AIRREX AIR CONDITIONER
▶ Thank you for purchasing an AIRREX AIR CONDITIONER.
BEFORE operation please read this user's manual carefully.
▶ Keep this manual readily available.
▶ It is ESSENTIAL that you read the 'NOTES ON SAFETY' carefully
before use and follow them at all times.
▶ This Air Conditioner is specified for use on the rated voltage
power supply. For use outside you must check that the local
electricity supply is the same by a qualified electrician.
▶ The Warranty form is on Page 16. Please complete it now and
keep in a safe place.
▶ We have a policy of continual improving to our products.
The contents (features and specifications) in this manual are
therefore subject to change without notice.
USER'S MANUAL
HSC-5000A
Advertisement
Table of Contents
Related Manuals for Hephzibah Airrex HSC-5000A
Summary of Contents for Hephzibah Airrex HSC-5000A
- Page 1 AIRREX AIR CONDITIONER USER'S MANUAL HSC-5000A ▶ Thank you for purchasing an AIRREX AIR CONDITIONER. BEFORE operation please read this user’s manual carefully. ▶ Keep this manual readily available. ▶ It is ESSENTIAL that you read the ‘NOTES ON SAFETY’ carefully before use and follow them at all times.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ■ SAFETY INSTRUCTIONS ■ GENERAL ADVICE BEFORE USE ■ EXTERIOR DESCRIPTION ■ OPERATION ■ SELECTION of AREA/ROOM or SPOT COOLING ■ TEMPERATURE CONTROL OPERATION ■ HOW TO SET THE 'OFF' TIMER ■ 'ERROR' and WARNING INDICATORS ■ CLEANING AND MAINTENANCE ■... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following instructions are for ensuring the user's safety and to prevent any physical injury or material damage. Please read carefully and follow all instructions. There are two sections to these instructions: WARNING and CAUTION. The following symbols are for your guidance: = You must NOT. -
Page 4: General Advice Before Use
SAFETY INSTRUCTIONS CAUTION Do not place cooler on uneven, unstable or inclined surface. (This could cause malfunction) When storing the cooler, ensure that it is kept in a dry, cool place. (To prevent corrosion and malfunction) If not being used for some time or if lightening is present, always unplug from power. -
Page 5: Exterior Description
EXTERIOR DESCRIPTION FRONT VIEW FLEXIBLE DUCT OUTLET (COLD AIR) DIGITAL CONTROLLER EVAPORATOR FILTER AMBIENT AIR INTAKE. ELECTRIC PANEL (ACCESS BY AUTHORISED SERVICE PERSONNEL ONLY) CONDENSED WATER TANK IN THE CASE TO COLLECT WATER AND GENERATED DURING COOLING. CASTERS (FRONT LOCKABLE) BACK VIEW CONDENSER OUTLET (HOT AIR) CONDENSER FILTER... - Page 6 EXTERIOR DESCRIPTION CONTROL PANEL ⑧ ⑤ ⑨ ⑥ ⑦ ③ ④ ⑩ ② ① ① Power : Use to power On / Off. ② : Raises or lowers temperature and/ or sleep (off) time. ③ Cool : Use to select cooling mode. ④...
-
Page 7: Operation
OPERATION RUNNING & STOP 1. START BY PRESSING THE ‘POWER’ BUTTON. ·Cooler will start up automatically. ·To STOP the unit, press the ‘POWER’ button once again. 2. If you wish to operate on fan only, press the ‘COOL’ button. To resume cooling, press the ‘COOL’... -
Page 8: Selection Of Area/Room Or Spot Cooling
SELECTION of AREA/ROOM or SPOT COOLING To reduce the temperature of the entire room select 'Area/Room'. For ‘targeted’ cooling of machinery, servers, or people etc. select ‘Spot Cooling’. 1. If you want to display room temperature, push cool and button simultaneously for 3 seconds. -
Page 9: Temperature Control Operation
TEMPERATURE CONTROL OPERATION 1. When power is ON, the setting temperature is displayed. Default of setting temperature is as below. 10℃(50℉) in Spot Mode. 16℃(60℉) in Room Mode. 2. When you push either (up) or (down) button, the setting temperature can be changed. 3. -
Page 10: How To Set The 'Off' Timer
HOW TO SET THE 'OFF' TIMER. This function enables you to set the length of time you want the cooler to operate. You can set the time period from 30min. to 24 hours in 30min. and 1 hour increments. 1. When cooler is operating, press the 'Off Timer' button and set the length of time you want by pressing ▲... -
Page 11: Error' And Warning Indicators
'ERROR' and WARNING INDICATORS The machine's safety devices will automatically signal any problems via the display window on the control panel. The information below shows how to read these signals. Water Full 1. WATER FULL- Display shows "tF" When the water container is full, "tF" is displayed and the LED "Water Full"... -
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING THE AIR FILTERS 1. To remove filters, slide up a little ① and pull towards you ②. 2. Clean the filters with water or compressed air. 3. Clean evaporator and condenser units with a vacuum cleaner or compressed air. MAINTENANCE 1. -
Page 13: Trouble Shooting
TROBULE SHOOTING TROUBLE CHECK REMEDY ● Cord correctly connected ● Connect cord correctly WORKING ● POWER button “OFF” ● Press POWER button to “ON” ● Fuse (supply) blown ● Exchange fuse in board ● Breaker on switch board ● Check load capacity a`nd reset tripped ●... -
Page 14: Specifications
SPECIFICATIONS MODEL HSC-5000A BTU/h 60,000 Cooling Capacity (17.6) Power Supply 380-415Vac 50Hz. 3Ph. Dimensions 740 X 1,400 X 1,490 Weight Evaporator Air Flow /min Power Consumption Current Consumption Amp. Refrigerant R-410A / 3,500 Air Filter Aluminium Mesh Cartridge ▶ High Pressure Switch ▶... - Page 15 WIRING DIAGRAM RP PCB DRAWING...
-
Page 16: Warranty
DISTRIBUTOR Telephone No. Name : CUSTOMER Address : DETAILS Telephone : HEPHZIBAH CO.,LTD. (Juan-dong) 86, Gilpa-ro 71beon-gil, Nam-gu, Incheon, Korea TEL : +82-32-509-5834 FAX : +82-32-502-5519 E-mail : airrex@airrex.co.kr Website : www.airrex.co.kr ● Designs and specifications of products are subject to change without prior notice for the improvement of products.
