Specifications; What Is Included - Boss Audio Systems MPWT60RGB User Manual

MPWT60RGB
6.5" (165 mm) 2-Way Marine/
Powersports Roll Cage/
Waketower Speaker Pods
Congratulations on your
purchase of a
It has been engineered to bring you
the highest level of performance.
Its quality will afford you years of
listening pleasure.
Thank you for making
your choice for audio
entertainment!

Specifications

Mid Bass Driver:
6.5" (165 mm )
Poly injection cone
Rubber surround
Tweeter:
1" (25 mm) PEI dome tweeter
Crossover network:
Built-in
Impedance:
4 Ohms
Power Handling:
600 Watts (MAX)
Frequency Response:
140Hz - 20kHz
Sensitivity:
93dB (1 watt/1 meter)
Dimensions (W x H x D):
7.17" x 9.84" x 7.32"
(182 x 250 x 186 mm)
Weight (in gift box):
9.8 lbs (4.45 kg)
All specifications are subject to
change without notice.
Introduction
Your new MPWT60RGB waketower speakers are high-power,
fully-waterproof 2-way systems featuring 6.5" drivers and
a 1" PEI dome tweeter. Both speakers have LED lights which can be
controlled by the supplied remote control.
different types of installations. Our versatile mounting solutions give
product.
you the ability to attach our wake tower speakers to mounting tubes
with diameters of 1.5" - 2" (38 - 51mm).

What is included?

Before you begin installation, please check that your product contains
the following contents:
(2) Speaker pods with male LED connector
(4) 130x14x2mm rubber mounting strips
(4) 120x14x1mm rubber mounting strips
(2) 48x30x2mm rubber mounting pads
(4) 2" mounting aluminum bands for 2" and 1.875" installation
(4) 1.75" mounting aluminum bands for 1.75" and 1.5" installation
(4) M6 locknuts
(4) M6 flat washers
(4) M6x60mm screws
(1) LED power wire
(1) LED connection wire with female connector
(1) Remote control
(1) Keychain tag
Safety considerations when installing
Please remember that these are heavy products that will be installed in a
boating environment. These vehicles can travel at high speeds and be unstable.
So please consider this and use extreme caution.
Some safety considerations include:
1- Do not mount the speakers in a location where someone may either walk
into or strike their head. During a turbulent ride, please make sure that you do
not loosen footing and fall or hit the unit, or it may cause injury.
2- Secure the wires to the speakers in multiple locations along their route to
your audio source, so that there are no hanging loops of wire. Having unsecure
wires in any hanging conditions can cause entanglement and injury.
3- Tighten the aluminum bands with rubber inserts using care. Do not over
compress the rubber inserts. After installation is complete, please recheck all
bolts and tighten them further if needed before taking your boat or vessel out
for an audio adventure.
4- Do not install these speakers where they may block the view of the pilot and
prevent safe operation of the vessel or vehicle.
understands that wake tower speakers are used in many
