- Page 1 a fast, long-range, optical underwater communication system Installation Guide 10/2020...
- Page 2 Contents Introduction ..........................3 Operation ..........................3 Setup ..........................3 Operation ......................... 3 Maintenance ........................... 3 Electrical and Software Characteristics .................. 4 Mechanical Characteristics ..................... 5 LUMA X 10/2020...
- Page 3 1 Introduction The LUMA X is an optical modem for fast, reliable underwater communication. Each LUMA X is a full transceiver and thus capable of half-duplex communication (transmission and reception). 2 Operation 2.1 Setup Attach both modems to their respective host systems using matching female SubConn Ethernet Circular 8 pin connectors such as DIL8F, DBH8F or DOM8F.
- Page 4 120 degree cone Connector pinout 1: GND 2: Vcc 3: RS232 RX / RS485 D+ 4: RS232 TX / RS485 D- 5: Ethernet RX- 6: Ethernet RX+ 7: Ethernet TX- 8: Ethernet TX+ (*) subject to change without notice LUMA X 10/2020...
- Page 5 RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL HYDROMEA BE LIABLE FOR ANY DIRECT, INDIRECT, ONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, OR LOSS OF INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF HYDROMEA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 6 LUMA X 10/2020...
