INSTRUCTION MANUAL
addendum
M
ONTAGUE –
SE
Gas Convection Ovens
with
Solid State Electronic Controls
MODELS:
SE70, SE115, SE2-70
and SE2-115 Series
This manual is meant as a supplement to the Gas Vectaire manual. The contents
herein describe the function and operation of the Solid state Electronic Controls. For
information on Gas Vectaire Oven Installation, operation, maintenance, service, and
parts, refer to the Gas Vectaire manual part no. 4520-9.
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.
Keep area around appliances free and clear from combustibles.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
THE MONTAGUE COMPANY
1830 Stearman Avenue P.O. BOX 4954
HAYWARD,CA 94540-4954
TEL: 510/785-8822 FAX: 510/785-3342

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vectaire SE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MONTAGUE Vectaire SE

Summary of Contents for MONTAGUE Vectaire SE

  • Page 1 Set up and installation should be performed by qualified installation personnel. Keep area around appliances free and clear from combustibles. PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE. THE MONTAGUE COMPANY 1830 Stearman Avenue P.O. BOX 4954 HAYWARD,CA 94540-4954 TEL: 510/785-8822 FAX: 510/785-3342...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION, INSTALLATION & CAUTIONS ………. 4 OPERATION (Cooking with Solid State Controls) ………. 5 All SE Series Models ……………………………….. 5 Standard Models with Suffix A …………………….. 5 Programmable Models with Suffix AP ……………. 6 Cook-n-Hold Models with suffix AH ………………. 8 WIRING DIAGRAMS ……………………………………….
  • Page 3 FIG. 2 FIG. 1 FIG. 3...

  • Page 4: Introduction, Installation & Cautions

    The SE series Vectaire gas convection ovens are very similar to the Vectaire ovens Montague has produced for years. The most significant difference is that solid-state electronic controls are used instead of the electro-mechanical ones commonly used. The result is the most accurate, responsive, and predictable ovens we have ever offered with the recognized dependabil- ity of solid-state components.

  • Page 5: All Se Series Models

    COOKING COOKING ALL SE SERIES MODELS — See Fig. 1 The ―I‖ portion of the control power switch must be depressed for the oven to operate. The oven display will illuminate (allow for a short time delay). The fan side of the ―FAN/OFF/COOL‖ switch should be depressed in order to begin cooking.

  • Page 6: Programmable Models With Suffix Ap

    COOKING EXAMPLE 1– Cook at 345°F for 2 hours and 15 minutes: EXAMPLE 1 1. Turn ―TIME‖ set dial clockwise (past 59:55 MN) until 2:15 appears in the display. Turn time to 2:15 HR 2. Turn ―TEMP‖ set dial clockwise until 345° appears in the display.
  • Page 7 EXAMPLE 2— Program a 325°F bake for 35 EXAMPLE 2 minutes into program 1: 1. Depress and HOLD ―PGM 1‖ key. Depress and hold 2. Turn ―TIME‖ set dial clockwise until 35:00 MN appears in the display. 3. Turn ―TEMP‖ set dial clockwise until 325° Turn time to 35:00MN appears in the display.

  • Page 8: Cook-N-Hold Models With Suffix Ah

    EXAMPLE 4 EXAMPLE 4—Clear ―PGM 1‖ for other use: Depress and hold 1. Depress and HOLD ―PGM 1‖ key. 2. Turn ―TIME‖ set dial counterclockwise until zeroed. 3. Turn ―TEMP‖ set dial counterclockwise until Turn time to 00:00MN zeroed. 4. Release ―PGM 1‖ key. 5.
  • Page 9 If no cooking mode is selected, or if more than 3 to 5 seconds elapse after depressing the ―ROAST/LOW FAN‖ key control will automatically revert to the ―COOK/HIGH FAN‖ mode and the word ―COOK‖ will appear in the display window. To program either a COOK or ROAST time and temperature into memory, proceed as with the programmable models, only select the cooking mode before depressing the program key.
  • Page 10 To manually set a Cook-n-Hold cycle, first momentarily depress either the ―COOK/HIGH FAN‖ or ―ROAST/LOW FAN‖ key and immediately begin turning the ―TEMP‖ set dial until the desired temperature appears in the display window. Next, set the desired time using the ―TIME‖ set dial. The oven will come on and begin preheating.
  • Page 11 The Cook-n-Hold cycle programmer can now be used as soon as the oven is preheated and loaded, or recalled at any time in the future simply by depressing the same ―PGM‖ key. To shut the oven off instead of using it, turn the ―TEMP‖ and ―TIME‖ set dials counterclockwise to zero out the temp and time displayed EXAMPLE 8 and press the ―CANCEL‖...
  • Page 15 In order to establish full compliance with Proposition 65, we attached a yellow warning label to each gas fired unit manufac- tured by the Montague Company. Carbon monoxide would not be present in concentrations that would pose a "significant risk" to the consumer when the equipment is installed, operated and maintained as follows: 1.
  • Page 16 Serial No. _____________________________________________ Model No. _____________________________________________ Change No. ____________________________________________ Name & No. of Part Model No. Change No. Serial No. The Montague Company 1830 Stearman Avenue P.O. Box 4954 Hayward, CA 94540-4954 Manual Part No. 17598-6 Rev. 1192...
