SERVICE MANUAL
COLD DELI 3/4/5 MERCHANDISERS
MODELS
Premium curved and square
Essential curved and square
Self Service curved and square
CD 3 Self service on underframe
WWW.FRIJADO.COM
This manual is prepared for the use of trained Service Technici-
ans and should not be used by those not properly qualified. If
you have attended a trianing for this product, you may be quali-
fied to perform all the procedures in this manual.
This manual is not intended to be all encompassing. If you have
not attended a training for this product, you should read, in its
entirety, the repair procedure you wish to performto determine
if you have the necessary tools, instruments and skills required
to perform the procedure. Procedures for which you do not have
the necessary tools, instruments and skills should be performed
by a trained technician.
Reproduction or other use of this Manual, without the express
written consent of Fri-Jado, is prohibited.
CD 5 Square on underframe
- NOTICE -
Service Manual Cold Deli CD3/4/5 form 9123583 rev.4/2015
