- Page 1 a fast, long-range, optical underwater communication system Manual Ver 1.4 3/2022...
-
Page 2: Table Of Contents
LUMA X setup ......................6 2.1.3 Setting the IP address ....................7 2.1.4 Setting modems to Active Mode ................8 Modem configuration ......................9 LUMA X web configuration menu ..................9 3.1.1 Main page ....................... 10 3.1.2 Parameters page ..................... 10 3.1.3 Status page ...................... - Page 3 WARNING: bright LED light source, do not look directly at emitter a few people may experience epileptic seizures when viewing flashing lights LUMA X 3/2022...
-
Page 4: Introduction
For the purpose of initial setup and testing, the default network configuration and IP addresses are used, as shown in Figure 1. For operational use, the IP addresses of the LUMA X modem and the computers connected to them can be configured differently to suit individual network requirements. -
Page 5: Windows 10 Setup
Ethernet adapter → Properties → select Internet Protocol Version 4 (TCP/IPv4) → Properties set the address as shown in Figure 2 Figure 2: Windows 10 network settings Verifying the IP address setting: Open a command line: → Windows PowerShell Type: ipconfig /all LUMA X 3/2022... -
Page 6: Luma X Setup
On the remote PC, repeat the procedure, but set the IP address to 192.168.102.103. 2.1.2 LUMA X setup Once the host computer’s IP address is set correctly the connection to the LUMA X can be tested. Connect only one LUMA X to a computer via an Ethernet connection using Hydromea’s power/data cable. -
Page 7: Setting The Ip Address
The LUMA X web interface main page should appear (see Figure 4) All LUMA X are factory-set to boot-up into config mode and their factory-set IP address is 192.168.102.101. In order to use several LUMA X within the same network for configuration and testing, they need to be set to differing IP addresses. -
Page 8: Setting Modems To Active Mode
The config mode is the inactive mode and the modem will not forward data between the ethernet cable and the optical interface. After setting the configuration, LUMA X can be switched to active mode. It will now behave as a bridge device, forwarding any traffic from the cable side via the optical link. This effectively connects the networks on both sides, comparable to a cabled connection between two switches or end devices. -
Page 9: Modem Configuration
This chapter will describe the modem configuration in detail. There are two ways to configure LUMA X, the built-in web interface as well as LumaConf, an external program. The web interface is the preferred way to configure LUMA X. LumaConf offers some additional test features that provide several performance metrics for a two-modem connection. -
Page 10: Main Page
SHA and the unique processor ID. 3.1.2 Parameters page Figure 5: parameter page of the web-based configuration-UI This is the main configuration page for the LUMA X. Hovering over the “?” next to each parameter provides a short description. LUMA X... - Page 11 Note: No change will become effective until the Set button has been pressed. After power- cycling the modem the parameters will revert to the previous setting. Pressing the Save button will store the new set of parameters into the LUMA X flash memory and make it the new permanent set of parameters.
-
Page 12: Status Page
(contact Hydromea for assistance if adjust required). Keep-alive When on, the modem will send short packets every 1-2 packets seconds, which helps to maintain optimal gain settings. When off, the modem will not emit any light unless there is data traffic, but there may be packet loss immediately after longer pauses in data flow until the gain control can adjust. -
Page 13: Ip Address Change Page
IP address. After reloading the page, the new IP address will be shown and a Save button is available. Pressing the Save will store the new IP address in the modem’s flash memory, thus making the change permanent. LUMA X 3/2022... -
Page 14: Modem Configuration And Testing Using Lumaconf
To use LumaConf, ensure that the LUMA X is connected to a computer via Ethernet and that it is powered up. After the start of LumaConf you will see the console shown in Figure 10. - Page 15 Note: If LumaConf cannot connect to the LUMA X, it will display “No LUMA connected”. Verify that your host PC is set to the IP address 192.168.102.100 (or respectively, the address specified as the “Host IP address” in the LUMA X parameters).
- Page 16 Selector for the baud rate of the serial interface (only selectable when a serial interface is selected in Selector for LUMA X. If multiple LUMA X are detected, their last IP address byte will be displayed in this drop-down list. The LUMA X which is to be configured can then be selected from this list.
-
Page 17: Lumaconf Parameters
Both LUMA X of a communication link need to be in active mode for normal operation. 4.1 LumaConf parameters Successfully setting a LUMA X into config mode makes the parameters in the lower half of the LumaConf main console changeable. Table 1 in chapter 3.1.2 provides an explanation of the parameters. -
Page 18: Firmware Upgrade And Factory Reset
4.2 Firmware upgrade and factory reset In order to upgrade the firmware of LUMA X or carry out a factory-reset, LUMA X must be put into Bootloader mode. The following steps will upgrade LUMA X firmware and/or carry out a factory reset: ... -
Page 19: Communication Test
Figure 11: Bootloader section of LumaConf for upgrading the firmware or factory reset of LUMA X Discover Query and display all connected LUMA X. Reset all Reset all connected LUMA X Get info Retrieve the processor ID of the selected LUMA X... - Page 20 The rate at which the data is received by the other modem will then be displayed on the opposite side. For example, Figure 12 shows a LUMA X with the last byte of its Configuration IP address being 102 sending random data with high throughput which is received by LUMA X with the last byte of its Configuration IP address being 101 at 10 Mbps.
-
Page 21: Recording A Log File
PDF graph of. The PDF graph will show the perceived throughput of the two LUMA X over a range of gain values. This can be useful to evaluate the autogain performance and, in case it has trouble to automatically find an optimal gain value, determine a value to which to set the gain manually in a controlled environment. -
Page 22: Api
6 API Hydromea provides an API, based on REST, with which key operating parameters of the LUMA X can be changed or status parameters retrieved while the modem is running. The following tables provide a complete list of these parameters, followed by examples showing how to retrieve and change them (in case they are writable). - Page 23 Parameter Valid input Description start_state 0:config, 1:active The state which the LUMA X will boot into. This is factory set to config, but for normal operation this should be set to active optical_speed {1, 4, 6, 8, 10} Speed (in Mbits/s) of the optical Link. Note that higher transmit speeds mean less range.
-
Page 24: Usage Examples
6Mhz, 3 banks of LEDs and with autogain active. Reading the API is similar: response = requests.get("http://192.168.102.101/api/status.json") print(response.json()) and gives the following result: {'amplitude': 3864, 'ambient': 3742, 'temperature': 40.3125, 'throughput_received': 0, 'crc_errors': 0, 'pkt_recv': 0, 'pkt_loss': 0, 'gain': 990, 'nb_additional_rcv': 0, 'status_electronics': 1} LUMA X 3/2022... -
Page 25: Electrical And Software Characteristics
120-degree cone Connector pinout 1: Vcc 2: GND 3: RS232 RX / RS485 D+ 4: RS232 TX / RS485 D- 5: Ethernet RX- 6: Ethernet RX+ 7: Ethernet TX- 8: Ethernet TX+ (*) subject to change without notice LUMA X 3/2022... -
Page 26: Mechanical Characteristics
RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL HYDROMEA BE LIABLE FOR ANY DIRECT, INDIRECT, ONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, OR LOSS OF INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF HYDROMEA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. - Page 27 LUMA X 3/2022...
-
Page 28: Errata
updated mechanical dimension in table 8 1.3.2 16.2.2022 added note about LumaConf not being certified added note about firmware file selection deleted a broken reference minor typo edits 31.3.2022 Added chapter 6 LUMA X 3/2022...
