AIRREX AIR CONDITIONER
▶ Thank you for purchasing this Airrex Portable Air Conditioner.
Please read the instructions thoroughly before operating.
▶ After reading the instructions, please keep them in
a safe place accessible to all users.
▶ Ensure you read the 'safety precautions' in advance and
use the product correctly.
▶ The product is specified for use with a power supply
of 115Va.c. 60Hz.
▶ This manual includes the product warranty.
▶ Specifications and contents of this manual may be changed
without prior notice, in accordance with our commitment
to product quality improvement, design and control.
WATER COOLED
MODEL : HWC-15/19
Advertisement
Table of Contents
Related Manuals for Hephzibah Airrex HWC-15
Summary of Contents for Hephzibah Airrex HWC-15
- Page 1 AIRREX AIR CONDITIONER WATER COOLED MODEL : HWC-15/19 ▶ Thank you for purchasing this Airrex Portable Air Conditioner. Please read the instructions thoroughly before operating. ▶ After reading the instructions, please keep them in a safe place accessible to all users. ▶...
-
Page 2: Table Of Contents
AIR-CONDITIONER CONTENTS ■ SAFETY INSTRUCTIONS ■ PRECAUTIONS FOR USE ■ NAME OF PARTS · MAIN BODY · CONTROL PART ■ HOW TO USE · HOW TO OPERATE · SELECTION of ROOM or SPOT COOLING · TEMPERATURE CONTROL/ ERROR INDICATION ■ HOW TO INSTALL & PRECAUTIONS 9~10 ■... - Page 3 AIR-CONDITIONER SAFETY INSTRUCTIONS These are contents for keeping the safety and preventing the property damage. Please read and use correctly. ● Precautions at this page are for the safe and correct use of the unit and for the preventing a danger and damage of the operator or others.
-
Page 4: Safety Instructions 3~4
AIR-CONDITIONER SAFETY INSTRUCTIONS For the damage occurred due to non-keeping of following matters, the manufacturer is not responsible for the compensation. When thunder, lightning or no-operation for Do not install the product on a long time, pull the power plug out of the outlet. the uneven or slant place. -
Page 5: Name Of Parts
AIR-CONDITIONER NAME OF PARTS ♣ For the efficiency improvement of this product, the specification may be changed without prior notice. Front Side Discharge Duct (The place where cold air comes out.) Handle Digital controller Air intake hole (Evaporator) Indoor unit/ Filter (The place where indoor air enters.) Casters for moving (This unit can be moved freely anywhere.) -
Page 6: Control Part
AIR-CONDITIONER NAME OF PARTS Control Part ⑨ ⑧ ⑦ ⑥ ⑤ ④ High / Low ① ③ ② ① POWER : It is used for ON/OFF ② Air Volume Control : High and Low for the discharging air volume. (Initial setting : High) ③... -
Page 7: How To Use
AIR-CONDITIONER HOW TO USE How to operate 1. Operation & Stop Confirm that the power cord is connected to the outlet. Press the Power button, and the operation starts automatically. At this time, it is operated as the basically Cool mode and Fan speed High. -
Page 8: Temperature Control/ Error Indication
AIR-CONDITIONER HOW TO USE Temperature Control When the operation begins, the setting temperature is shown. (Operation Off) The initial set temperature is 60℉. Press the temperature control button , you can select the desired set temperature. The range of temperature control is 34~86℉. -
Page 9: How To Install & Precautions 9~10
AIR-CONDITIONER HOW TO INSTALL & PRECAUTIONS Selection of the Installation Place As the air conditioner should be connected with the tap water tube, its installation near the hydrant is good. Install it on the even and stable place. How to Connect Pipes 1. - Page 10 AIR-CONDITIONER HOW TO INSTALL & PRECAUTIONS Check Points after Installation After confirming the state of pipe connection, check whether a leakage is at the connection part. Confirm whether the connection of the drain hose is good. Confirm whether the earth line is good. Precautions for Installation 1.
-
Page 11: Cleaning And Maintenance
AIR-CONDITIONER CLEANING AND MAINTENANCE Cleaning the Air Filters and Maintenance Cleaning of filter : Detach the filter from the A/C, Cleaning of heat-exchanger : Clean dust attached and clean it with compressed air or water. to the heat-exchanger with compressed air or a vacuum cleaner. -
Page 12: Trouble Shootings
AIR-CONDITIONER TROUBLE SHOOTINGS Symptom Check Points Measures to be Taken ● Is the power plug pulled out? ● Insert the plug. The operation ● Is the operation stopped? ● Press ON/ OFF switch, and confirm is not done. the lamp condition. ●... -
Page 13: Specifications & Accessaries
AIR-CONDITIONER SPECIFICATIONS & ACCESSARIES MODEL HWC-15 HWC-19 Cooling Capacity 13,800 Btu/h 18,200 Btu/h Power Supply 115Va.c. 60Hz 1ph Size (WxDxH) 17.7 X 22.8 X 42 (inch.) Weight 159 lbs 77lbs Power Consumption 1.1 kW 2.1kW R410a 1.1 lb R410a 1.32 lb Refrigerant Aluminum Filter AIR Filter... -
Page 14: Warranty
Warranty (Applicable to first retail purchaser only) AIRREX WATER COOL AIR CONDITIONER give more reliable performance, comfort and durability the more they are used. They are built under a strict quality assurance regime which includes inspection both during and after production and exhaustive reliability testing. - Page 15 AIR-CONDITIONER MEMO.
- Page 16 AIRREX USA P.O BOX 340 HEWITT. TEXAS 76643 TEL : 800-699-8998 FAX : 469-574-7924 E-mail : sales@airrexusa.com Website : www. airrexusa. com HEPHZIBAH CO.,LTD. 423-5 CHUNGCHUN-DONG, BUPYUNG-KU INCHEON, KOREA TEL : +82-32-509-5834 FAX : +82-32-502-5519 E-mail : airrex@hdtek.com Website : www.airrex.co.kr...
