Fence Wiring Diagrams - Nemtek Druid LCD 20 Installer Manual

The Druid LCD D20 can be connected to a standard electric fence installation, as a low
voltage substitute for an electric fence energizer. The installation and erection of an electric
fence in, South Africa, is to be done according to the latest addition of SANS 10222-3.
In other countries, according to relevant specifications.
Live wire connection
Fence 1
Earth wire connection with earth loop monitoring (preferred)
The fence earth wire is
to be connected to the
main earth spike and
not directly to the unit.
Earth wire connection with no earth loop monitoring
The fence earth wire is
to be connected to the
main earth spike and
not directly to the unit.
Fence 1
Install the main earth
spikes close to the unit
Fence 1
Install the main earth
spikes close to the unit

Fence wiring diagrams

Fence 2
Fence 2
10
Fence 2
All earth spikes are
connected to one wire of
the fence only, and this
one wire is connected to
the rest of the fence at the
main earth spikes.
