WWG-2
LARGE-SIZE DISPLAY
USER MANUAL
ITKU-07-03-05-22-EN

Advertisement

Table of Contents
loading

Related Manuals for RADWAG WWG-2

Summary of Contents for RADWAG WWG-2

  • Page 1 WWG-2 LARGE-SIZE DISPLAY USER MANUAL ITKU-07-03-05-22-EN...
  • Page 2 MAY 2022...

  • Page 3: Table Of Contents

    CONTENTS 1. GENERAL INFORMATION ..........................5 2. WARRANTY CONDITIONS ..........................5 3. MAINTENANCE ..............................5 3.1. Cleaning Stainless Steel Components ......................5 3.2. Cleaning ABS Components ......................... 6 4. SERVICE AND REPAIR ............................. 6 5. RECYCLING ............................... 7 6. MECHANICAL DESIGN ............................. 7 6.1.
  • Page 4 PRECAUTIONS Prior to installation, operation, or maintenance activities, carefully read this user manual. Follow the instructions strictly. Prior to the first use, carefully read this user manual. Use the device only as intended. The device must not be used in environments with explosive gases or dust.

  • Page 5: General Information

    RS232 interface. The display is supplied with 230VAC. 2. WARRANTY CONDITIONS A. RADWAG is obliged to repair or exchange all elements that appear to be faulty by production or by construction. B. Defining defects of unknown origin and methods for eliminating them can only be accomplished with the assistance of the manufacturer and user representatives.

  • Page 6: Cleaning Abs Components

    The damaged component must be replaced or repaired by RADWAG service directly. In the case of defects, deliver the faulty product to the manufacturer's service point. If the product cannot be delivered to the manufacturer's service point, call the service and report the defect.

  • Page 7: Recycling

    The device must be recycled; it should not be disposed of as regular household waste. The device to be decommissioned must be decommissioned in accordance with valid legal regulations. 6. MECHANICAL DESIGN 6.1. Dimensions Fig.1. Dimensions of the WWG-2 large-size display 6.2. Fixing Method Fig. 2. Way of fixing the WWG-2 large-size display.

  • Page 8: Models

    Dimensions (without handle) 635x195x48mm 7. START-UP The WWG-2 large-size display should be connected to the scale's RS232 port and then to the mains supply. When communication with the scale is established, the background of the display is backlit and the mass value is displayed.

  • Page 9: Communication Protocol

    9. COMMUNICATION PROTOCOL The display supports a communication frame sent as a continuous transmission. Frame format supported by the display: 7-15 stability space space character mass space unit marker Command 3 characters, left justification [space] if stable [?] if unstable Stability marker [^] if high limit is out of range [v] if low limit is out of range...
