EKHO EK-WL8-OV General Description Manual

Wireless optical smoke sensor with integrated voice annunciator and visual alarm device (vad)
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
STFV.425238.037-AU-UM rev. 24
GENERAL DESCRIPTION
EK-WL8-OV is a wireless 3-in-1 optical smoke
sensor with an integrated voice annunciator
and visual alarm device (VAD).
The device analyses the protected area for
traces of smoke. An alarm condition is
generated when the smoke level exceeds the
threshold. The alarm signal is relayed to the
Control
Panel
translator/expander modules.
The advanced design of the optical chamber
guarantees a very high level of dust protection,
effectively
increasing
maintenance procedures.
The device is supplied with a mounting kit.
The product complies with the requirements of the AS ISO 7240.7, AS ISO
7240.23:2014 and AS ISO 7240.25 standards.
FEATURES
• Bi-directional wireless communication
• Intelligent algorithms
• Tamper switch
• 10-year battery life
• Self-optimizing wireless frequency and amplitude algorithms
• Patented smoke chamber design
• Integral VAD with white LED's (C-3-2.6)
via
the
connected
the
time
between
EK-WL8-OV/AU
WIRELESS OPTICAL SMOKE SENSOR
WITH INTEGRATED VOICE
ANNUNCIATOR AND VISUAL ALARM
DEVICE (VAD)
06.11.2020
Page 1 from 8
