Instruction Manual 19 Heavy Duty Rack Case
4
6
7
Item
1
BASE PANEL
2
SIDE PANEL
3
REAR PANEL
4
FRONT PANEL
5
TOP COVER (Option)
6
HANDLE
7
HEX SOCKET SCREW M5 X 20
8
SCREW M4 X 8 mm. PAN HEAD BLK. (With washer)
9
HEX NUT M5 BLK.
1
19" HEAVY DUTY RACK CASE
Description
8
9
Material
Mild Steel 1.20 mm.
Mild Steel 2.00 mm.
Mild Steel 1.20 mm.
AL 3.00 mm.
Mild Steel 1.20 mm.
AL Extruded
Steel
Steel
Steel
5
3
8
2
Qty.
1
2
1
1
1
2
4
12
4
1/4 Rev.03
Advertisement
Related Manuals for RS 6657630
Summary of Contents for RS 6657630
- Page 1 Instruction Manual 19 Heavy Duty Rack Case 19" HEAVY DUTY RACK CASE Item Description Material Qty. BASE PANEL Mild Steel 1.20 mm. SIDE PANEL Mild Steel 2.00 mm. REAR PANEL Mild Steel 1.20 mm. FRONT PANEL AL 3.00 mm. TOP COVER (Option) Mild Steel 1.20 mm.
- Page 2 Instruction Manual 19 Heavy Duty Rack Case 2/4 Rev.03...
- Page 3 19" RACK INSTALLATION GUIDE INSTALLATION HARDWARE NOT INCLUDED Article # Description 6657630 Heavy duty rack case, 1U 46 6x 423 x 34 mm. 6657633 Heavy duty rack case, 2U 466 x 423 x 79 mm. 6657637 Heavy duty rack case, 3U 466 x 423 x 123 mm.
- Page 4 - DEPTH : 466 (D) ARTICLE# MODEL FRONT PANEL HANDLE HEIGHT CABINET (A+B) (E X D X C) 6657630 483 X 44 423 X 466 X 34 6657633 483 X 88 423 X 466 X 79 6657637 483 X 133...
