Summary of Contents for TMT Automation ChowBELL
- Page 1 ChowBELL User Manual for video doorbell www.tmt-automation.com...
- Page 3 Index Introduction of the ChowBELL Product Overview Kit contents Specifications Hardware installation_Wifi Hardware installation_LAN cable Pairing indoor chime with ChowBELL Connect ChowBELL to Chow! App Connect your ChowBELL with a gate opener...
-
Page 4: Product Overview
Introduction of the ChowBELL This user manual is designed to provide indications of the ChowBELL and its features and functions. ChowBELL is a device which can connect to App! Chow and provide two-way audio communication. Product Overview Video Doorbell Microphone... -
Page 5: Kit Contents
Kit contents ChowBELL DC cable Power wiring 12V Power Parts package Indoor chime POE cable Specifications Image Sensor 1/4" Color CMOS Sensor Image Sensor Display Resolution 1920 x 1080 Viewing Angle 150° Image Compression H.264 Video Image Frame Rate 25 fps... - Page 6 Hardware installation Wifi Connect to your home Wi-Fi Connect the ChowBELL via 2. 4 GHz Wi-Fi. Please make sure your W i-Fi signal is strong and stable. Hardware installation Connect the 12V Power plug to the Choose a proper location for the DC cable.
- Page 7 Hardware installation LAN cable Connect to LAN cable Connect the ChowBELL to the router with a LAN cable through the RJ45 port. Please connect your ChowBELL to the Wi-Fi network before connect to the LAN cable. Hardware installation Align the DC cable, LAN...
- Page 8 Blue LED blinks. Blue LED blink Step2 Press the button of ChowBELL, the Blue LED of the indoor chime blinks once. Blue LED blink button of ChowBELL again, and the indoor chime will blink which Step3 Press the means the pairing procedure is completed.
- Page 9 Switch to your smartphone’ s Wi-Fi setting page to connect to “GW_AP_XXXXXXXX” (XXXXXXXX is the UID of the device) ***Please refer to the FAQ if GW_AP of the ChowBELL cannot be found*** Tap (+) icon to add a new device.
- Page 10 Connect your ChowBELL with a gate opener To connect your ChowBELL to the gate opener, please go the operation page of a gate opener. Gate opener operation page Settings Available Accessories Select ChowBELL from the list. Device name Live view screen...
- Page 11 Make sure you turn on your smart phone’ s Wi-Fi. Make sure ChowBELL has been set to factory default If ChowBELL is connected to the LAN wire, the AP mode will turn off automatically. Question 3 Change ChowBELL’ s Wi-Fi network Answer 3 ChowBELL control page →...
