- Page 1 SAFETY JET MODEL 50 R504500 OWNER’S MANUAL RAIDER OUTBOARDS, INC 1885 ARMSTRONG DRIVE, TITUSVILLE, FL 32780 (321) 383 9585...
- Page 2 BOUT AIDER Raider Outboards, Inc. is a US-owned and operated company located in the Space Port Commerce Park, near Kennedy Space Center in Central Florida. Raider designs and produces a line of submersible outboard motors and associated parts, including the Raider Safety Jet.
-
Page 3: Table Of Contents
RAIDER SAFETY JET R504500 ONTENTS ............................1 NTRODUCTION TO THE AFETY ...............................1 IMITED ARRANTY ............................3 ENERAL AFETY RECAUTIONS ..............................5 SSEMBLY VERVIEW ............................7 NSTALLATION NSTRUCTIONS ..............................11 ROUBLESHOOTING Revision A/2022.05.25//... -
Page 4: Introduction To The Safety Jet
NTRODUCTION TO THE AFETY The Raider Outboards Safety Jet Model 50 is a specially manufactured outboard motor jet pump for use on Tohatsu and Mercury 50 horsepower two-stroke outboard motors. Successful usage can only be assured on condition that this manual is read through in its entirety and the maintenance routines described in this manual are followed. - Page 5 RAIDER SAFETY JET R504500 This page intentionally left blank Revision A/2022.05.25//...
-
Page 6: General Safety Precautions
RAIDER SAFETY JET R504500 ENERAL AFETY RECAUTIONS a. As the operator of a Safety Jet-equipped vessel, you are responsible for the well-being of those aboard, those in other craft around yours, and swimmers. It is imperative that you possess thorough knowledge of correct operation of the vessel and the Safety Jet. Please read through this manual carefully to learn the correct operation and maintenance of the Safety Jet. - Page 7 RAIDER SAFETY JET R504500 This page intentionally left blank Revision A/2022.05.25//...
-
Page 8: Assembly Overview
RAIDER SAFETY JET R504500 SSEMBLY VERVIEW Ref. No. Part Number Description R504501 Captive Screw (6) R504502 Washer (6) R504503 Stator R504504 Cotter Pin R504505 Castle Nut R504506 Brass Impeller Washer R504507 Impeller R504508 Stator Carrier Bolt (2) R504509 Wedge-Locking Washer (2) - Page 9 RAIDER SAFETY JET R504500 This page intentionally left blank Revision A/2022.05.25//...
-
Page 10: Installation Instructions
RAIDER SAFETY JET R504500 NSTALLATION NSTRUCTIONS a. This section of the owner’s manual provides the instructions for the proper installation and service of the Raider Safety Jet to your outboard motor. Improper installation or servicing of this Raider product could result in damage to the Safety Jet, outboard motor, or personal injury to those installing or operating the product. - Page 11 RAIDER SAFETY JET R504500 1. P & A ROPELLER NODE EMOVAL a. Begin by using a pair of needle nose pliers or similar to remove the cotter pin from the castle nut. b. Remove the castle nut using a socket wrench and appropriate socket.
- Page 12 RAIDER SAFETY JET R504500 2. S AFETY NSTALLATION a. Install the modified zinc anode provided with the Safety Jet using the hardware removed in step b. Install the stator onto the lower unit, with the wider-slotted standoff oriented towards the top, contacting the lower unit above the prop shaft.
- Page 13 RAIDER SAFETY JET R504500 Img 2e. Install impeller Img 2f. Install brass impeller washer Img 2g. Secure with castle nut & cotter pin Img 2i. Secure nozzle using captive screws ERFORMANCE ONSIDERATIONS An outboard motor with Raider Safety Jet installed will perform similarly to an outboard motor with a propeller, however: •...
-
Page 14: Troubleshooting
RAIDER SAFETY JET R504500 ROUBLESHOOTING Symptom Corrective Action • Change the Trim Angle of the Motor by Craft will not plane moving/changing the Thrust Rod position. • Check for proper craft inflation. • Adjust craft load distribution. • Check fuel supply. - Page 15 RAIDER SAFETY JET R504500 This page intentionally left blank Revision A/2022.05.25//...
- Page 16 Outboards, Inc. 1885 Shepard Drive Titusville, FL 32780 www.raideroutboards.com Telephone: (321) 383-9585 Propeller to Pump Jet...
