Part Number:
9027294
Do not connect panel
Note:
to more than one Li-ion Motor
or Li-ion Battery Pack.
Introduction
Included:
WireFree™ Li-ion Solar Panel
A.
Glass-Mount Adhesive
B.
Alcohol wipe
C.
Mounting Brackets with screws (2" & 4")
D.
WireFree™ Li-ion Solar Panel
The WireFree™ Li-ion Solar Panel provides long-life, autonomous energy for Somfy
Li-ion WireFree™ products.
CAUTION
The WireFree™ Li-ion Solar Panel is for indoor use only.
Keep the product out of reach of children. Do not
drop product or expose to flame or heat. Keep away
from liquids and moisture.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9027294 and is the answer not in the manual?

Questions and answers

Related Manuals for SOMFY 9027294

Summary of Contents for SOMFY 9027294

  • Page 1 WireFree™ Li-ion Solar Panel Part Number: 9027294 The WireFree™ Li-ion Solar Panel provides long-life, autonomous energy for Somfy Li-ion WireFree™ products. CAUTION Do not connect panel Note: The WireFree™ Li-ion Solar Panel is for indoor use only. to more than one Li-ion Motor Keep the product out of reach of children.
  • Page 2 Direct to Glass Installation 1. To mount the WireFree™ Li-ion Solar Panel, choose position on the interior side of the glass. WireFree Motorized 2. Position the WireFree™ Li-ion Solar Panel photovoltaic Window cells in direct sunlight. Ensure there are no obstructions. Covering Do not install on tinted or Low E glass.

  • Page 3: Bracket Installation

    Bracket Installation You will need to mount solar panel with brackets if glass application is not possible, such as: panel blocks window movement or casement, double-hung windows or when roll-up cassettes/headrails inhibit direct-to-glass mounting area. Window Frame Mounting 1. For inside top of window frame mounting, position brackets and mark hole locations.

  • Page 4: Operation

    Programming If this installation is an upgrade to an existing Somfy WireFree™ Note: motorized window covering, there is no need to reprogram the motor. If this is a new installation with a Somfy Wirefree™ Motor, please follow the motor installation and programming guide.
  • Page 5 Window Application Tables and Guidelines Window Type Light Single or Window Inside Window Transmission Double Pane Tinting Only 65% or Greater Moving Window Double Hung Sliding Casement Fixed Window Caution: Avoid Caution: Avoid Caution: Panel Concern Clean Install Panel Collision Panel Collision Movement Will Tug or Tear Harness...

  • Page 6: Troubleshooting

    European Directives and in particular of the Machinery Directive 2006/42/EC, and the Radio Directive 2014/53/EU. The full text of the EU declaration of conformity is available at www.somfy.com/ce. Antoine Crézé, Approval manager, acting on behalf of Activity director, Cluses, 06/2018.
