RHINO TR208LT Manual

Rotary cutter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev 10-2020
An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part of
the safe operation of this machine and must be maintained
with the unit at all times. READ, UNDERSTAND, and FOLLOW
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is
not with the equipment, contact your dealer or Servis-Rhino
(800-446-5158) to obtain a Free copy before operating the
equipment.
®
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
TR208LT/PT
PART'S MANUAL
© 2006 Alamo Group Inc.
ROTARY CUTTER
Part No. 00793559P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR208LT and is the answer not in the manual?

Questions and answers

Related Manuals for RHINO TR208LT

Summary of Contents for RHINO TR208LT

  • Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. If the Operator's Manual is not with the equipment, contact your dealer or Servis-Rhino (800-446-5158) to obtain a Free copy before operating the equipment.
  • Page 2 TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
  • Page 3 PARTS SECTION Parts Section – 1...
  • Page 4 Part Number when ordering Replacement Safety Decals. For maximum safety and to guarantee optimum product reliability, always use genuine Servis-Rhino Parts. The use of inferior replacement parts may cause premature or catastrophic failure which could result in serious injury or death.

  • Page 5: Table Of Contents

    PART NAME INDEX AXLE ASSEMBLY - LIFT TYPE................................4 AXLE ASSEMBLY - LIFT TYPE TAILWHEEL 00776220........................5 AXLE ASSEMBLY - PULL TYPE................................7 AXLE ASSEMBLY - PULL TYPE HUB & SPINDLE ASSEMBLY 00790220..................9 BLADE CARRIER...................................... 10 CANISTER ASSEMBLY.................................... 11 CYLINDER ASSEMBLY - PULL TYPE..............................

  • Page 6: Axle Assembly - Lift Type

    AXLE ASSEMBLY - LIFT TYPE ITEM PART NO. QTY. DESCRIPTION 00793358 WDMT, TR 8` CASTOR ARM 00776220 ASY, CASTER FORK & WHEEL 00793361 PLATE, TR 8` CASTOR LOCK 00793360 PLATE, TR 8` CASTOR HEIGHT 00748823 HHCS 1/2-13 UNC X 1-1/2 GR.5 PL 00001800 LOCKNUT TLM 1/2 NC PLC 4526...
  • Page 7 BLANK INTENTIONALLY TR208 ©2019 Alamo Group Inc.

  • Page 8: Axle Assembly - Lift Type Tailwheel 00776220

    AXLE ASSEMBLY - LIFT TYPE TAILWHEEL 00776220 TR208 ©2019 Alamo Group Inc. Parts Section -5...
  • Page 9 AXLE ASSEMBLY - LIFT TYPE TAILWHEEL 00776220 Continued... ITEM PART NO. QTY. DESCRIPTION 00776220 ASSY CASTER FORK & WHEEL - COMPLETE 373024H WHEEL & TIRE ASSY 00758899 PIN COTTER 3/8X2-1/2 PL EXTEND 02822500 FLATWASHER 1 PL STD ---------- HUB 4 BOLT - ORDER 00780238 (ITEM# 19) 00776213 BEARING 00776219...

  • Page 10: Axle Assembly - Pull Type

    AXLE ASSEMBLY - PULL TYPE ITEM PART NO. QTY. DESCRIPTION 00793240 WDMT, STIFF AXLE ARM 00793220 WDMT, MAIN AXLE 8` DECK 00793242 PLATE, AXLE CLAMP 00790220 ASY,HUB & SPINDLE 8727A CYLINDER, HYD 2-1/2 X 8 00755234 KIT, CONTROL SPACER 00791366 CASTING, 8IN CYLINDER LOCK 420011 PIN, CLEVIS 1 X 5 PL...
  • Page 11 AXLE ASSEMBLY - PULL TYPE Continued... ITEM PART NO. QTY. DESCRIPTION 00037200 NUT,HEX TOPLOCK 3/4 NC GR.C PL 03200347 EMBLEM, SMV 00021400 HEXB 1/4 NC 3/4 PL5 00793364 MOUNT, CANISTER SMV BRANDED 00793365 PLATE, BRANDING BACKER 00780878 RIVET, 3/16 POP X 15/32" G.R. 00748823 HHCS 1/2-13 UNC X 1-1/2 GR.5 PL 4526...

  • Page 12: Axle Assembly - Pull Type Hub & Spindle Assembly 00790220

    AXLE ASSEMBLY - PULL TYPE HUB & SPINDLE ASSEMBLY 00790220 ITEM PART NO. QTY. DESCRIPTION 00790220 ASY,HUB & SPINDLE - 5 BOLT (1-3/4 DIA SHAFT,5-1/2 BC) 00750614 NUT, 1/2-20NF 90° CONE LUG PL (5) 00790292 CAP, HUB (1) 0538400 DRIVE STUD, 1/2-20X1-7/8 (5) 00764375 HHCS ½...

  • Page 13: Blade Carrier

    BLADE CARRIER ITEM PART NO. QTY. DESCRIPTION 00792357 WDMT, BLADE CARRIER 00792892 BLADE, FAN CW 3X14-1/2 CTR-TIP (SHOWN) 00792893 BLADE,FAN CCW 3X14-1/2 CTR-TIP (PARALLEL LIFT) 00786548 KIT, HARDWARE (BOLTS, NUTS, & WASHERS) TR208 ©2019 Alamo Group Inc. Parts Section -10...

  • Page 14: Canister Assembly

    CANISTER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00776031 CANISTER, PARTS MANUAL 00780878 RIVET, 3/16 POP X 15/32" G.R. TR208 ©2019 Alamo Group Inc. Parts Section -11...

  • Page 15: Cylinder Assembly - Pull Type

    CYLINDER ASSEMBLY - PULL TYPE ITEM PART NO. QTY. DESCRIPTION 8727A CYLINDER,HYD 2-1/2 X 8 00774729 CLEVIS CAP ---------- ROD CAP ---------- PISTON 00774753 --------- TUBE 3047112 TIE ROD 00774760 SEAL KIT 3047117 NYLON THREAD PROTECTOR 1917140 ROD CLEVIS ---------- SET SCREW ---------- TIE ROD NUT...

  • Page 16: Decals - Lift Type

    DECALS - LIFT TYPE TR208 ©2019 Alamo Group Inc. Parts Section -13...
  • Page 17 DECALS - LIFT TYPE Continued... ITEM PART NO. QTY. DESCRIPTION ---------- DECAL,MODEL TR208 S/N (N/A) 00790342 DECAL,PAW PRINT 6" 00793551 DECAL, RHINO 12" X 2.69" 00793546 DECAL, TR208 MODEL 1458392 DECAL,RED REFLECTOR 2X9 1458393 DECAL,YELLOW REFLECTOR 2X9 00792312 DECAL,RHINO-BLACK 5.68" TALL...

  • Page 18: Decals - Pull Type

    DECALS - PULL TYPE TR208 ©2019 Alamo Group Inc. Parts Section -15...
  • Page 19 DECALS - PULL TYPE Continued... ITEM PART NO. QTY. DESCRIPTION ---------- DECAL,MODEL TR208 S/N (N/A) 00790342 DECAL,PAW PRINT 6" 00793551 DECAL, RHINO 12" X 2.69" 00793546 DECAL, TR208 MODEL 1458392 DECAL,RED REFLECTOR 1458393 DECAL,YELLOW REFLECTOR 00792312 DECAL,RHINO-BLACK 5.68" TALL 00792179...

  • Page 20: Driveline - 00793194 Double Shaft Flex Coupler

    DRIVELINE - 00793194 DOUBLE SHAFT FLEX COUPLER ITEM PART NO. QTY. DESCRIPTION 00793194 COMPLETE SHAFT,DOUBLE FLEX COUPLER 00778756 DBL FLEX COUPLER SHAFT 11-7/16 00785557 DISC,RUBBER - 7" OD 00766475A WASHER,BEADED D/L COUPLER 00771287 BUSHING,RUBBER DISK 00758636A SPIDER, W/1-3/8-21 SPLINE SE-8 02964434 HEXB METRIC 16-P2.0 - 65MM 5 00765962...

  • Page 21: Driveline - Jackshaft 00793191

    DRIVELINE - JACKSHAFT 00793191 ITEM PART NO. QTY. DESCRIPTION 00793191 COMPLETE JACKSHAFT 00756934 PIN,ROLL 10 X 80 00775310 YOKE INBOARD S5 ---------- STUB + PROFILE W.A. 00756004 DECAL,DANGER - GUARD MISSING 00793535 ASY,FRICTION CLUTCH, 2-PLATE 00793536 KIT,CROSS & BEARING 75MM 0921000470 KIT-FLG.

  • Page 22: Driveline - Main Cv 540Rpm 00787965Sp Pull Type

    DRIVELINE - MAIN CV 540RPM 00787965SP PULL TYPE ITEM PART NO. QTY. DESCRIPTION 00787965SP DRIVELINE,540 RPM,CAT.4,CV 80 DG CV,35EBL 00788002 COMPLETE SHIELD ASSEMBLY 50069190 CROSS BEARING KIT (35EBL) 50069189 CROSS BEARING KIT (80°EBL) 00788001 BOLT, FLANGED 5/8”-11 X 3-1/2” GR.8 5HR10110 LOCKNUT, TOPLOCK FLANGED 5/8”...

  • Page 23: Driveline -540Rpm 00793370 Lift Type

    DRIVELINE - 540RPM 00793370 LIFT TYPE ITEM PART NO. QTY. DESCRIPTION 00793370 ASY,DRIVELINE,540 RPM 1-3/8-6 2 PLATE 00779516 YOKE,1-3/8 - 6 SPLINE 00793536 KIT,CROSS & BEARING 75MM 8982 INBOARD YOKE 2400 SERIES 00756934 PIN,ROLL 10 X 80 8387 YOKE, INBOARD 00793535 ASY,FRICTION CLUTCH, 2-PLATE 8393...

  • Page 24: Gearbox Assembly - 00777389P 1:1.21 Su 540 (Divider)

    GEARBOX ASSEMBLY - 00777389P 1:1.21 SU 540 (DIVIDER) TR208 ©2019 Alamo Group Inc. Parts Section -21...
  • Page 25 GEARBOX ASSEMBLY - 00777389P 1:1.21 SU 540 (DIVIDER) Continued... ITEM PART NO. QTY. DESCRIPTION 00777389P DIVIDERBOX, 1:1.21 SU 540 RPM 00777413 CASTING, DIVIDERBOX 00758497 LOCKNUT,METRIC M40 X 1.5 00744338 HHCS, M10 X 22 PL5 00777414 SHAFT, THROUGH 1-3/8 Z21 00755632 SHIM, 65.1 X 45.3 ID X 2.5 THK 00777415 GEAR, PINION Z22.M5.7...

  • Page 26: Gearbox Assembly - 00791028 1:1.69 No-Lube (Outboard)

    GEARBOX ASSEMBLY - 00791028 1:1.69 NO-LUBE (OUTBOARD) TR208 ©2019 Alamo Group Inc. Parts Section -23...
  • Page 27 GEARBOX ASSEMBLY - 00791028 1:1.69 NO-LUBE (OUTBOARD) Continued... ITEM PART NO. QTY. DESCRIPTION 00791028 ASSY, GEARBOX- 1:1.69 ADJ TO INPUT SHAFT 00791030 CAP, HOUSING 00791031 SHAFT, INPUT-1-3/8 6-SPL 00754753 SEAL, OIL - 35 X 72 X 10 2716540 CAP, OIL-72 X 10 61364C8 HHCS, M10-1.5 X 16MM PL8 00791032...

  • Page 28: Guarding Assemblies

    GUARDING ASSEMBLIES ITEM PART NO. QTY. DESCRIPTION 00793276 ASY, TR208 FRONT CHAIN 00793274 ASY, TR208 REAR RH CHAIN 00793270 ASY, TR208 REAR CHAIN 00793272 ASY, TR208 REAR LH CHAIN 00793268 BRACKET, TAIL DEFLECTOR 00793267 DEFLECTOR, RUBBER TAIL 4526 NUT LOCK FLG WHIZ 1/2-13 NC PL 000514 CARB, 1/2 NC 1-1/4 PL5 000644...

  • Page 29: Level Rod Assembly - Pull Type 00793257

    LEVEL ROD ASSEMBLY - PULL TYPE 00793257 ITEM PART NO. QTY. DESCRIPTION 00793257 SUB-ASSY, TR8` LEVEL ROD 00793258 WDMT, TR 8` FRONT LEVEL ROD 00778163 WDMT,ROD,LEVEL,SHORT 00778159 NUT,ADJUSTING,9" 00778160 NUT,HEX JAM 7/8-9 UNC LH PLT 15B1200 WASHER 3/4 P SAE 651102 PIN, DRILLED 00755153...

  • Page 30: Quick Hitch Components

    QUICK HITCH COMPONENTS ITEM PART NO. QTY. DESCRIPTION 00792426 ARM, FRONT A-FRAME-RH 00792425 ARM, FRONT A-FRAME-LH 00793227 LINK, TR208 LIFT 00780663 FLAT,DRIVELINE STORAGE 00793269 LINK, SMALL REAR A-FRAME RH 00793266 LINK, SMALL REAR A-FRAME 00792427 PLATE, RAMP LINK 03200782 HEXB 1 NC 5 PL5 317014C HEX CAP 3/4-10 X 5 00792430...
  • Page 31 QUICK HITCH COMPONENTS Continued... ITEM PART NO. QTY. DESCRIPTION 00792278 BUSHING, .88 OD X .64 ID X 1.19 00780869 NUT, FLG 5/8NC SPIRALOCK PL5 00755305 HEXB, 1-8UNC-6 LG GRD 8 5JRC1680 NUT TOPLOCK 1 00791906 COVER, BLADE BOLT 69141 PIN, HITCH CAT II & III 2196 CLIP (LYNCH PIN), 13/32 DIA.

  • Page 32: Shield Assembly - Center Lift Type

    SHIELD ASSEMBLY - CENTER LIFT TYPE ITEM PART NO. QTY. DESCRIPTION 00787817 DRIVELINE SHIELD - COMPLETE ASSEMBLY 00787820 BAND CLAMP ASSEMBLY 00787818 DRIVELINE SHIELD CONE 00787819 MOUNTING PLATE 00023500 FLATWASHER 5/16 PL 00011700 HIGH ALLOY, L/W 5/16 YZ KG 10119000 HEXB 5/16 X 1 NC GR5 02030700 HHCS 1/2 NC 1-1/4 PL5...
  • Page 33 BLANK INTENTIONALLY TR208 ©2019 Alamo Group Inc.

  • Page 34: Shield Assembly - Center Pull Type

    SHIELD ASSEMBLY - CENTER PULL TYPE TR208 ©2019 Alamo Group Inc. Parts Section -30...

  • Page 35: Shield Assembly - Outboard

    SHIELD ASSEMBLY - CENTER PULL TYPE Continued... ITEM PART NO. QTY. DESCRIPTION 00793421 SHIELD, TR 210 JACKSHAFT 00793281 LATCH, COMPRESSION 00793321 BRKT, JCKSHFT SHIELD HINGE RH 00793317 BRKT, JCKSHFT SHIELD HINGE LH 00793319 PLATE, JACKSHAFT SHIELD MOUNT 00793307 BEARING, 45MM FLANGE 00793252 WDMT, SM TR BEARING MOUNT 32754...
  • Page 36 SHIELD ASSEMBLY - OUTBOARD ITEM PART NO. QTY. DESCRIPTION 00793279 SHIELD, TR 8` OUTER DL RH 00793278 SHIELD, TR 8` OUTER DL LH 00793312 BRACKET, SIDE DR SHIELD HINGE RH 00793311 BRACKET, SIDE DR SHIELD HINGE LH 00793314 WDMT, SIDE DR SHIELD HINGE MOUNT 00793313 SUPPORT, SIDE DRIVE SHIELD 00793281...

  • Page 37: Skid Shoes

    SKID SHOES ITEM PART NO. QTY. DESCRIPTION 00792558 SHOE, LONG FORMED SKID-LEFT (SHOWN) 00792559 SHOE, LONG FORMED SKID-RIGHT 000644 CARB-3/8 NCK 1-1/4 PL5 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ TR208 ©2019 Alamo Group Inc. Parts Section -34...

  • Page 38: Slipclutch - 00793535

    SLIPCLUTCH - 00793535 ITEM PART NO. QTY. DESCRIPTION 00793535 ASY,FRICTION CLUTCH, 2-PLATE INT DRIVELINE 1-3/8" 6-SPLINE 61064C8 M10X1.5X50 GR.8.8 HEX CAPSCREW 00765676 NUT,METRIC TOPLOCK M10-P1.5 ---------- BALL,1/2 1416425 COLLAR,LOCK ---------- SPRING,COMPRESSION ---------- BACK UP RING 00754202 DISC,FRICTION - NON ASBESTOS ---------- SNAP RING-SP42 DIN 5417 ----------...

  • Page 39: Tongue Assembly - Pull Type

    TONGUE ASSEMBLY - PULL TYPE ITEM PART NO. QTY. DESCRIPTION 00793228 WDMT, TONGUE STANDARD CLEVIS 00778053 WDMT,CLEVIS 00760941 WDMT, JACK TUBE MOUNT 00791218 PIN, CLEVIS PIVOT 02822500 FLATWASHER 1 PL STD 00755153 PIN,COTTER 3/16 X 1-1/2 PLATED 316020H5C HEXB 5/8 NC 2 PL8 00695100 NUT, TOPLOCK 5/8 NC PLC 00756077...

  • Page 40: Tire Options

    TIRE OPTIONS TR208 ©2019 Alamo Group Inc. Parts Section -37...
