printer. Load paper for printing the images into the printer. Press the USB cradle’s [USB] button. • This displays the print menu on the camera’s monitor screen.
Page 217 PRINTING IMAGES 11 . Use [ ] and [ ] to specify the print option you want. • To print a single image: Select “1 Image” and then press [SET]. Next, use [ ] and [ ] to select the image you want to print.
Page 218: Date Printing
PRINTING IMAGES Date Printing Any one of the procedures described below can be used to include the recording date in image prints. Correct date printing requires that the current date be set on the camera before the image is recorded. •...
Page 219: Print Image Matching Iii
PRINTING IMAGES PRINT Image Matching III Images include PRINT Image Matching data (mode setting and other camera setup information). A printer that supports PRINT Image Matching reads this data and adjusts the printed image accordingly, so your images come out just the way you intended when you recorded them.
Page 220: Viewing Images On A Computer
VIEWING IMAGES ON A COMPUTER VIEWING IMAGES ON A COMPUTER After using the USB cradle to establish a USB connection between the camera and your computer, you can use your computer to view images in file memory and copy images to your computer’s hard disk or other storage media.
Page 221 VIEWING IMAGES ON A COMPUTER IMPORTANT! • Low battery power can cause the camera to power down suddenly during data communication. Use of the special AC adaptor is recommended to power the camera during data communication. • If you are using battery power without the AC adaptor, make sure that the battery is fully charged.
Page 222 VIEWING IMAGES ON A COMPUTER What you should do first depends on whether your computer is running under Windows XP, 2000, Me, 98SE, or 98. Windows 98SE/98 Users • Start from step 2 to install the USB driver. • Note that the example installation presented here uses Windows 98.
Page 223 VIEWING IMAGES ON A COMPUTER When the final setup screen appears, click the [Exit] button on the CD-ROM menu to exit the menu, and then remove the CD-ROM from your computer. • With some computer operating systems, a message prompting you to restart your computer may appear. If this happens, restart your computer.
Page 224 VIEWING IMAGES ON A COMPUTER Connect the USB cable that comes bundled with the camera to the USB cradle and your computer’s USB port. USB cable (bundled) USB port Connector A • Take care when connecting the USB cable to the USB cradle or your computer.
Page 225 VIEWING IMAGES ON A COMPUTER Place the camera onto the USB cradle. • Do not place the camera onto the USB cradle while it is turned on. Press the USB cradle’s [USB] button. • This will cause your computer to create a hardware profile for camera’s built-in memory or the memory card loaded in the camera.
Page 226 VIEWING IMAGES ON A COMPUTER On your computer, double-click “My Computer”. • If you are running Windows XP, click [Start] and then [My Computer]. Double-click “Removable Disk”. • Your computer sees the camera’s file memory as a removable disk. Double-click the “DCIM” folder. Double-click the folder that contains the image you want.
Page 227 VIEWING IMAGES ON A COMPUTER NOTE • If you already have a folder named “DCIM” in your computer’s “My Documents” folder, performing the procedures under step 19 above will overwrite the existing “DCIM” folder with the newly saved folder. If you want to save the contents of the existing “DCIM”...
Page 228: Using The Camera With A Macintosh Computer
VIEWING IMAGES ON A COMPUTER I USB Connection Precautions • Do not leave the same image displayed on your computer screen for a long time. Doing so can cause the image to “burn in” on the screen. • Never disconnect the USB cable, or perform any camera or USB cradle operation while data communication is in progress.
Page 229 VIEWING IMAGES ON A COMPUTER IMPORTANT! • If you want to transfer files from the camera’s built-in memory to a computer, make sure there is no memory card loaded in the camera before you place it onto the USB cradle. •...
Page 230 VIEWING IMAGES ON A COMPUTER [DC IN 5.3V] Connect the USB cable that comes bundled with the camera to the USB cradle and your computer’s USB port. • Take care when connecting the USB cable to the USB cradle or your computer. USB ports and cable plugs are shaped for proper positioning.
Page 231 VIEWING IMAGES ON A COMPUTER Press the camera’s power button to turn it on, and then press its [MENU] button. Select the “Set Up” tab, select “USB”, and then press [ ]. Use [ ] and [ ] to select “Mass Storage (USB DIRECT-PRINT)”, and then press [SET].
Page 232 VIEWING IMAGES ON A COMPUTER Double-click the file that contains the image you want to view. • For information about file names, see “Memory Folder Structure” on page 235. NOTE • If you open a rotated image on your Macintosh, the original unrotated version will appear (page 175).
Page 233: Using A Memory Card To Transfer Images To A Computer
VIEWING IMAGES ON A COMPUTER I USB Connection Precautions • Do not leave the same image displayed on your computer screen for a long time. Doing so can cause the image to “burn in” on the screen. • Never disconnect the USB cable, or perform any camera or USB cradle operation while data communication is in progress.
Page 234: Memory Data
VIEWING IMAGES ON A COMPUTER Using a Commercially Available SD Memory Card Reader/Writer See the user documentation that comes with the SD memory card reader/writer for details about how to use it. Using a Commercially Available PC Card Reader/Writer and PC Card Adaptor (for an SD memory card or MMC) See the user documentation that comes with the PC card reader/writer and PC card adaptor for details about how to use them.
Page 235: Memory Folder Structure
* These folders are created in built-in memory only. I Folder and File Contents • DCIM folder Folder that stores all of the digital camera files • Storage folder Folder for storing files created by the digital camera • Image file...
Page 236: Image Files Supported By The Camera
VIEWING IMAGES ON A COMPUTER • FAVORITE folder (Built-in memory only) Folder that contains Favorites image files (Image Size: 320 × 240 pixels) • DPOF file folder Folder that contains DPOF files • BEST SHOT folder (Built-in memory only) Folder that contains BEST SHOT user setup files •...
Page 237 VIEWING IMAGES ON A COMPUTER I Built-in Memory and Memory Card Precautions • Note that the folder named “DCIM” is the parent (top) folder of all the files in memory. When transferring memory contents to a hard disk, CD-R, MO disk, or other external storage, treat all the contents inside a DCIM folder as a set and always keep them together.
Page 238: Using The Camera With A Windows Computer
Macintosh (see page 253). Using the Camera with a Windows Computer Your digital camera comes bundled with useful applications for using it in combination with a computer. Install the applications you need on your computer. Selecting the Software You Need Install the software on your computer that allows you to perform the type of operations you want.
Page 239 USING THE CAMERA WITH A COMPUTER Purpose Software Name Snapshot retouching, Photohands 1.0 reorientation, printing Movie playback Windows Media Player 9 * DirectX 9.0c Windows 98 WMP6.4 codec Movie editing Ulead Movie Wizard SE – Viewing of user Adobe Reader 6.0 documentation (PDF) files –...
Page 240: Computer System Requirements
USING THE CAMERA WITH A COMPUTER Computer System Requirements Computer system requirements are different for each of the applications. Be sure to check the requirements for the particular application you are trying to use. Note that the values provided here are minimum requirements for running each application.
Page 241 USING THE CAMERA WITH A COMPUTER Photohands 1.0 OS: XP/2000/Me/98SE/98 Memory: At least 64MB HD: At least 10MB DirectX 9.0c OS: XP/2000/Me/98SE/98 HD: At least 65MB free space during installation, 18MB after installation is complete. Adobe Reader 6.0 OS: XP/2000/Me/98SE CPU: Pentium Memory: 32MB HD: 60MB...
Page 242: Managing Images On A Pc
USING THE CAMERA WITH A COMPUTER Managing Images on a PC To manage images on a PC, you need to install the Photo Loader application from the CD-ROM that comes with the camera. • Use the CD-ROM whose contents label shows “Photo Loader”.
Page 243 USING THE CAMERA WITH A COMPUTER I Viewing the Contents of the “Read me” File You should always read the “Read me” file for “Photo Loader” before installing it. The “Read me” file contains information you need to know when installing the application.
Page 244 USING THE CAMERA WITH A COMPUTER I Checking for the Proper Version of DirectX In order to manage images using Photo Loader, your computer also needs to have DirectX 9.0 or higher installed. You can check the installed version of DirectX using your PC’s DirectX Diagnostic Tool.
Page 245: Retouching, Reorienting, And Printing A Snapshot
USING THE CAMERA WITH A COMPUTER Retouching, Reorienting, and Printing a Snapshot In order to retouch, reorient, or print snapshots on your PC, you need to install Photohands from the CD-ROM that comes bundled with the camera. • Use the CD-ROM whose contents label shows “Photohands”.
Page 246 USING THE CAMERA WITH A COMPUTER I Viewing the Contents of the “Read me” File You should always read the “Read me” file for “Photohands” before installing it. The “Read me” file contains information you need to know when installing the application.
Page 247: Playing A Movie
USING THE CAMERA WITH A COMPUTER Playing a Movie In order to play a movie recorded with this camera on your PC using Windows Media Player, you need to install MPEG-4 codec. I To install the codec on a PC that can connect to the Internet Connect the PC to the Internet.
Page 248: Connect To The Internet
USING THE CAMERA WITH A COMPUTER I To install the codec on a PC that cannot connect to the Internet If your PC cannot connect to the Internet, install Windows Media Player 9 from the CD-ROM that comes bundled with the camera.
Page 249 USING THE CAMERA WITH A COMPUTER G Viewing the Contents of the “Read me” File You should always read the “Read me” file for “Windows Media Player 9” before installing it. The “Read me” file contains information you need to know when installing the application.
Page 250: Editing A Movie
USING THE CAMERA WITH A COMPUTER I Movie Playback Precaution The recommended system requirements described below are necessary to use your computer to play back movies recorded with this camera. OS: XP CPU: Pentium M 1GHz or higher Pentium 4 2GHz or higher Required software: Windows Media Player 9 (bundled with camera) DirectX 9.0c (bundled with camera)
Page 251: Selecting A Language
USING THE CAMERA WITH A COMPUTER I Getting Started Start up your computer and insert the CD-ROM into its CD- ROM drive. This will automatically launch the menu application, which displays a menu screen on your computer. • The menu application may not start up automatically on some computers.
Page 252: Viewing User Documentation (Pdf Files)
USING THE CAMERA WITH A COMPUTER Viewing User Documentation (PDF Files) In the “Manual” area, click the name of the manual you want to read. IMPORTANT! • You must have Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view the contents of a PDF file.
Page 253: Using The Camera With A Macintosh Computer
USING THE CAMERA WITH A COMPUTER Using the Camera with a Macintosh Computer Your digital camera comes bundled with useful applications for using it in combination with a computer. Install the applications you need on your computer. Selecting the Software You Need Install the software on your Macintosh that allows you to perform the type of operations you want.
Page 254: Computer System Requirements
Macintosh using the USB cable. CASIO AVI Importer component 1.0 OS: OS X 10.2.8 or greater QuickTime: QuickTime 6.5.2 or greater IMPORTANT! •...
Page 255: Managing Images On A Macintosh
USING THE CAMERA WITH A COMPUTER Managing Images on a Macintosh I To manage images on a Macintosh running OS 9 Install the Photo Loader application from the CD-ROM that comes with the camera. • Use the CD-ROM whose contents label shows “Photo Loader”.
Page 256: Playing Back A Movie On Your Macintosh
In the “Library” folder, double-click “QuickTime”. Drag “CASIO AVI Importer. component” to the “QuickTime” folder. • This installs “CASIO AVI Importer. component” in the “QuickTime” folder. • If there are any other AVI components in the [QuickTime] folder, it can make proper movie playback impossible.
Page 257 USING THE CAMERA WITH A COMPUTER Restart your Macintosh and confirm that QuickTime can play the movies properly. IMPORTANT! • Be sure to move the movie data to the hard disk of your Macintosh before trying to play it. Proper movie playback may not be possible for data accessed over a network, from a memory card, etc.
Page 258: Viewing User Documentation (Pdf Files)
I To view the Photo Loader user’s guide On the CD-ROM, open the “Manual” folder. Open the “Photo Loader” folder and then open the “English” folder. Open “PhotoLoader_english”. To register as a camera user Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/...
Page 259: Menu Reference
APPENDIX APPENDIX Menu Reference The following shows lists of menus that appear in a REC mode and the PLAY mode, and their settings. • The settings that are underlined in the following table are initial defaults. I REC Modes G REC Tab Menu Self-timer 10 sec / 2 sec / X3 / Off Anti Shake...
Page 260 APPENDIX G Quality Tab Menu 8M (3264 × 2448) / Size 8M (3:2) (3264 × 2176 (3:2)) / 6M (2816 × 2112) / 4M (2304 × 1728) / 2M (1600 × 1200) / VGA (640 × 480) Quality Fine / Normal / Economy (Snapshots) Quality HQ / Normal / LP...
Page 261 APPENDIX I PLAY Mode G PLAY Tab Menu Slideshow Start / Images / Time / Interval / Effect / Cancel MOTION PRINT 9 frames / 1 frame / Cancel Movie Editing Cut (Before) / (Between) / Anti Shake On / Off White Balance (Daylight) / (Cloudy) /...
Page 262: Indicator Lamp Reference
APPENDIX Indicator Lamp Reference The camera has three indicator lamps: a green operation lamp, a red operation lamp, and a AF assist light/REC light/ self-timer lamp. These lamps light and flash to indicate the current operational status of the camera. Operation lamp Green * There are three lamp flash patterns.
Page 263 APPENDIX AF assist light/REC light/self- Operation Lamp timer lamp Green White Memory card is locked. / Cannot create folder. / Memory is full. / Write error Pattern 3 Low battery alert Pattern 3 Formatting card Pattern 3 Powering down IMPORTANT! •...
Page 264: Usb Cradle Indicator Lamps
APPENDIX I PLAY Mode AF assist light/REC light/self- Operation Lamp timer lamp Green White Operational (Power on, recording enabled) One of the following operations is being performed: delete, DPOF, image protect, copy, format, power Pattern 3 down, image resizing, image trimming, after recording, keystone correction, color correction, MOTION PRINT, movie editing...
Page 265: Troubleshooting Guide
APPENDIX Troubleshooting Guide Symptom Power does not turn on. 1) The battery is not oriented correctly. 2) The battery is dead. Camera suddenly powers 1) Auto Power Off activated (page 47). down. 2) The battery is dead. Image is not recorded 1) The camera is in the PLAY mode.
Page 266 APPENDIX Symptom Auto Focus does not focus 1) The lens is dirty. properly. 2) The subject is not located in the center of the focus frame when you compose the image. 3) The subject you are shooting is a type that is not compatible with Auto Focus operation (page 61).
Page 267 APPENDIX Symptom Camera powers down The battery is dead. during self-timer countdown. Monitor screen image is 1) You are using the Manual Focus mode and out of focus. have not focused the image. 2) You are trying to use the Macro mode ( when shooting a scenery or portrait shot.
Page 268 APPENDIX Symptom Vertical lines on the Recording a very brightly lit subject can cause a monitor screen. vertical band to appear in the monitor screen image. Out of focus images. The subject is outside the shooting range of the camera. Digital noise in images.
Page 269 APPENDIX Symptom All buttons and switches Circuit problem caused by electrostatic charge, are disabled. impact, etc. while the camera was connected to another device. Monitor screen is off. USB communication is in progress. Cannot transfer files over a 1) Camera is not set securely on the USB cradle. USB connection.
Page 270: If You Have Problems Installing The Usb Driver
Windows 98SE/98 before installing the USB driver from the bundled CD-ROM, or if you have another type of driver installed. This will make it impossible for the computer to recognize the digital camera when it is connected. If this happens, you will need to re-install the camera’s USB driver.
Page 271: Display Messages
If the same message appears after you turn power back on, contact your retailer or a CASIO service center. Load paper! The camera is in the Printer mode, and the printer is out of paper.
Page 272 SYSTEM ERROR Your camera system is corrupted. Contact your retailer or a CASIO service center. The card is locked. The LOCK switch of the SD memory card is locked. You cannot store images to or delete images from a memory card that is locked.
Page 273: Specifications
APPENDIX Specifications Product ... Digital Camera Model ... EX-Z850 I Camera Functions Image Files Format Snapshots ... JPEG (Exif Ver.2.2); DCF (Design rule for Camera File system) 1.0 standard; DPOF compliant Movies ... AVI (MPEG-4) Audio ... WAV Recording Media ... 8.0MB built-in memory...
Page 274 APPENDIX • Movies Image Maximum Approximate Approximate Size Recording Data Rate Recording (Pixels) Time Per (Frame Rate) Time for Built- File in Memory Until 4.0 megabits 16 seconds 640 × 480 memory per second full (30 frames / second) Normal Until 2.1 megabits 31 seconds...
Page 275 APPENDIX Exposure Control Light Metering ... Multi-pattern, center-weighted, spot by Exposure ... Program AE, Shutter Speed Priority AE, Aperture Priority AE, Manual Exposure Exposure Compensation ... –2EV to +2EV (1/3EV units) Shutter ... CCD electronic shutter; mechanical shutter Program AE: 1/2 to 1/1600 second Manual Exposure / Shutter Speed Priority AE: 60 to 1/1600 second Aperture Priority AE: 1 to 1/1600...
Page 276 APPENDIX Recording Functions ... Snapshot; audio snapshot; macro; self- timer; Continuous shutter (Normal- speed Continuous Shutter, High-speed Continuous Shutter, Flash Continuous Shutter, Zoom Continuous Shutter, Multi Continuous Shutter); BEST SHOT; movie with audio (Movie, MOVIE BEST SHOT, Short Movie, Past Movie) ; voice recording •...
Page 277: Power Requirements
APPENDIX I Power Requirements Power Requirements ... Rechargeable lithium ion battery (NP-40) × 1 Approximate Battery Life: The values below indicate the amount of time under the conditions defined below, until power automatically turns off due to battery failure. They do not guarantee that you will be able to achieve this level of operation.
Page 278 APPENDIX I Rechargeable Lithium Ion Battery (NP-40) Rated Voltage ... 3.7 V Rated Capacitance ... 1230 mAh Operating Temperature Range ... 0°C to 40°C (32°F to 104°F) Dimensions ... 38.5(W) × 38.0(H) × 9.3(D) mm (1.53˝(W) × 1.50˝(H) × 0.37˝(D)) Weight ...
Page 279 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA0604-C...

Casio Exilim EX-Z850 User Manual

Introduction

Quick Start Guide

Getting Ready

Basic Image Recording

79 Other Recording Functions

150 Playback

Deleting Files

File Management

Other Settings

203 Using a Memory Card

Printing Images

Viewing Images on a Computer

Using the Camera with a Computer

Appendix

Quick Links

Digital Camera

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Casio Exilim EX-Z850

Summary of Contents for Casio Exilim EX-Z850
