Connections - Nemtek Druid LCD 20 Installer Manual

12V DC Strobe Light for
Zone 2
12V DC Strobe Light for
Zone 1
20W max 12V DC Siren
Radio alarm not to be
powered from unit!
Gate Switch
(Normally closed)
External On/Off Switch
for Zone 1
External On/Off Switch
for Zone 2
Panic Switch
(Normally closed)
A maximum of two NEMTEK
Druid 4-Zone keypads, two
expansion cards and 100m
of comms cable can be
connected.
A total of two units can
be linked together.
See; Creating a 4 zone
installation, later on in
this manual.
