Homewerks Worldwide 3190-40-CH-BC-Z Manual

HIGH ARC WALL-MOUNT FAUCET
3190-40-CH-BC-Z – Chrome finish
PACKAGE AND HARDWARE CONTENTS
PART DESCRIPTION
A Spout with two-function aerator
B Faucet body
C Swivel union
D Flange
E Rubber washer
SAFETY INFORMATION
Please read and understand this entire manual before attempting to
assemble, operate or install the product.
WARNING
• Protect your eyes with safety glasses when cutting or soldering water supply lines.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts
with package and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Adjustable wrench, groove joint pliers,
pipe wrench, Phillips screwdriver, supply lines and thread seal tape
Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-319-3757,
7:30 a.m. - 4:30 p.m., CST, Monday - Friday.
Homewerks Worldwide, LLC • Lake Bluff, IL 60044 • HomewerksWW.com
QUANTITY
1
1
2
2
2
CAUTION
• If you solder the joints during installation of the faucet, the seats, cartridges,
• Cover the sink drain to avoid losing parts.
Installation may vary depending on how the previous faucet was installed. Supplies
necessary for the installation of the faucet are not all included; however, they are
available wherever plumbing supplies are sold.
Prior to beginning installation, turn off the hot or cold water lines, then turn on the
old faucet to release built-up pressure. When installing the new faucet, hand tighten
the connector nuts. DO NOT OVERTIGHTEN. Connections that are too tight will
reduce the integrity of the system.
A
E
B
and washers must be removed before using a flame
or the warranty will be voided on these parts.
NSF/ANSI61
C
D
04-2020
