- Page 1 V5 Universal Throttle Module 28 MAR 17 WoodTech Electronics Ph: 07 3888 2998 Fax: 07 3888 3871 Email: sales@woodtech.net.au Automotive Control Solutions Electronics Engineering - Design & Manufacturing – Over 20 Years Experience...
- Page 2 Typical Installation – Manual Transmission Ignition Switch Engine Revs Engine Revs Increase Switch Decrease Switch Fuse Battery Park Brake Switch White Black Black Green Remote Accelerator Wiring Harness ISUZU P/N 92955197 Vehicle Remote Accelerator Connector Stop Light Switch WoodTech Electronics Ph: 07 3888 2998 Fax: 07 3888 3871 Email: sales@woodtech.net.au Automotive Control Solutions Electronics Engineering - Design &...
- Page 3 IMPORTANT – PLEASE READ ALL INFORMATION BEFORE PROCEEDING WITH INSTALLATION. IF IN DOUBT, ASK! Connections CN1 – 10 Way Number Function 10-30VDC Input Negative Increase Revs – Positive Input Increase Revs – Negative Input Decrease Revs – Positive Input Decrease Revs – Negative Input Lockout 1 –...
- Page 4 All inputs are monitored by on-board LEDs. The LED is lit when the input is active. Each input contains a pair of wires – a positive and a negative. Both wires must be connected for the input to function. By using this method, it does not matter whether your inputs are switching positive or negative signals –...
- Page 5 The number of dipswitches has increased from 4 to 8 in the V5 model to allow for added features in the future. Dipswitches 1 thru 4 work exactly the same way as they did with V4 and have the same functions. If you are replacing a V4 version with a V5 dipswitch 8 must also be Features Designed and manufactured in Australia by WoodTech Electronics –...
- Page 6 Note: The supplied wiring diagrams are correct at the time this document was written. The factory wiring colours do not match up between the remote throttle connector and the extension wiring harness. If in doubt, ask! You will also need to install the parts in the Isuzu Remote Accelerator Kit. Please follow the instructions supplied with the kit.
- Page 7 Start the engine and engage the PTO. Activate the Increase Revs switch and the engine revs should slowly increase. The maximum required engine RPM can be adjusted with the “HI” adjustment. Turning clockwise will increase the RPM. Activate the Decrease Revs switch and the engine rpm should return to idle.
