UTILITY SHOWER KIT
Español p. 5
PACKAGE AND HARDWARE CONTENTS
PART
DESCRIPTION
A
Shower head
B
Shower arm
C
Soap dish
D
Body
SAFETY INFORMATION
Please read and understand this entire manual before
attempting to assemble, operate or install the product.
CAUTION
• If you solder the joints during installation of the faucet,
the seats, cartridges, and washers must be removed
PREPARATION
Before beginning assembly of product, make sure all parts
are present. Compare parts with package contents list and
hardware contents. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer
service for replacement parts.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Adjustable
Wrench, Groove Joint Pliers, Pipe Wrench, Phillips Screw-
driver, Pipe Tape or Pipe Thread Compound, and Supply
Lines
Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-319-3757,
7 a.m. - 5 p.m., CST, Monday - Friday.
www.homewerksww.com
QUANTITY
1
1
1
1
WARNING
Installations may vary depending on how the previous faucet
was installed. Supplies necessary for the installation of the
faucet are not all included; however, they are available
wherever plumbing supplies are sold.
Prior to beginning installation, turn off the hot or cold water
lines, then turn on the old faucet to release built-up pressure.
When installing the new faucet, hand tighten the connector
nuts. DO NOT OVERTIGHTEN. Connections that are too
tight will reduce the integrity of the system.
1
A
B
C
D
before using a flame or the warranty will be voided on
these parts.
• Cover the sink drain to avoid losing parts.
• Protect your eyes with safety glasses when cutting or
soldering water supply lines.
MODEL #3070-250-CH-B
04-13-2012
