Gateway Description - Saswell SASWG-01-RF-WIFI User Manual

TRV - Smart thermostat
for radiator valve
04
Power supply：2 AA alkaline batteries LR06
(don't use rechargeable batteries!）
Battery life: up to 1 year
Temperature set from 5℃~30℃
Temperature set accuracy (step) 0.5℃
:
Temperature display range 0℃~50℃, accuracy 0.1
Ambient temperature: 0℃~50℃
Warehouse temperature: -10℃~60℃
RF frequency：868MHz, FSK
RF range ：Up to 100m in open

Gateway description

125mm
AP/WIFI
RF
80mm
ON/OFF
Reset button for WIFI mode change
Power supply
RF connect button
26mm
Button description
1 Connection button: Hold the button (5 sec)
to enable RF connectivity mode
Reset button: Hold the button (5 sec) to
2
change the gateway WIFI mode
Status WIFI connection
Status RF connection
Status of output
Changing the WIFI gateway mode AP /WIFI mode
in Wifi mode hold the reset button for 5 sec. and the
device will change the mode to AP. Use the same
procedure to change the gateway mode from AP to
WIFI. The device will reconnect to your local wireless
network, if it was already connected and if is all the
same as the last time it was connected.
05
