Sandstrom S74PD11E Quick Start Manual

Quick Start Guide
7" Portable DVD Player
S74PD11E
Thank you
for purchasing your new
Sandstr m 7" Portable DVD Player.
Ø
Please follow this quick start guide for a
successful first time set up.
We recommend that you spend some
time reading the instruction manual in
order to fully understand all the opera-
tional features it offers.
Read all the safety instructions carefully
before use and keep the instruction
manual for future reference.
1
Unpacking
Remove all packaging from the unit. Retain the packaging.
If you dispose of it please do so according to any local regulations.
DVD Player Remote Control
(with battery)
SOURCE DISPLAY REPEAT/ REPEAT
PROG A-B
AUDIO/
ANGLE
SUBTITLE/
TITLE
MENU/
ZOOM
/ SETUP
SLOW
OK GOTO
OK
Car Power Adapter
3.5mm to
RCA AV Cable
Carry Bag Instruction Manual
2
Removing the Insulating Strip from the Remote Control
Remove the insulating mylar strip from the battery if the battery is
being used for the first time. It is located at the bottom backside of
the remote control.
GB
REPEAT/
SOURCE DISPLAY
PROG
AUDIO/
ANGLE
SUBTITLE/
TITLE
MENU/
ZOOM
/
SLOW
OK
3
Charging the Battery
1. Connect the mains adapter to DC IN socket on the unit then connect
the mains adapter to the mains socket.
• The LED indicator lights up red indicating that the battery is in
Mains Adapter
charging mode. When the battery is charged to full capacity, the
LED indicator goes green.
2. Remove the mains adapter. The battery is now fully charged and the
unit is ready to use.
Right side of the DVD player
Earphones
USB
Quick Start Guide
Battery Operation time from fully charged battery = Approx. 3 hours
REPEAT
A-B
SETUP
GOTO
To the mains socket
Power adaptor
VOL AV OUT PHONE ON OFF
DC IN 12V
Mains Adapter (included)
4
Power Supply
Using the Mains Adapter
(for indoor use)
Right side of the DVD player
VOL AV OUT PHONE ON OFF
USB
DC IN 12V
Using the Car Power Adapter
(for in-car use)
Right side of the DVD player
USB VOL AV OUT PHONE ON OFF
DC IN 12V
Car Power Adapter (included)
5
Basic DVD Playback
1. Slide the ON/OFF switch to the ON
position.
2. Slide the front panel to open the disc
compartment.
3. Hold the disc by its sides and carefully
place onto the disc holder with the label
side facing up. Gently push the disc down
until you hear a "click" sound.
4. Slide the front panel to close the disc
compartment. You may hold the DVD
player in your hands or use the stand
located at the rear of the unit. The unit
starts playback if the disc does not have
any menus recorded on it. If the disc has
one or more titles recorded on it, a menu
screen will appear on the screen.
5. To play a title, press the / 0-9 buttons
on the remote control to highlight the title
and then press the button on the unit or
the remote control.
You will find that there are many exciting features available.
Tip:
To get to know all these features, please take some time to read
the instruction manual provided.
To the mains
Power adaptor
socket
To cigarette
lighter socket
OK OK
Open the stand
(P.N.: 4034W758001)
