- Page 1 TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1 Release Date: 2019-03-27...
- Page 2 This Manual contains information of the Techman Robot product series (hereinafter referred to as the TM Robot).The information contained herein is the property of Techman Robot Inc. (hereinafter referred to as the Corporation). No part of this publication may be reproduced or copied in any way, shape or form without prior authorization from the Corporation.
-
Page 3: Table Of Contents
Control Box Installation for TM5 series HW 3.0 ....................13 Robot Arm Installation ............................16 TM Mobile Workstation Application ........................17 Casters Setting ..............................17 Terminal Block Wiring ............................18 TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... -
Page 4: Revision History Table
Original release 1. Add Packing List for Control Box TM5 Series HW 3.00 Components October 2018 2. Add Installation for Control Box TM5 Series HW 3.00 March 2019 update Packing List TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... -
Page 5: Product Function And Specification
Function TM Mobile Workstation is a convenient tool for users to organize and store the TM Robot, the control box and other components. Users can move the TM Mobile Workstation with the TM Robot to different work cells for easy and flexible deployment. -
Page 6: Three-View Diagram
Three-view Diagram ＊ ＊ * The distances have deducted the wheel range. Flange Surface TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... -
Page 7: Packing List
2 x Bracket B 2 x Rail (HW3.0) (HW2.0/ 3 holes) (HW2.0/ 2 holes) 2 x Bracket A 2 x Bracket B 1 x Desktop Cover (HW3.0/ 4 holes) (HW3.0/ 3 holes) TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... - Page 8 Taiwan, Japan, and North America. To compatible with the plugs and sockets regulated by your local governments, it is recommend to use the power cord comes with the TM Mobile Workstation to connect between control box and TM Mobile Workstation and use the power cord comes with TM Robot for external power.
-
Page 9: Installation
Mount both of the Rail (HW1.0) on the control box with #6-32. #6-32 Combination Put the control box on the TM Mobile Workstation as shown below, and then secure the control box with M4*6mm Combination. TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... -
Page 10: Control Box Installation For Tm5 Series Hw 2.0
M4*6mm Combination Control Box Installation for TM5 series HW 2.0 Remove the hand grips and the foot stands. Hand Grip Foot Stand Positions to Detach the Hand Grip TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... - Page 11 Positions to Detach the Foot Stand Mount both of the Rail (HW2.0) on the braces inside of the TM Mobile Workstation with M4*6mm Screws to the respective holes as shown. Holes for M4*6mm Flat Screws TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1...
- Page 12 Put the control box on both of Rails (HW2.0) of the TM Mobile Workstation as shown below, and then secure the control box with both of Brackets A (HW2.0), both of Brackets B (HW2.0), M4*6mm Combination langed-Hex/Phillips-Head Screws, and the screws removed from the hand grips.
-
Page 13: Control Box Installation For Tm5 Series Hw 3.0
Control Box Installation for TM5 series HW 3.0 Remove the hand grips and the foot stands. Hand Grip Foot Stand Positions to Detach the Hand Grip Positions to Detach the Foot Stand TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... - Page 14 Holes for M4*6mm Flat Screws Put the control box on both of Rails (HW3.0) of the TM Mobile Workstation as shown below, and then secure the control box with both of Brackets A (HW3.0), both of Brackets B (HW3.0), M4*6mm Combination langed-Hex/Phillips-Head Screws, and the screws removed from the hand grips.
- Page 15 The screw removed from the hand grips M4*6mm Combination Bracket A (HW3.0) Flanged-Hex/Phillips-Head Screw M4*6mm Combination Bracket B (HW3.0) Flanged-Hex/Phillips-Head Screw TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1...
-
Page 16: Robot Arm Installation
Cable of the Robot Pass cable of the robot through the cord hole and connect to control box, and cover the cord hole with desktop cover. Desktop Cover Cord Hole TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... -
Page 17: Tm Mobile Workstation Application
TM Mobile Workstation Application You can put insertion stopper nuts into the slots at the top of the TM Mobile Workstation, and thread your application with bolts together on the nuts. The recommended thread nominal of the insertion stopper nuts come with the dimension of 10mm x 5mm is M5 or M6. -
Page 18: Terminal Block Wiring
Terminal Block Wiring After shutting down the control box and turning off the circuit breaker, connect L2, N2, and PE with the extension cord. Turn on the circuit breaker. TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1... - Page 19 TM Mobile Workstation Manual Hardware Version: 1.0 Document Version: 2.1...
